LEDJ335 Artisan 1000 WW Fresnel
Product Information
The Artisan 1000 WW Fresnel is a stage lighting fixture with a
100W warm white COB LED. It is designed for use in schools,
churches, and stages, providing an ideal replacement for tungsten
fixtures. The beam angle is manually adjustable, and all other
features can be controlled through the 4-button menu and OLED
display or by DMX. The fixture also has a USB socket on the back
panel for optional W-DMX compatible transceiver, allowing for
wireless master/slave or DMX control.
Technical Specifications
- Power Consumption: 105W
- Power Supply: 100~240V, 50/60Hz
- Fuse: T3A 250V
- Noise Level: 55dBA @ 2m
- Dimensions: 300 x 300 x 304mm
- Weight: 4.1kg
- Order Code: LEDJ335
Features
- 100W warm white COB LED
- Manually adjustable beam angle
- Controlled via 4-button menu and OLED display or DMX
- Optional W-DMX compatible transceiver for wireless control
Included Accessories
- 1 x Barn doors
- 1 x Filter frame
- 1 x Power cable
Product Usage Instructions
Before using the Artisan 1000 WW Fresnel, please read the user
manual carefully for your own safety and to prevent any damage to
the equipment.
- Ensure that the equipment is kept away from rain, moisture, and
liquids. - Take care when using the equipment as it operates at high
voltage and there is a risk of electric shock. - Do not modify the equipment without authorization, as this may
result in damages for which the manufacturer will not accept
liability. - Operate the equipment only as described in the user manual to
avoid damage and to maintain the warranty. - These fixtures are intended for stage lighting and
entertainment applications only. They should not be used for
extended periods or for house-light, industrial, or architectural
applications. Use short duty cycles.
To operate the Artisan 1000 WW Fresnel:
- Connect the power supply to the PowerCON input.
- Adjust the zoom using the zoom adjustment feature (01).
- Use the hanging bracket (02) and carry handle (03) for
installation and transportation. - Release and replace filters using the filter frame release
mechanism (04). - Adjust the hanging bracket using the adjustable knobs
(05). - Control the features through the function buttons (06) or via
DMX using the 5-Pin DMX input (07) and output (08). - View information and settings on the LED display (09).
- For wireless control, use the Wireless DMX USB input (10).
- In case of any issues or to restore factory settings, refer to
the appropriate menu options on the display.
Artisan 1000 WW Fresnel
User Manual
Order code: LEDJ335
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP!
· Before your initial start-up, please make sure that there is no damage caused during transportation. · Should there be any damage, consult your dealer and do not use the equipment. · To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual. · Please note that damages caused by user modifications to this equipment are not subject to warranty.
CAUTION!
KEEP THIS EQUIPMENT AWAY FROM RAIN, MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorised modification to the equipment.
· Never let the power cable come into contact with other cables. Handle the power cable and all mains voltage connections with particular caution!
· Never remove warning or informative labels from the unit. · Do not open the equipment and do not modify the unit. · Do not connect this equipment to a dimmer pack. · Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life. · Only use the equipment indoors.
· If the equipment has been exposed to drastic temperature fluctuation (e.g. after transportation), do not connect power or switch it on immediately. The arising condensation might damage the equipment. Leave the equipment switched off until it has reached room temperature.
· If your product fails to function correctly, stop use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Pro Light dealer for service.
· Do not expose to flammable sources, liquids or gases.
· Only use fuses of same type and rating.
· Always disconnect the power from the mains when equipment is not in use or before cleaning! Only handle the power-cable by the plug. Never pull out the plug by pulling the power-cable.
· Make sure that the available mains supply voltage is between 100~240V AC, 50/60Hz.
· Make sure that the power cable is never crimped or damaged. Check the equipment and the power cable periodically.
· If the equipment is dropped or damaged, disconnect the mains power supply immediately and have a qualified engineer inspect the equipment before operating again.
· Repairs, servicing and power connection must only be carried out by a qualified technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
· This lighting fixture is for professional use only – it is not designed for or suitable for household use. The product must be installed by a qualified technician in accordance with local territory regulations. The safety of the installation is the responsibility of the installer. The fixture presents risks of severe injury or death due to fire hazards, electric shock and falls.
