CWM20 Parts Washer
Product Information: Parts Washer
The CLARKE Parts Washer Model No: CWM20, Part No: 7630925 is
designed for cleaning smaller automotive and machinery components
in a garage or workshop setting. The maximum pump capacity is 90
L/hour, and the tank capacity is 60 L / 16 Gal. The weight carrying
capacity of the washer is 50 Kg. The dimensions of the washer when
the lid is closed are 985 x 540 x 930 mm and when it is open are
985 x 540 x 1410 mm. The product comes with a 12-month guarantee
against faulty manufacture from the date of purchase.
Features:
- 230V, 1ph, 50Hz motor
- Maximum pump capacity of 90 L/hour
- Tank capacity of 60 L / 16 Gal
- Weight carrying capacity of 50 Kg
- Dimensions (L x W x H) when lid is closed: 985 x 540 x 930
mm - Dimensions (L x W x H) when lid is open: 985 x 540 x 1410
mm - Weighs 33 kg
- 12-month guarantee against faulty manufacture from the date of
purchase
Safety Precautions:
It is important to follow these safety precautions to ensure
safe usage of the Parts Washer:
- Read the operating manual to understand the machine’s
applications, limitations, and specific potential hazards. - Wear suitable protective clothing, gloves, and goggles
manufactured according to the latest European Safety
Standards. - Clean off any accidental splashes of degreaser on the skin and
seek medical attention if necessary. - Follow degreaser manufacturer’s instructions carefully.
- Check for damage before using the washer and ensure that any
damaged part is properly repaired or replaced. - Disconnect the washer from the power supply before carrying out
any maintenance. - Keep the work area clean and mop up accidental spillages of
degreaser immediately. - Ensure adequate lighting is available with a minimum intensity
of 300 lux to avoid working in your own shadow. - Keep children and visitors away from the work area, especially
while operating the machine. - Maintain the washer in top condition and keep it clean for the
best and safest performance. - Ensure the switch is off before plugging into mains to avoid
accidental starting.
Product Usage Instructions:
Follow these instructions to use the Parts Washer:
- Read the operating manual thoroughly before using the
product. - Wear suitable protective clothing, gloves, and goggles
manufactured according to the latest European Safety
Standards. - Check for damage before using the washer and ensure that any
damaged part is properly repaired or replaced. - Disconnect the washer from the power supply before carrying out
any maintenance. - Keep the work area clean and mop up accidental spillages of
degreaser immediately. - Ensure adequate lighting is available with a minimum intensity
of 300 lux to avoid working in your own shadow. - Keep children and visitors away from the work area, especially
while operating the machine. - Add degreaser to the tank as per manufacturer’s instructions.
Do not overfill the tank. - Place the components to be cleaned in the tank.
- Close the lid and switch on the power supply.
- Allow the components to be cleaned for the recommended time
period as per the degreaser manufacturer’s instructions. - Switch off the power supply and open the lid.
- Remove the components from the tank and dry them thoroughly
before use.
PARTS WASHER
MODEL NO: CWM20
PART NO: 7630925
ASSEMBLY & MAINTENANCE INSTRUCTIONS
ORIGINAL INSTRUCTIONS
DL0822 – Rev 5
INTRODUCTION
Thank you for selecting this CLARKE Parts Washer. The CWM20 is ideal for garage/workshop use when cleaning smaller automotive and machinery components. Before using the product, be sure to read these instructions thoroughly. In doing so you will ensure the safety of yourself and of others around you, and you can look forward to the product giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for its intended purpose. Faulty goods should be returned to their place of purchase, no product can be returned to us without prior permission. This guarantee does not effect your statutory rights.
