US28000 Core EZ Drilling

Product Information

The Core EZ is a portable coring system designed for drilling
anchor holes and mounting core bits. It features a W24-230 9 Metabo
Grinder as its motor and has a capacity to hold 3 to 10 core bits
(not included). The system operates on 115V electrical requirements
with a minimum of 15 amps. The dimensions of the system are 24 x 17
x 11 inches, and it weighs 65 lbs.

The Core EZ stands out from other coring systems with its unique
features:

1. Centrally mounted guide shaft for easy centering of the
   core
2. The system securely holds the core during drilling
3. Reduced drag allows for higher drilling speed and less operator
   fatigue
4. Designed for use in tight spaces
5. Comes as a complete kit for convenient setup and usage

Product Usage Instructions

Step 1: Mark Center of Core & Drill Anchor Hole

1. Mark the center of the desired core location.
2. Drill an anchor hole at the marked center using an appropriate
   drill bit.

Step 2: Anchor Pin & Mount Guide Post

1. Insert the anchor pin into the anchor hole.
2. Mount the guide post onto the anchor pin, ensuring a secure
   fit.

Step 3: Mount Core Bit Assembly

1. Attach the hex core bit tube to the grinder coupling.
2. Slide the assembled core bit onto the guide post, aligning it
   with the anchor pin.

Step 4: Mount Gearbox

1. Attach the gearbox to the grinder coupling.
2. Ensure a secure connection between the gearbox and the core bit
   assembly.

Items included with your Core EZ kit:

• Grinder
• Grinder Coupling*
• Gearbox
• Carry Case
• Guide Post
• Water Feed Hex Core Bit Tube
• Adapter
• Anchor

*Factory Installed

Note: For horizontal drilling, vertical &
angled drilling, and confined space drilling, follow the same steps
mentioned above.

FEATURED ACCESSORIES

CORE EZ – CORE DRILLING

Bit Selection Guide

*Speciality sizes available

Description
3″ x .165 Core Bit 4″ x .165 Core Bit 5″ x .165 Core Bit 6″ x .165 Core Bit 7″ x .165 Core Bit 8″ x .165 Core Bit 10″ x .165 Core Bit 3/8″-16 x 5″ Anchors 10″ Toggle Bolt

Other Accessories

Part Number
CBB0300M CBB0400M CBB0500M CBB0600M CBB0700M CBB0800M CBB1000M US28210 US27538

Extendable Core Bit Angle Drilling Washer Slurry Ring

Ask about our Continental Tubing Extendable Core Bits
Available sizes: 3″ – 6″
Part Number: Depends on Bit Size

Special washers for

Slurry water for

drilling at an angle clean coring removal

Part Number: US28273 Part Number: US28261 – 6inch US28263 – 10inch

Water Tank Kits
3.5 gallon manual water pump.
Part Number: US27810-1 5 gallon battery powered pump.
Part Number: US27815

1-866-987-7297 | www.ussaws.com

3702 W. Central Avenue Santa Ana, CA 92704 Phone 714 434 7297 Fax 714 434 7299

8004B E. Broadway Ave Tampa, FL 33619
Phone 813 621 8015 Fax 813 621 7125

1-866-987-7297
ussaws.com

PORTABLE CORING SYSTEM

Features · Lightweight · Easy and fast set-up and
break-down · No measuring off-sets · Won’t damage surfaces · Unit holds the core once
drilling is complete · All equipment fits in one
case

Deluxe Package Includes
· Grinder · Grinder Coupling*
Guide Post · Water Feed Tube · Hex Core Bit Adapter · Gearbox · Carry Case

Other Required
Equipment · Water Supply · Core Bit · 3/8″ Masonry Drill
Bit · Hammer Drill · 3/8″ Wedge Anchor

Specifications

Part Number

US28000

Capacity

3″ – 10″ Core Bits (not included)

Electrical Requirements 115V (minimum 15 amps)

Motor

W24-230 9″ Metabo Grinder

Dimensions

24″ x 17″ x 11″

Weight

65 lbs

WHAT SETS THE CORE EZ APART?

Step 1: Mark Center of Core & Drill Anchor Hole

Step 2: Anchor Pin & Mount Guide Post

Step 3: Mount Core Bit Assembly

Step 4: Mount Gearbox

Items included with your Core EZ kit:
Grinder Grinder Coupling*

Gearbox Carry Case

Guide Post Water Feed Hex Core Bit

Tube

Adapter

Anchor

*Factory Installed

1. Centrally mounted guide shaft (no offsets to measure) 2. The system holds the core 3. Reduced drag allows higher speed and less load on the operator 4. Designed for tight spaces 5. One simple kit

HORIZONTAL DRILLING

VERTICAL & ANGLED DRILLING CONFINED SPACE DRILLING