· Warning! Risk Group 2 LED product according to EN 62471. Do not view the light output with optical instruments or any device that may concentrate the beam.
OPERATING DETERMINATIONS
· WARRANTY: One year from date of purchase.
If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and/or property.
Please note: These fixtures are intended for stage lighting and entertainment applications only, and are not intended for extended periods of use, including but not limited to house-light, industrial or architectural applications and should only be operated with short duty cycles.
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 2
Product overview & technical specifications
Artisan 1000 WW Fresnel
The Artisan 1000 WW Fresnel with a 100W warm white COB LED is ideal for schools, churches and stages and making it an ideal replacement for tungsten fixtures. The beam angle is manually adjustable, with all other features being controllable via the 4 button menu and OLED display or by DMX. The USB socket on the back panel allows for an optional W-DMX compatible transceiver, further expanding the fixtures versatility with wireless master/slave or DMX control.
· 1 x 100W warm white (3200K) COB LED (WW) · Manually adjustable beam angle: 15°- 45° · 15° – 7,011 Lux @ 2m (full on), 45° – 1,768 Lux @ 2m (full on) · Refresh rate: 1.2kHz, 2.4kHz, 4kHz, 6kHz or 10kHz selectable · DMX channels: 1/2 or 4 selectable · Artisan Series W-DMX USB compatibility for wireless master/slave
or DMX control · Artisan Series W-DMX USB can be used to receive wireless
DMX and relay the DMX signal via the XLR output · 0-100% dimming · 4 dimming curves: Linear, square law,
inverse square law and S-curve · Variable strobe · 4 push button menu with OLED display · PowerCON input/output · 5-Pin XLR input/output · Temperature controlled fan for whisper quiet operation · Handle on rear panel · Filter frame and barn doors included
Specifications Power consumption Power supply Fuse Noise Level Dimensions Weight Order code
Artisan 1000 WW Fresnel 105W 100~240V, 50/60Hz T3A 250V 55dBA @ 2m 300 x 300 x 304mm 4.1kg LEDJ335
15° – Lux 28044 45° – Lux 7072
7011 1768
3116 786
1753 442
1122 282
15° 45°
0m
1m
2m
3m
4m
5m
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 3
300mm
Technical specifications
300mm 195mm
150mm
304mm 40mm
185mm 165mm
340mm
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 4
Technical specifications
04
01
05
05
02
03 09
06
07 08
MENU ENTER UP DOWN
W-DMX USB PORT
Artisan 1000 WW Fresnel
www.prolight.co.uk
5-PIN DMX INPUT
FUSE: T3A 250V
POWER INPUT
POWER CONSUMPTION: 105W 100-240V~50/60Hz
5-PIN DMX OUTPUT
POWER OUTPUT
10 11 12 13
01 – Zoom adjustment 02 – Hanging bracket 03 – Carry handle 04 – Filter frame release mechanism 05 – Hanging bracket adjustable knobs 06 – Function buttons 07 – 5-Pin DMX input
www.prolight.co.uk
08 – 5-Pin DMX output 09 – LED display 10 – Wireless DMX USB input 11 – Fuse: T3A 250V 12 – PowerCON input 13 – PowerCON output
In the box: 1 x fixture, 1 x barn doors, 1 x filter frame & 1 x power cable
Artisan 1000 WW Fresnel User Manual 5
Operating instructions
Main Menu DMX Settings
Personality
Manual Information
Sub Menu DMX Address DMX Channel Mode
No DMX Status
Primary Secondary LED Refresh Dim Modes
Dim Curve
Wireless
Display
Factory Restore White Strobe Master Dimmer LED Temperature Software Version Fixture Hours
Options/Values (Default Settings in BOLD) 001-509
Secondary Options/Values (Default Settings in BOLD)
1CH
2CH
4CH
Hold Last
Blackout
Manual Settings
ON/OFF
ON/OFF
1200hz, 2400hz, 4000hz, 6000hz, 10000hz
LED
HALOGEN
Linear
Square
Inv.Squa
S.Curve
ON/OFF
Saver Delay
OFF, 1-10 seconds
Menu Lock
OFF – 30 seconds, 2-10 minutes
Rotate Display 180°
YES/NO
YES/NO
000-255
000-255
000-255
xxx F/ xxx C
x.xx
xxxxxH
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 6
1 channel mode:
Channel Value Function 1 000-255 Master Dimmer (0-100%)
2 channel mode:
Channel Value Function 1 000-255 Master Dimmer (0-100%) 000-015 No Function 2 016-255 Strobe effect (slow to fast)
Operating instructions
4 channel mode:
Channel Value Function 1 000-255 Master Dimmer (0-100%) 000-015 No Function 2 016-255 Strobe effect (slow to fast) 000-020 Default to Unit settings 021-040 Linear LED 041-060 Square LED 061-080 Inv. Squa LED 081-100 S. Curve LED 3 101-120 Linear Halogen 121-140 Square Halogen 141-160 Inv. Squa Halogen 161-180 S. Curve Halogen 181-255 Default to Unit Settings Refresh Rates 000-020 Default to Unit Settings 021-040 1200hz 041-060 2400hz 4 061-080 4000hz 081-100 6000hz 101-120 10000hz 121-255 Default to Unit Settings