SPECIFICATIONS & FEATURES
Motor: Maximum Pump Capacity Tank Capacity Weigh carrying capacity Dimensions (L x W x H)
Weight:
230V, 1ph, 50Hz 90 L/hour 60 L / 16 Gal 50 Kg 985 x 540 x 930 mm (Lid Closed) 985 x 540 x 1410 mm (Lid Open) 33 kg
· Accepts all common degreasing fluids. · Fusible link automatically closes lid in case of fire. · Easy maintenance solvent pump. · Built-in replacable filter · Easy maintenance solvent pump
2
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
SAFETY PRECAUTIONS
WARNING: AS WITH ALL EQUIPMENT, THERE ARE CERTAIN HAZARDS INVOLVED WITH ITS OPERATION AND USE. EXERCISING RESPECT AND CAUTION WILL CONSIDERABLY LESSEN THE RISK OF PERSONAL INJURY. HOWEVER, IF NORMAL SAFETY PRECAUTIONS ARE OVERLOOKED OR IGNORED, PERSONAL INJURY TO THE OPERATOR OR DAMAGE TO PROPERTY MAY RESULT.
1. ALWAYS learn the machine’s applications, limitations and the specific potential hazards peculiar to it. Read and become familiar with the entire operating manual.
2. ALWAYS wear suitable protective clothing, gloves and goggles, manufactured to the latest European Safety Standards. Everyday eye glasses are not safety glasses.
3. ALWAYS clean off any accidental splashes of degreaser on the skin. Seek medical attention immediately if necessary.
4. ALWAYS follow degreaser manufacturer’s instructions carefully.
5. ALWAYS check for damage before using the washer. Any damaged part, should be checked to ensure that it will operate properly and perform its intended function. Any damage should be properly repaired or the part replaced. If in doubt, DO NOT use. Consult your local CLARKE dealer.
6. ALWAYS disconnect the washer from the power supply before carrying out any maintenance.
7. ALWAYS keep the work area clean. Cluttered areas and benches invite accidents. Mop up accidental spillages of degreaser immediately.
8. ALWAYS ensure that adequate lighting is available. A minimum intensity of 300 lux should be provided. Ensure that lighting is placed so that you will not be working in your own shadow.
9. ALWAYS keep children away. All visitors should be kept a safe distance from the work area, especially whilst operating the machine.
10. ALWAYS maintain in top condition. Keep the washer clean for the best and safest performance.
11. ALWAYS ensure the switch is off before plugging in to mains. Avoid accidental starting.
12. ALWAYS concentrate on the job in hand, no matter how trivial it may seem. Be aware that accidents are caused by carelessness due to familiarity.
13. ALWAYS keep your proper footing and balance at all times don’t over reach. For best footing, wear rubber soled footwear. keep floor clear.
3
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
ELECTRICAL CONNECTIONS
WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY.
Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. Connecting it to any other power source may cause damage.
This product may be fitted with a non-rewireable plug. If it is necessary to change the fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or damaged, the plug must not be used until a suitable replacement is obtained.
If the plug has to be changed because it is not suitable for your socket, or due to damage, it should be cut off and a replacement fitted, following the wiring instructions shown below. The old plug must be disposed of safely, as insertion into a mains socket
could cause an electrical hazard.
If the colours of the wires in the power cable of this product do not correspond with the markings on the terminals of your plug, proceed as follows.
· The Blue wire must be connected to the terminal marked N or coloured Black.
· The Brown wire must be connected to the terminal marked L or coloured Red.
· The Yellow and Green wire must be connected to the terminal marked E or or coloured Green.
Plug must be BS1363/A approved.
Earth
(Green and Yellow)
Always fit a 3 Amp fuse.
Neutral
(Blue)
Live
(Brown)
Ensure that the outer sheath of the cable is firmly held by the clamp
We strongly recommend that this machine is connected to the mains supply via a Residual Current Device (RCD).
If in doubt, consult a qualified electrician. DO NOT attempt any repairs yourself
4
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
ASSEMBLY
1. Choose a firm, flat and level surface to site the parts washer on, in a well ventilated area and away from any naked flames.
