WF294586AAG Country Gray Solid Platform Full Bed with Oak Top
Product Information: Full Bed
This product is a full bed made in Malaysia that comes with
assembly instructions. The bed includes upper and lower slats
support, headboard (HB) slats, lower slats support for HB, HB
pillar – L and R, HB support rail, top panel, FB slats, lower slats
support for FB, FB pillar – L and R, bed side rail, center support
rail, center support leg, bed slats, wood dowel M8x30MM, U bracket,
screw M3.5x16MM, minifix + cap, iron plate, bed bracket – 2L2R FL
FR, hex nut, spring washer, spanner, bolt, allen key M5, screw M4 x
32MM.
The bed requires a screwdriver for assembly and the hardware
list includes 16 wood dowel M8x30MM, 2 U bracket, 44 screw
M3.5x16MM, 8 sets of minifix + cap, 4 iron plate, 4 bed bracket –
2L2R FL FR, 10 hex nut, 10 spring washer, 1 spanner, 8 bolt, 1
allen key M5, and 20 screw M4 x 32MM.
Product Usage Instructions
Step 1: Attachment of Wood Dowel and Brackets
- Attach wood dowel M8 x30 MM (A) to Upper Slats Support (1),
Lower Slats Support – HB (3), HB Support Rail (5) and Lower Slats
Support – FB (9). - Attach U Bracket (B), Iron Plate (E), and Bed Bracket (F) to
parts (4,5,6,9,10,11,12) accordingly using Screw M3.5 x 16MM
(C). - Attach Minifix (D) to Top Panel (7).
Step 2: Headboard Assembly
- Slot in HB slats (2) to Upper Slats Support (1), then slot the
Lower Slats Support – HB (3) in. - Attach the connected parts and HB Support Rail (5) to HB Pillar
– L (4) and lock with Hex Nut (G) and Spring Washer (H) using
Spanner (I) provided. - Attach the connected parts again to HB Pillar – R (6) and lock
with Hex Nut (G) and Spring Washer (H) using Spanner (I)
provided. - Finally, connect Top Panel (7) to the Headboard and lock with
Minifix Cap (D2).
ASSEMBLY INSTRUCTIONS Item No : WF294586AAG Description : FULL BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside carton during shipment.
PAGE 1 OF 7
WF294586AAG
MADE IN MALAYSIA
ASSEMBLY INSTRUCTIONS Item No : WF294586AAG Description : FULL BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside carton during shipment.
7
6
1
2
4
3
5 13
14 15
12
14 10
12
7 11
1 8
9
TOOLS REQUIRED (Not provided) Screwdriver
Hardware List
No.
Description
Sketch
A Wood Dowel M8x30MM
B U Bracket
C Screw M3.5 x 16MM
D Minifix + Cap
D1 D2
E Iron Plate
F Bed Bracket – 2L2R FL FR
G Hex Nut
H Spring Washer
I Spanner
J Bolt
K Allen Key M5
L Screw M4 x 32MM
Quantity 16PCS 2PCS 44PCS 8SETS 4PCS 4PCS 10PCS 10PCS
1PC 8PCS 1PC 20PCS
PAGE 2 OF 7
Part List
No.
Description
1 Upper Slats Support
2 HB Slats
3 Lower Slats Support – HB
4 HB Pillar – L
5 HB Support Rail
6 HB Pillar – R
7 Top Panel
8 FB Slats
9 Lower Slats Support – FB
10 FB Pillar – L
11 FB Pillar – R
12 Bed Side Rail
13 Center Support Rail
14 Center Support Leg
15 Bed Slats
Sketch
Quantity 2PCS 12PCS 1PC 1PC 1PC 1PC 2PCS 12PCS 1PC 1PC 1PC 2PCS 1PC 2PCS 10PCS
MADE IN MALAYSIA
ASSEMBLY INSTRUCTIONS Item No : WF294586AAG Description : FULL BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside carton during shipment.