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 7
Operating instructions
Wireless operation: To operate the fixture wirelessly you will need to plug in the Artisan Series W-DMX Compatible Transceiver (sold separately) into the USB port on the rear of the fixture. W-DMX should also be set to “ON” in the fixtures settings (this can be found on page 6). If using it in wireless DMX mode a compatible wireless DMX Transmitter (e.g. Wireless Solutions Sweden W-DMX Micro F-1 Lite G5 Transceiver) will need to be connected. The Artisan Series W-DMX Compatible Transceiver features 2 operating protocols as listed below. The LED on the side of the dongle will illuminate a different colour for each operating protocol. W-DMX G3 Transmit Protocol – Blue (when transmitting) W-DMX Receive Protocol – Green (when receiving) To set the dongle in one of these modes plug the Artisan Series W-DMX Compatible Transceiver into the USB port on the rear of the fixture. Press the button on the dongle whilst powering on the unit. The LED will illuminate white for a brief moment and then change colour. You can then press the button which will scroll through the operating protocols. Once you have selected the chosen protocol, press and hold the button on the dongle for 3 seconds. The LED will illuminate white, then turn blue (transmit mode) or stay white (receive mode). The unit is now set in your chosen protocol.
W-DMX G3 Transmit Protocol: Once in this protocol the LED will illuminate blue. This indicates the fixture is ready to pair with the receiver(s). Once all the receiver(s) have been set up press the button on the dongle once and the LED will flash blue quickly, this indicates it is attempting to pair with the receivers. Once pairing is complete the LED will illuminate static blue to indicate the fixture is transmitting signal. To disconnect the transmitting fixture from all receiving fixtures within range when connected, hold the button on the transmitting fixtures dongle down for 3 seconds until the LED illuminates red. This indicates the wireless memory has been cleared.
W-DMX Receive Protocol: Once in this protocol the LED will illuminate white. This indicates a connection has not yet been established with the transmitter. Once the transmitter has been set up press the button on the transmitter fixtures dongle once or press the pair button on your wireless transceiver. The LED on the receiving units will flash green quickly, this indicates it is attempting to pair with the transmitter. Once pairing is complete the LED will illuminate static green to indicate the fixture is receiving signal. To disconnect the transmitting fixture from all receiving fixtures within range when connected, hold the button on the transmitting fixtures dongle down for 3 seconds until the LED illuminates white. This indicates the wireless memory has been cleared. If the indicator on the receiving units flashes red quickly this indicates that the signal from the transmitting fixture has been lost.
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 8
DMX setup
Setting the DMX address: The DMX mode enables the use of a universal DMX controller. Each fixture requires a “start address” from 1- 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the start address. For example, a fixture that occupies or uses 7 channels of DMX and was addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103, 104, 105 and 106. Choose a start address so that the channels used do not overlap. E.g. the next unit in the chain starts at 107.
DMX 512: DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent fixtures and controllers. A DMX controller sends DMX data instructions form the controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most controllers only have a data “out” terminal).
DMX linking: DMX is a language allowing all makes and models of different manufactures to be linked together and operate from a single controller, as long as all fixtures and the controller are DMX compliant. To ensure proper DMX data transmission, when using several DMX fixtures try to use the shortest cable path possible. The order in which fixtures are connected in a DMX line does not influence the DMX addressing. For example; a fixture assigned to a DMX address of 1 may be placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a fixture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit, no matter where it is located in the DMX chain.