2. Loosely bolt the supporting brackets to the side bars. · Do not tighten at this stage.
3. Bolt the tank loosely to the supporting brackets on each side bar.
4. Loosely bolt the middle (draining) and lower trays to the side bars.
5. Finally tighten all bolts evenly across the whole assembly until secure.
5
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
6. Fit the castors to the side bars.
7. Fit the drain valve as shown.
8. Slide the oil tank into position. 9. Rest the part tray into position.
6
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
OPERATION
1. Open the tank lid and fill the tank with a nonflammable degreaser or cleaning agent, such as Clarke’s degreaser, to just below the level of the parts shelf. DO NOT fill with flammable solvents such as paraffin, thinners, etc.
2. Insert the mains plug into a suitable mains outlet. 3. Using the On/Off button, switch the pump on. Hold the part to be cleaned
under the flexible nozzle and slowly rotate the part until the part is clean. 4. When clean, leave the part to drain on draining tray until dry. 5. Switch off the pump, close the lid and disconnect the power supply. 6. Remove gloves and goggles and store safely.
NOTE: To prevent an accident, any spillages should be mopped up immediately.
IMPORTANT
1. The lid stay incorporates a safety device in the form of a thermally activated safety link, which closes the lid in the event of fire. The link is nonresetting and must be replaced in the event of it operating.
2. Do not allow the level of liquid in the parts washer to fall below the pump inlet, as damage to the pump can result.
ENVIRONMENTAL PROTECTION
Never throw away used oil with domestic refuse or flush it down a sink or drain. Collect any oil in a leak proof container & take it to your waste disposal site. Through purchase of this product, the customer is taking on the obligation to deal with the WEEE in accordance with the WEEE regulations in relation to the treatment, recycling, recovery & environmentally sound disposal of the WEEE. In effect, this means that this product must not be disposed of with general household waste but according to the laws governing Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal facility. Do not dispose of this product or damaged components with general household waste. All tools, accessories and packaging should be sorted, taken to a recycling centre and disposed of appropriately.
7
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
CLEANING AND MAINTENANCE
DRAINING THE TANK
1. Open the drain valve on the underside of the tank. · The liquid will drain onto the draining tray below and into the oil tank for disposal. Make sure that the oil tank does not over fill.
CHANGING THE FILTER
1. Lift out the parts shelf.
2. Slide the filter holder up from the pump as shown.
3. Remove the filter from the holder and replace.
4. Refit the filter holder. Caution: Do not use the parts washer without the filter in place.
8
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
PARTS DIAGRAM
9
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
PARTS LIST
No Description 1 Castor 2 Hex bolt M8 x 40 3 Flat washer M8 4 Side post 5 Parts shelf 6 Support bracket (lefthand) 7 Nut M8 8 Tank 9 Tank lid 10 Fusible link 11 Bolt M8 x 15 12 Draining tray 13 Lower Tray 14 Oil tank 15 Power cable 16 Cable gland 17 Switch box 18 Screw M4 x 10 19 Flat washer M4 20 On/Off switch
No Description 21 Wire guard 22 Nut M4 23 Spring washer 24 Flange (wire) 25 Support bracket (righthand) 26 Flexible nozzle 27 Pump housing cover 28 Filter cover 29 Filter 30 Pump assembly 31 Pump housing 32 Sealing ring 33 Spigot 34 Sealing ring 35 Nut M5 36 Flat washer 37 Screw M5 x 20 38 Drain valve 39 Spring washer
CONSUMABLES
This parts washer is suitable for use with Clarke water-based parts washer fluid; Concentrated; P/No: 3051063 (5 Litre) P/No: 3051065 (25 Litre) – or Ready to Use; P/No: 3051064 (5 Ltr) P/No: 3051066 (30 Ltr) These products are non-flammable and bio-degradable. We do not recommend the use of solvent-based parts washer fluids such as P/Nos: 3051115 and 3051120 with this parts washer.
10
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
DECLARATION OF CONFORMITY
11
