PB 5032 Grande Ring Chandelier
Product Information
The Overture Grande Ring Chandelier is a light fixture designed
to be installed in accordance with local installation codes. It
should be installed by a person familiar with the construction and
operation of the fixture, as well as the associated hazards. The
item is labeled as PB 5032.
Product Usage Instructions
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Remove the mounting plate (C) from the canopy (J) by taking off
the collar ring (Y). - Detach the mounting plate bracket (H) from the mounting plate
(C) by removing screws (B). - Install the mounting plate (C) to the junction box and secure
it with mounting screws (D). - Connect the supply ground wire (usually green or bare copper)
around the mounting screw (M). - Slide the collar ring (Y) and canopy (J) down onto the hub (O)
while holding the fixture upright. Then connect the top rod (M3) to
the middle rod (M2). Slide components down slowly to avoid
damages. - Hang the fixture swivel ball (I) to the center of bracket (H)
and secure it with set screw (G) using the provided wrench
(F). - Cut excess wire, leaving enough to reach the junction box.
- Remove the outer housing of the wire by making a neat cut all
around, about 1″ from the end. Be careful not to cut too deep to
avoid damaging electrical wires underneath. Remove and discard the
1″ piece of housing, exposing the electrical wires. - Separate the wire and strip insulation on each end by
5/8″. - Connect the fixture neutral wire (black) to the driver (E)
output wire (black) using the wire nut (A). - Connect the fixture hot wire (red) to the driver (E) output
wire (red) using the wire nut (A). Ensure not to reverse the hot
and neutral connections. - Install the canopy (J) to the mounting plate bracket (H) and
secure it with the collar ring (Y). - Thread rods (S) to the fixture body (P).
- Remove protective covers (R) from the socket, then thread
shades (Q) onto the sockets. Do not overtighten, as it may damage
the shade.
Care Instructions
Clean the fixture only with a soft dry cloth or feather duster.
Avoid using abrasive or chemical agents.
ASSEMBLY INSTRUCTIONS
Diagram 1
F G
F G H I
Diagram 2
A B
C D
E
A H I J M3
Y
M2
M1
O
P Q R
S
Overture Grande Ring Chandelier
Item # PB 5032
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Wire Strippers
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (C) from canopy (J) by removing collar
ring (Y). 3. Remove mounting plate bracket (H) from mounting plate (C) by
removing screws (B). 4. Install mounting plate (C) to the junction box and secure with mounting
screws (D). 5. Connect supply ground wire (usually green or bare copper) around the
green grounding screw (see diagram 1). Tighten. NOTE: It is imperative that the fixture is grounded. 6. Connect driver (E) input neutral wire (white) to the supply neutral wire (usually white) using wire nut (A). 7. Connect driver (E) input hot wire (black) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections. 8. Make sure all wire connections are tight, then carefully tuck into the junction box. 9. Place driver (E) onto the mounting plate bracket (H), then install to mounting plate (C) and secure with screws (B). 10. Feed electrical wire through bottom rod (M1) and thread to hub (O). Repeat for middle rod (M2), connecting to bottom rod (M1). 11. Continue feeding wire through collar ring (Y), canopy (J) and top rod (K).
M
LI ST ED
US
ASSEMBLY INSTRUCTIONS
Diagram 1
F G
F G H I
Diagram 2
A B
C D
E
A H I J M3
Y
M2
M1
O
P Q R
S
Overture Grande Ring Chandelier
Item # PB 5032
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
12. Holding fixture upright, slide collar ring (Y) and canopy (J) down and rest on hub (O). Then connect top rod (M3) to middle rod (M2). NOTE: Slide components down slowly to avoid damages.
13. Hang fixture swivel ball (I) to center of bracket (H) and secure with set screw (G) using provided wrench (F). See diagram 2.
14. Cut excess wire, being sure to leave enough to reach the junction box.
15. Remove outer housing of wire by making a neat cut all the way around, about 1″ from the end. Make sure not to cut too deep or electrical wires could be damaged underneath. Once cut is made, remove and discard the 1″ piece of housing off the end, exposing the electrical wires.
16. Separate wire and strip insulation on each 5/8″. 17. Connect fixture neutral wire (black) to driver (E) output wire (black)
using wire nut (A). 18. Connect fixture hot wire (red) to driver (E) output wire (red) using wire
nut (A). CAUTION: Do not reverse the hot and neutral connections. 19. Install canopy (J) to mounting plate bracket (H) and secure with collar ring (Y). 20. Thread rods (S) to fixture body (P). 21. Remove protective covers (R) from socket, then thread shades (Q) to sockets. NOTE: Do not overtighten otherwise shade could become damaged.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
M
LI ST ED
US
ASSEMBLY INSTRUCTIONS
S
T
X
U V
Diagram 3
O
NL
T
NL
Y Z
V
Diagram 4
M1
O
S
X
T
U
V
W
Overture Grande Ring Chandelier
Item # PB 5032
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
Inverted Installation: 1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Loosen set screw (S) using provided wrench (X), then unscrew
hub (O) from base (V). See diagram 3. 3. Loosen bottom screws on terminal block (T) and screws (Z) on cable
nut (Y), then remove wires and separate. 4. Loosen set screws (U) and remove cables (W) from base (V). Turn
fixture over, then re-assemble cables (W) to base (V), securing with set screws (U). 5. Install cable nuts (Y) to end of hanging cables. Insert other end of hanging cable (Y) through the cable lock and tighten screw ends (Z) with a screwdriver to secure. See diagram 4. 6. Twist fixture neutral wires (black) together, then insert into terminal block neutral (N) and secure screw. See diagram 4. 7. Twist fixture line wires (red) together, then insert into terminal block line (L) and secure screw. See diagram 4. P 8. Install hub (O) to hub base (V) and secure with set screw (S) using provided wrench (X).
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
