1 PHOENIX CONTACT 1310928 DIN Rail Mounting

PHOENIX CONTACT 1310928 DIN Rail Mounting

Housing set – UM-PRO-KIT-B72-L100-7035 – 1310928
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user’s documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)

Profile housing (PA), mounting type: DIN rail mounting, color: light gray (7035), dimensions on the DIN rail: width: 103.8 mm, height: 92.3 mm, depth: 39.45 mm, incl. 2 lateral elements (PA), color: black (9005), for PCBs with width: 72 mm, length: 100 mm, PCB surface: 5650 mm²

Key Commercial Data

Packing unit	1 pc
GTIN
GTIN	4063151570224
Custom tariff number	39169010

Technical data

Product properties

Brief article description	Housing set
Type	UM-PRO-KIT-B72-L100-7035
Item no.	1310928
Housing type	Profile housing
Housing series	UM-PRO
Type	incl. 2 lateral elements
Mounting type	DIN rail mounting

Dimensions

Width	103.8 mm
Height	92.3 mm
Depth	39.45 mm
Depth from top edge of DIN rail	32.45 mm

PCB specifications

Number of PCB holders	3
Dimensions	72 mm x 100 mm (PCB dimensions)

Technical data
PCB specifications

PCB surface, maximum	5650 mm²
PCB thickness	1.4 mm…. 1.8 mm
Mounting position	parallel to the DIN rail
Type of PCB mount	Insertion/securing with additional elements

Material specifications – Profile

Material	PA
Color (RAL)	light gray (7035)
Flammability rating according to UL 94	V0

Material specifications – Lateral elements

Material	PA
Color (RAL)	black (9005)
Flammability rating according to UL 94	V0

Ambient conditions

Ambient temperature (storage/transport)	-40 °C … 55 °C
Ambient temperature (assembly)	-5 °C … 100 °C
Ambient temperature (operation)	-40 °C … 105 °C (depending on power dissipation)
Relative humidity (storage/transport)	80 %

General information