Step 1 : Attach Wood Dowel M8 x30 MM (A) to Upper Slats Support (1), Lower Slats Support – HB (3), HB Support Rail (5) and Lower Slats Support – FB (9). Attach U Bracket (B), Iron Plate (E), and Bed Bracket (F) to parts (4,5,6,9,10,11,12) accordingly using Screw M3.5 x 16MM (C). Attach Minifix (D) to Top Panel (7).
A
14
A
1
14
1
A A
A A
3
A
13
A
C x 4
A
A
5B
C x 4
A
A A
9B
7 D1 x 4
4 C x 4
E
C x 4
E
A 6
C x 4
A A
7 D1 x 4
C x 5 F-L
E 11
C x 4
C x 5 F-L
E
12
10
C x 5
12
F-R C x 5
F-R
C
C C
C
B
PAGE 3 OF 7
CCC C E
C CC
CC F-R
A Wood Dowel M8x30MM
16PCS
B U Bracket
2PCS
C Screw M3.5x16MM
44PCS
D Minifix E Iron Plate F Bed Bracket – 2L2R
D1 FL FR
8PCS 4PCS 4PCS
MADE IN MALAYSIA
ASSEMBLY INSTRUCTIONS Item No : WF294586AAG Description : FULL BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside carton during shipment.
Step 2 :Headboard (HB) assembly. First slot in HB slats (2) to Upper Slats Support (1), then slot the Lower Slats Support – HB (3) in. Attach the connected parts and HB Support Rail (5) to HB Pillar – L (4) and lock with Hex Nut (G) and Spring Washer (H) using Spanner (I) provided. Attach the connected parts again to HB Pillar – R (6) and lock with Hex Nut (G) and Spring Washer (H) using Spanner (I) provided. Finally, connect Top Panel (7) to the Headboard and lock with Minifix Cap (D2)
2 1
7
Lock Minifix cap clockwise
D2
D2
D2
D2
3
4 GH
GH GH
5
PAGE 4 OF 7
GH I
HG
G H HG 6
HG
I
G Hex Nut H Spring Washer I Spanner D Minifix Cap
6PCS
6PCS
1PC
D2
4PCS
MADE IN MALAYSIA
ASSEMBLY INSTRUCTIONS Item No : WF294586AAG Description : FULL BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside carton during shipment.
Step 3 :Footboard (FB) assembly. First slot in FB slats (8) to Upper Slats Support (1), then slot the Lower Slats Support – FB (9) in. Attach the connected parts to FB Pillar – L (10) and lock with Hex Nut (G) and Spring Washer (H) using Spanner (I) provided. Attach the connected parts again to FB Pillar – R (11) and lock with Hex Nut (G) and Spring Washer (H) using Spanner (I) provided. Finally, connect Top Panel (7) to the Footboard and lock with Minifix Cap (D2)
8 1
7
D2 D2
Lock Minifix cap clockwise
D2 D2
9
PAGE 5 OF 7
10 GH
H G
GH I
HG HG
11
G Hex Nut H Spring Washer I Spanner D Minifix Cap
HG
I
4PCS
4PCS
1PC
D2
4PCS
MADE IN MALAYSIA
ASSEMBLY INSTRUCTIONS Item No : WF294586AAG Description : FULL BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside carton during shipment.
Step 4 : Connect Bed Side Rails (12) to Headboard and Footboard with Bolt (J) using Allen Key M5 (K)
J Insert the Bolt. Do not J tighten the bolt yet, leave
at least 5MM gap.
K
12
Lock Bed Bracket to Bolt Tighten the Bolt
12
Step 5 : Attach the Center Support Rail (13)(14) to the bed.
J Bolt K Allen Key M5
8PCS 1PC
13 14
14
PAGE 6 OF 7
Slot Center Rail (13)(14) into EP Bracket MADE IN MALAYSIA
ASSEMBLY INSTRUCTIONS Item No : WF294586AAG Description : FULL BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside carton during shipment.
Step 6 : Attach Bed Slats (15) to the bed using Screw M4 x 32MM (L).
L
15
Completed assembly.
L Screw M4 x 32MM
20PCS
PAGE 7 OF 7
