RS720A-E12 Servers and Workstations

Product Information:

The RS720A-E12 is a server motherboard designed for
high-performance computing. It comes with various FRU (Field
Replaceable Unit) parts and upgrade kits that allow for
customization and expansion.

FRU Parts & Upgrade Kits:

Motherboard Converted Board: Part Number:
90SB0AS0-M0XBN0
Backplane: Part Number: 90SC0G10-M0XBN0
Front I/O Board Cable: Part Number:
90SC0F80-M0XBN0
Riser Card: Part Number: 90SC0F70-M0XBN0
Riser Kit: Part Number: 90SC0JU0-M1XBN0
Fan (Include fan cables): Part Number:
90SC0IC0-M0XBN1
Heatsink (Include thermal grease/pad): Part
Number: 90SC0K60-M1XBN0
HDD Tray: Part Number: 90SC0JD0-M0XBN0 /
90SC0JE0-M0XBN0
Power Supply: Part Numbers: 90SKP000-M4PAN0,
90SKP000-M4UAN0, 90SKP000-M4FAN0, 90SKP000-M28AN0

Upgrade Kits:

Double-deck GPU upgrade kit: Part Number: 8038
FAN 6PIN 16300RPM DELTA (13070-01270200)
AMD SP5 1U EVAC HS(GPU SKU): Part Number:
13SF02D0M03011
AMD SP5 2U STD HS(non-GPU SKU): Part Number:
13SF02E0M04011
2.5 HDD TRAY TOOLLESS (Front/Rear): Part
Number: 13SF02E0AM0101
3.5 HDD TRAY TOOLLESS: Part Number:
13SF01A0AM110113SV0005M10011

Note: Some parts may be unavailable for repair due to Customer
Induced Damage (CID). Please contact Customer Service Center for
assistance.

Product Usage Instructions:

1. To replace the Motherboard Converted Board, Backplane, Front
I/O Board Cable, Riser Card, Riser Kit, Fan, Heatsink, HDD Tray, or
Power Supply, follow these steps:

Ensure the server is powered off and unplugged.
Locate the specific part that needs replacement.
Remove any screws or connectors holding the current part in
place.
Gently disconnect the cables attached to the part.
Take out the old part and replace it with the new one.
Secure the new part with screws or connectors.
Reconnect any cables previously disconnected.
Power on the server and ensure the new part is functioning
properly.

2. To install an Upgrade Kit, follow these steps:

Ensure the server is powered off and unplugged.
Locate the specific Upgrade Kit you want to install.
Refer to the provided manual or instructions for detailed
installation steps.
Follow the instructions to properly install the Upgrade
Kit.
Secure all connections and ensure everything is properly
seated.
Power on the server and verify that the Upgrade Kit is
functioning as intended.

For any further assistance or questions, please refer to the
user manual or contact Customer Service Center.

View Fullscreen

RS720A-E12 FRU Parts & Upgrade Kits list
The illustrations below show the components of RS720A-E12 (Illustration model may not be the same, for more detailed information, please refer to the SN)

FRU Parts & Upgrade Kits list
Part Number MOQ

Description

Motherboard Converted Board Backplane
Front I/O Board Cable

90SB0AS0-M0XBN0 1 90SC0G10-M0XBN0 1
90SC0F80-M0XBN0 1
90SC0F70-M0XBN0 1 90SC0JU0-M1XBN0 1 90SC0IC0-M0XBN1 1 90SC0K60-M1XBN0 1
90SC0JD0-M0XBN0 T 90SC0JE0-M0XBN0 1
90SK0000-MMRAN0 1 set

90SKS000-M21BN0 1 set

90SKS000-M3JAN0 1 set

90SKS000-M3KAN0 1 set

90SKS000-M3LAN0 1 set

90SKS000-M3MAN0 1 set

90SKS000-M3NAN0 1 set

90SKS000-M3PAN0 1 set

K14PP-D24 FPB-R2P-B
CB12LE16G-R2PB/Gen4 support
BP24LE16G-25-R2PBD (RS24U) BP24LE32G-25-R2PD (RS24) BP12LE32G-35-R2PD (RS12) BP2LE32G-25-R2PD//R1.03 (RS12 Rear BP)
CBI-10G-X710-R1PB CBI-1G-I350-R1PB
8SATA Cable Kit/RS720A-E12-RS24U (14022-00270000*2) 8SATA Cable Kit (RS720A-E12-RS24) (14022-00130600) 8NVMe Cable Kit (RS720A-E12-RS24 GPU SKU) (14022-00362400*214022-00250900*2) 16NVMe Cable Kit (Non-GPU SKU) (14022-00250900*414022-00310900*2) 8NVMe Cable Kit (For RS720A-E12-RS12) (14022-00250900*4) 4NVMe Cable Kit (For RS720A-E12-RS12) (14022-00250900*2) 9560 RAID Cable Kit/Support NVMe/SATA/SAS (RS24U) (14022-00270000*214022-00330200) 9560 RAID Cable Kit/Support NVMe/SATA/SAS (RS24/RS12) (14022-00130600*214022-0033020014022-00137700*2)

Riser Card

90SC0H10-M0XBN0 1 90SC0IA0-M0XBN0 1 90SC0IB0-M0XBN0 1

Riser Kit

90SKS000-M4RAN0 1 set

Fan (Include fan cables)

90SK0000-MJDBN0 1 set

Heatsink (Include 90SKS000-M4PAN0 1

thermal

90SKS000-M4LAN0 1

grease/pad)

HDD Tray

90SKH000-MPPBN0 10 90SKH000-MPRBN0 10

Power Supply

90SKP000-M4PAN0 1 90SKP000-M4UAN0 1 90SKP000-M4FAN0 1 90SKP000-M28AN0 1

RF16RG8L-R1PB(Low Profile Slot) RF16LX4-D-R2PD(4 Slots) RF16LX2-D-R2PD(2 Slots)
Double-deck GPU upgrade kit
8038 FAN 6PIN 16300RPM DELTA (13070-01270200)
AMD SP5 1U EVAC HS(GPU SKU) (13SF02D0M03011) AMD SP5 2U STD HS(non-GPU SKU) (13SF02E0M04011)
2.5″ HDD TRAY TOOLLESS (Front/Rear) (13SF02E0AM0101) 3.5″ HDD TRAY TOOLLESS (13SF01A0AM110113SV0005M10011)
PSU CRPS 2600W TITANIUM/GOSPOWER (0A100-00450700U:0A100-00450400 ) PSU CRPS 1600W TITANIUM/GOSPOWER (0A100-00251400S:0A100-00252000) PSU CRPS 2000W PLATINUM/ACBEL (0A100-00310900) PSU CRPS 1600W PLATINUM/CHICONY (0A100-00251700U:0A100-00251200)

Parts unavailable
If there is any CID (Customer Induced Damage) related repair demand, below spares parts are not available and suggest to go through CSC (Customer Service Center) process:
· Chassis · Screws · M.2 stand off · Ear BKT with front panel board · HDD Cage · COM port

Riser Kit
– Please select by model / SKU / configuration

Component
4-slot Riser Kit(GPU SKU)

Part No.
90SKXXXX-XXX

4-slot Riser Kit(Non-GPU SKU)

90SKXXXX-XXX

2-slot Riser Kit(GPU SKU)

90SKXXXX-XXX

2-slot Riser Kit(Non-GPU SKU)

90SKXXXX-XXX

1-slot Low Profile Riser Kit Double-deck GPU upgrade kit Single-deck GPU upgrade kit

90SKXXXX-XXX 90SKXXXX-XXX 90SKXXXX-XXX

MOQ
