900005 6-Light Bronze Iron Ceiling Lamp Chandelier Pendant
Product Information
The product is a light fixture that requires a supply circuit of
120V and 60Hz. It is compatible with six E26 60W max bulbs (not
included). The suggested bulb type is 9W LED ST58 bulb. The package
includes a canopy with mounting kits and ground wire, stems, rod,
light cluster, pipes, and frames. The parts are packed in a parts
bag. The product has various parts with different quantities, and
each part has a specific code and name.
Product Usage Instructions
- Open the box from the top and carefully take out all the
components, parts bag, and manual from the box. - Check all the components against the parts list to ensure that
you have each part. If any parts are missing or damaged, contact
the manufacturer at [email protected] to get a replacement. Parts
that are shown as 0 under QTY are not included. - Refer to the illustration provided in the manual for assembly
and wiring. Follow the steps below:
- Attach the top frame (N) onto the tabs of the top of four
square pipes (R) by using screws (P). Do not attach tightly
yet. - Connect the stem with swivel fixture wire (I) to the bottom
frame (S) by using hex nut (E) and washer (F). - Attach the mounting bracket with studs (C) onto the junction
box by using two mounting screws (D). - Secure the junction box supply wires onto the supply wires in
the mounting bracket using wire nuts (H). - Insert the mounting bracket with studs into the central rod (O)
and secure it by using hex nut (G) and waved washer (K). - Attach the square pipes (R) to the central rod (O) by using hex
nut (B) and washer (J). - Attach the light cluster (T) to the bottom frame (S) by using
screws (P). - Attach the canopy (A) to the central rod (O) by using cap nut
(U). - Attach the cap top frame (M) to the top of the central rod (O)
by using screws (P). - Attach the ring (L) to the bottom of the central rod (O) by
using screws (P). - Attach the ground wire (Q) to the mounting bracket with studs
(C) by using a screw (P). - Use an Allen wrench (X) to tighten all the hex nuts.
Note: Please make sure to turn off the power supply before
installation.
Missing parts? Glass damage? Any questions?
Please email us at : [email protected]
We are always here to help you fix the problems you are facing.
Assembly & Installation Instructions
MODEL: 900005 900006 IMPORTANT SAFETY INSTRUCTIONS: · Warning: If any special control devices are used with this fixture, follow the instructions carefully to assure
full compliance with N.E.C. requirements. If there are any questions, please contact a qualified electric contractor. · Warning: This product can expose you to chemicals including lead, which is known to the State of California, to cause cancer or birth defects or other reproductive harm. For more information, please go to www.P65Warnings.ca.gov · Caution: Electrician installation highly recommended. All glass is fragile, use care when handling glass component(s) and or lamp(s). Read instructions carefully and turn electricity off at the main circuit breaker panel before beginning installation. Important Notice: This is a generic instruction sheet used for various fixtures. The shape and style of fixture / glass / shade / diffuser may vary.
(Required Supply Circuit: 120V, 60Hz. Bulb Type: 6*E26*60W Max) Compatible Bulb Type(NOT Included) The mostly suggested bulb type is 9W LED ST58 bulb
COMPONENTS INCLUDED IN THE PACKAGE Canopy with mounting kits & ground wire/Stems/Rod/Light cluster/Pipes/Frames Parts packed in parts bag
ASSEMBLY & INSTALLATION STEPS:
1. Open the box from top, take out all the components, parts bag and manual from the box carefully. 2. Check all the components against the parts list. Make sure get each parts on list. If any parts missing or glass damage, please contact manufacturer at: [email protected] to get a replacement. Parts are NOT included for which is shown as 0 under QTY.
Part Name Junction Box Supply Wires Mounting Bracket with Studs Mounting Screw Hex Nut Waved Washer Washer Canopy 6″ Stem with Swivel Fixture Wire 12″ Stem Ring
QTY 0 0 1 2 2 2 2 1 2 2 8 2
Code A B C D E F G H I J K L
PARTS LIST Part Name
Cap Top Frame Central Rod Screw Light Bulb Square Pipe with Tabs Light Cluster Bottom Frame Wire Nut Ground Wire Cap Nut Allen Wrench
QTY 2 1 2 16 0 4 1 1 3 1 2 1
Code M N O P Q R S T U V W X
3. Refer to the illustration while doing assembly and follow the steps as below: I Attach the top frame (N) onto the tabs of the TOP of four square pipes (R) by the screws (P), do not
fasten the screws yet. Attach the bottom frame (T) onto the tabs of the BOTTOM end of the pipes (R) by the screws (P). Adjust four pipes, top and bottom frames to a perfect position, then fasten the screws. II Release the ring (L) from the top of the central rod (O) first, then insert the rod (O) with fixture wires (J) into the central hole of top frame (N), slide on the cap (M) to cover the top openning of top frame (N), then fix it in position with the ring (L). Thread the other end of central rod (O) with the light cluster (S). Place fixture wires (J) through the central rod (O) for later installation. III Thread the short and long stems (I & K) onto the central rods (O) one by one. Release the hex nuts (E), waved washers (F), ground wire (V) and washers (G) from the swivel on the short stem (I), then slide the canopy (H), washers (G), ground wire (V), waved washers (F) and hex nuts (E) onto the stems (I) in sequence, use Allen Wrench (X) to fasten the hex nuts (F) so all parts are fixed in positon. Fixture wires (J) go through the canopy (H) and ready for wiring. IV Adjust the studs on the mounting bracket (C) to a proper protrusion if necessary. As for a test, slide the canopy (H) onto the studs to figure if the cap nuts (W) cover the protrusion properly. Thread the studs toward the junction box (A) a little bit if it protrudes from the canopy (H) too much. Attach the mounting bracket (C) to the junction box (A) by two mounting screws (D). V Connect wires according to the wiring diagram on the right. VI Slide the canopy (H) to the studs on the mounting bracket (C), then fix it with two cap nuts (W). VII Screw the light bulb (Q) onto the socket on the light cluster (S).
Illustration of assembly and wiring:
I. N, T, P
R
II. L, M, N, O
S
III. E, F, G, V
H, I, K, O
IV. C, D
A
V. B, J, V
U
VI. W, H
C
VII. Q
S
A
B C
U
D
V
E GF
H
W
I
J
K
L M
N
O ( Top)
P Q R S P
(Bottom) T
