CHD2529 Parkington 24 Inch Three Light Bath Bar
Product Information
The product is the Parkington 24 Three Light Bath Bar, item #
CHD2529. It is a light fixture that consists of three lights and is
suitable for use in bathrooms.
The fixture is available in two shade options:
- Glass Shade
- Metal Shade
Please note that bulbs are not included with the fixture.
Product Usage Instructions
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Locate the mounting plate (B) and remove it from the fixture by
unscrewing the screws (D). - Install the mounting plate (B) to the junction box and securely
fasten it using the provided mounting screws (C). - Wrap the fixture ground wire (bare copper) around the green
grounding screw on the junction box and tighten it. - Connect the black wires from the fixture to the black wires in
the junction box, and secure them with wire connectors. - Connect the white wires from the fixture to the white wires in
the junction box, and secure them with wire connectors. - If applicable, connect any additional wires according to the
manufacturer’s instructions. - Attach the glass or metal shades to the fixture, following the
specific instructions provided for each shade type. - If necessary, install the included bulbs into the fixture.
- Inspect the installed fixture and ensure that all connections
are secure. - Turn on the power to the junction box and test the fixture to
confirm proper operation.
Important Notice: This light fixture should be
installed in accordance with all applicable local installation
codes and by a person familiar with its construction and operation,
as well as the associated hazards. Before installation, carefully
inspect the item and its contents. If any damage or defect is
found, do not proceed with the installation. Retain all packaging
material until the installation is complete and approved.
Product Care Instructions
To clean the fixture, use only a soft dry cloth or feather
duster. Avoid using abrasive or chemical agents that may damage the
surface.
Important: The product is listed and suitable
for use in the US.
ASSEMBLY INSTRUCTIONS
A
BC
D
E
Diagram 1
F
Glass Shade
Metal Shade
Bulbs not included
Parkington 24″ Three Light Bath Bar
Item # CHD2529
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (B) from fixture by removing screws (D). 3. Install mounting plate (B) to the junction box and secure with
mounting screws (C). 4. Wrap fixture ground wire (bare copper) around the green grounding
screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (A). NOTE: It is imperative that the fixture is grounded. 5. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (A). 6. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections. 7. Make sure all wire connections are tight, then carefully tuck into the junction box. 8. Install fixture to mounting plate (B) by securing with screws (D). 9. Remove thumbscrews (E) from fixture, then install shades (F) to fixture body and secure with thumbscrews (E). NOTE: Do not over-tighten otherwise glass could become damaged. 10. Install light bulbs into the sockets.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
M
L IST ED
US
LED