DATA cable (DMX cable) requirements (for DMX operation): This fixture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit. Your unit requires either a standard 3-pin or 5-pin XLR connector for data input/output, see images below.
Further DMX cables can be purchased from all good sound and lighting suppliers or Prolight Concepts dealers. Please quote: 3-Pin: CABL10 2m CABL11 5m CABL12 10m
5-Pin: CABL185 2m CABL187 5m CABL188 10m
Also remember that DMX cable must be daisy chained and cannot be split.
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 9
DMX setup
Notice:
Be sure to follow the diagrams below when making your own cables. Do not connect the cables shield conductor to the ground lug or allow the shield conductor to come in contact with the XLRs outer casing. Grounding the shield could cause a short circuit and erratic behaviour.
Pin Configuration
3-Pin
5-Pin
Pin 1 – Ground
Pin 2 – Negative
Pin 3 – Positive
Pin 4 – N/C
Pin 5 – N/C
DMX 512 3-Pin XLR output
1 3
2
GROUND DMX + DMX
DMX 512 3-Pin XLR input
1 3
2
3-Pin XLR male
3-Pin XLR female
1 ground 3 hot
2 cold
2 cold
1 ground 3 hot
DMX 512 5-Pin XLR output
DMX 512 5-Pin XLR input
GROUND
12
DMX
21
3
DMX + 3
54
N/C
45
N/C
5-Pin XLR male
5-Pin XLR female
1 ground 2 cold
3 hot
5 N/C 4 N/C
5 N/C 4 N/C
3 hot
1 ground 2 cold
Line termination:
When longer runs of cable are used, you may need to use a terminator on the last unit to avoid erratic behaviour.
Using a cable terminator will decrease the possibilities of erratic behaviour. (3-pin – Order ref: CABL90, 5-pin – Order ref: CABL89)
3-Pin
12 3
Termination reduces signal transmission problems and
interference. It is always advisable to connect a DMX
terminal, (resistance 120 Ohm 1/4W) between pin 2 (DMX-) and pin 3 (DMX+) of
the last fixture.
5-Pin
15 24
3
5-pin XLR DMX connectors:
Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-pin XLR fixtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be used. The diagram below details the correct cable conversion.
5-pin XLR (female) Pin 1: GND (screen) Pin 2: Signal (-) Pin 3: Signal (+) Pin 4: N/C Pin 5: N/C
3-pin XLR (male) Pin 1: GND (screen) Pin 2: Signal (-) Pin 3: Signal (+)
3-pin XLR (female) Pin 1: GND (screen) Pin 2: Signal (-) Pin 3: Signal (+)
5-pin XLR (male) Pin 1: GND (screen) Pin 2: Signal (-) Pin 3: Signal (+) Pin 4: N/C Pin 5: N/C
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 10
Multiple fixture power linking
Power linking: This fixture provides power linking via the power output on the rear allowing multiple units to be connected together. The maximum number of fixtures that can be connected is 14 fixtures @ 240V or 7 fixtures @ 120V (including the first fixture). After the maximum number of fixtures are connected a new power run will need to be started. Please note: Caution should be used when power linking other fixtures to the Artisan 1000 WW Fresnel as the power consumption of other fixtures will vary. Fixtures fitted with lamps often require 2/3 times more current on startup, these may require their own power source.
POWER CONSUMPTION: 105W 100-240V~50/60Hz
POWER CONSUMPTION: 105W 100-240V~50/60Hz
MENU ENTER UP DOWN
W-DMX USB PORT
Artisan 1000 WW Fresnel
www.prolight.co.uk
5-PIN DMX INPUT
FUSE: T3A 250V
POWER INPUT
5-PIN DMX OUTPUT
POWER OUTPUT
MENU ENTER UP DOWN
W-DMX USB PORT
Artisan 1000 WW Fresnel
www.prolight.co.uk
5-PIN DMX INPUT
FUSE: T3A 250V
POWER INPUT
5-PIN DMX OUTPUT
POWER OUTPUT
www.prolight.co.uk
Artisan 1000 WW Fresnel User Manual 11
WEEE notice
Correct Disposal of this Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.
