S1134 Series Multi Channel Signal Generator
Product Information
The S1134 Series Multi-channel Signal Generator is a versatile
device designed for generating multiple RF signals simultaneously.
With a frequency range of 10MHz to 40GHz, it offers 2 to 8 RF
output channels that can operate individually. The signal generator
provides a maximum output power of +15dBm and features low phase
noise, ensuring accurate and reliable signal generation.
Product Usage Instructions
- Power on the S1134 Series Multi-channel Signal Generator by
connecting it to a power source. - Connect the desired RF output channels to the devices or
systems that require the generated signals. - To set the frequency for each channel, use the frequency
control knobs or input the desired frequency values using the
interface panel. - Adjust the output power level by using the power control knobs
or inputting the desired power values through the interface
panel. - If operating multiple channels, ensure that each channel is
configured independently according to the desired frequency and
power settings. - Verify that the phase noise level meets your requirements. If
necessary, refer to the user manual for instructions on adjusting
the phase noise. - Once all settings are configured, initiate signal generation by
pressing the “Start” or “Generate” button on the interface
panel. - Monitor the output signals using appropriate measurement
equipment or by connecting them to the intended
devices/systems. - To stop signal generation, press the “Stop” or “Off” button on
the interface panel. - After usage, power off the S1134 Series Multi-channel Signal
Generator and disconnect it from the power source.
Please refer to the user manual for detailed instructions on
advanced features, troubleshooting, and safety precautions.
S1134 Series Multi-channel Signal Generator
(Frequency Range: 10MHz – 40GHz, 2-8 channels)
Key Features
Frequency range: 10MHz to 40GHz 2-8 RF output channels which can operate individually Maximum output power: +15dBm Phase noise: <-116dBc/Hz (10GHz, 10kHz offset) Phase coherent among every channel Channel to channel relative phase drift (10GHz, 24h) ±1° High-speed frequency switching <10us Narrow pulse modulation, minimum pulse width 50ns Rise/fall time 10ns
Overview
Saluki S1134 series signal generator is a phase-coherent and low phase noise signal generator with 2-8 channels. Every channel can be independently fully adjusted. S1134 series can cover frequency range from 10MHz to 40GHz with frequency resolution as low as 0.01 Hz. The instrument comes in a standard 2U/3U rack-mount form and offers LAN control interface, which allows easy and fast communication. Remote control of the instrument can be quickly attained from any host system. Application programming interface (API) or programming examples make the control implementation very easy. Applications: Local Oscillator Replacement / Component Test / Receiver Sensitivity Test / R&D low noise microwave generator No.367, Fuxing N. Rd.,105 Taipei,Taiwan Tel: +886.909 602 109
[email protected] www.salukitec.com
S1134 Series Multi-channel Signal Generator
(Frequency Range: 10MHz – 40GHz, 2-8 channels)
Technical Specifications
Model
S1134 Series
Frequency Range Output Channel
Output 10MHz – 20/40GHz (each channel can be different) *For other frequency range, contact us for customization* 2-8 channels
Frequency Resolution
0.01Hz
Maximum Output Power
10MHz to 20GHz: +15dBm 20GHz to 40GHz: +13dBm
Minimum Output Power
-110dBm
Power Resolution
0.01dB
Switching Speed
20ms
Power Level Uncertainty
±1.3dB @>-20dBm ±1.5dB @-20 to -70dBm ±3dB @ -70dBm
Harmonic Spurious
-50dBc @10dBm output
Non-harmonic Spurious
10MHz – 12GHz: -70dBc 12GHz – 20GHz: -65dBc 20GHz – 40GHz: -60dBc
Channel to Channel Isolation 80dB
Pulse Modulation
Minimum pulse width 50ns
SSB Phase Noise (@10GHz )
-86dBc/Hz@100Hz -108dBc/Hz@1KHz -116dBc/Hz@10KHz -116dBc/Hz@100KHz -120dBc/Hz@1MHz -140dBc/Hz@10MHz
No.367, Fuxing N. Rd.,105 Taipei,Taiwan Tel: +886.909 602 109
[email protected] www.salukitec.com
S1134 Series Multi-channel Signal Generator
(Frequency Range: 10MHz – 40GHz, 2-8 channels)
SSB Phase Noise (@10GHz )
Frequency Reference
Both external and internal reference supported
Internal Reference Frequency Temperature Stability
±5e-8, 0°C to+50°C
Internal Reference Frequency 10MHz
Internal Reference Output Power
5dBm
External Reference Input Level Range
5dBm – 10dBm
SSB of Internal Reference
-125dBc/Hz@10Hz -140dBc/Hz@100Hz -150dBc/Hz@1KHz -155dBc/Hz@10KHz -155dBc/Hz@100KHz
General Information
LAN Control
RJ-45 (TCP/IP over Ethernet )
No.367, Fuxing N. Rd.,105 Taipei,Taiwan Tel: +886.909 602 109
[email protected] www.salukitec.com
S1134 Series Multi-channel Signal Generator
(Frequency Range: 10MHz – 40GHz, 2-8 channels)
Operation Temperature Operation Humidity Power Supply
Dimension
Weight
0°C to +50°C 20%-80% (+30°C) AC 176-264VAC, 45Hz-65Hz 483 (W) × 89 (H) × 559 (D) mm (2U) 483 (W) × 134 (H) × 559 (D) mm (3U) 20kg
Ordering Information
The output frequency of each channel can be configured flexibly.
Module No. S1134D S1134T S1134Q S1134F S1134S S1134H S1134O
Item 2-channel output, frequency range: 10MHz-20GHz/40GHz 3-channel output, frequency range: 10MHz-20GHz/40GHz 4-channel output, frequency range: 10MHz-20GHz/40GHz 5-channel output, frequency range: 10MHz-20GHz/40GHz 6-channel output, frequency range: 10MHz-20GHz/40GHz 7-channel output, frequency range: 10MHz-20GHz/40GHz 8-channel output, frequency range: 10MHz-20GHz/40GHz
Example: S1134T-224: 3CH output, t channels are 10MHz-20GHz, 1 channel is 10MHz-40GHz. S1134Q-2222: 4CH output, all channels are 10MHz-20GHz.
Note: Information will conduct the necessary updates, the contents of this document are subject to change without notice
