BEGAS5800 Garden Shredder
Product Information
The product is a mains-powered appliance with the model number
BEGAS5800. The product manual is available in English and contains
information on intended use, safety instructions, training,
preparation, and residual risks.
Intended Use
The intended use of the product is described in the manual. Any
accessory or attachment or operation with this appliance other than
those recommended in this instruction manual may present a risk of
personal injury.
Safety Instructions
Basic safety precautions should always be followed when using
the product to reduce the risk of fire, electric shock, personal
injury, and material damage. The instructions in the manual should
be read carefully before using the appliance. Children or people
unfamiliar with these instructions should not use the machine.
Local regulations can restrict the age of the operator. The
operator or user is responsible for accidents or hazards occurring
to other people or their property.
Training
The instructions should be read carefully to be familiar with
the controls and the proper use of the appliance. The machine
should not be operated while people, especially children, or pets
are nearby.
Preparation
The appliance should only be operated in open space and on a
firm, level surface. It should not be operated in bad weather
conditions especially when there is a risk of lightning. Safety
glasses should be worn at all times while operating the appliance.
Hearing protection should be worn whenever the sound level seems
uncomfortable. Loose clothing or jewellery should not be worn as
these can be caught in moving parts.
Safety of Others
The appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children should not
play with the appliance. Cleaning and user maintenance should not
be made by children without supervision.
Residual Risks
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These risks
can arise from misuse, prolonged use etc. Even with the application
of the relevant safety regulations and the implementation of safety
devices, certain residual risks can not be avoided. These include
injuries caused by touching any moving parts, hot parts, or when
changing any parts or accessories. Injuries caused by prolonged use
of the appliance and impairment of hearing and health hazards
caused by breathing can also occur.
Product Usage Instructions
To use the product safely and effectively, follow the below
instructions:
- Read all instructions carefully before using the
appliance. - Use the product only for its intended purpose as described in
the manual. - Do not use any accessory or attachment or perform any operation
with this appliance other than those recommended in this
instruction manual as it may present a risk of personal
injury. - Familiarize yourself with the controls and proper use of the
appliance before operating it. - Do not allow children or people unfamiliar with these
instructions to use the machine. Local regulations can restrict the
age of the operator. - Never operate the machine while people, especially children, or
pets are nearby. - Operate the appliance only in open space and on a firm, level
surface. - Avoid using the machine in bad weather conditions especially
when there is a risk of lightning. - Wear safety glasses at all times while operating the
appliance. - Hearing protection should be worn whenever the sound level
seems uncomfortable. - Do not wear loose clothing or jewellery, as these can be caught
in moving parts. - If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard. Replace damaged or unreadable
labels. - The operator or user is responsible for accidents or hazards
occurring to other people or their property. - Ensure that children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge have been given supervision or instruction
concerning use of the appliance in a safe way and understand the
hazards involved before allowing them to use the appliance. - Do not allow children to play with the appliance. Cleaning and
user maintenance should not be made by children without
supervision. - Be aware of residual risks that may arise when using the tool
which may not be included in the enclosed safety warnings. - Injuries caused by touching any moving parts, hot parts, or
when changing any parts or accessories can occur. Injuries caused
by prolonged use of the appliance and impairment of hearing and
health hazards caused by breathing can also occur.
84
1 3
2
7
5 6
www.blackanddecker.co.uk
BEGAS5800
ENGLISH
(Original instructions)
15 13 12
11 9
14
16
10
A
17
18
5
6
B
C
2
8
1
3
D
E
2
(Original instructions)
ENGLISH
u Retain this manual for future reference.
7
F
Intended use
Your BLACK+DECKERTM garden shredder BEGAS5800 has been designed for shredding most kitchen and garden waste, including prunings, hedge trimmings, twigs and other organic garden waste as well as paper and cardboard. The shredded waste is ideal for composting purposes or to obtain a smaller volume of waste for easy disposal. This garden shredder is intended for consumer use only. It is intended for intermittent use: the recommended material feed time is 40% of the total run time of the shredder. Selecting and picking up the material will normally provide a sufficient idle time.
Safety instructions
Warning! When using mains-powered appliances, basic safety precautions, including the following, should always be followed to reduce the risk of fire, electric shock, personal injury. u Read all of this manual carefully before
using the appliance and material damage. u The intended use is described in this manual. The use of any accessory or attachment or the performance of any operation with this appliance other than those recommended in this instruction manual may present a risk of personal injury.
Training
u Read the instructions carefully. Be familiar with the controls and the proper use of the appliance.
u Never allow children or people unfamiliar with these instructions to use the machine. Local regulations can restrict the age of the operator.
u Never operate the machine while people, especially children, or pets are nearby.
u Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people or their property.
Preparation
u Do not operate this equipment in the vicinity of bystanders.
u Only operate the appliance in open space (e.g. not close to a wall or other fixed objects) and on a firm, level surface.
u Avoid using the machine in bad weather conditions especially when there is a risk of lightning
u Wear safety glasses at all times while operating the appliance.
u Hearing protection should be worn whenever the sound level seems uncomfortable.
u Do not wear loose clothing or jewellery, as these can be caught in moving parts.
3
ENGLISH
(Original instructions)
Preferably wear rubber gloves and non-slip footwear when working outdoors. Wear protective hair covering to keep long hair out of the way. u Always wear long trousers when using this equipment. u Do not expose the appliance to rain. Do not use the appliance where there is a risk of causing fire or explosion, e.g. in the presence of flammable liquids and gases. u Do not operate the appliance on a paved or gravel surface where ejected material could cause injury. u To prevent damage to the cutting gear, remove earth from roots. Do not attempt to shred bones, stone, glass, metal, plastics or rags. u Before use, carefully check the appliance and mains cable for damage. Check for misalignment and seizure of moving parts, breakage of parts, damage to guards and switches and any other conditions that may affect its operation. Ensure that the appliance will operate properly and perform its intended function. Do not use the appliance if any part is damaged or defective. Do not use the appliance if the switch does not turn it on and off. u Have any damaged or defective parts repaired or replaced by an authorised repair agent. Never attempt any repairs yourself.
4
u If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. Replace damaged or unreadable labels.
Safety of others
u This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
u Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
Residual risks
Additional residual risks may arise when using the tool which may not be included in the enclosed safety warnings. These risks can arise from misuse, prolonged use etc. Even with the application of the relevant safety regulations and the implementation of safety devices, certain residual risks can not be avoided. These include: u Injuries caused by touching any
moving parts. u Injuries caused by touching any hot
parts. u Injuries caused when changing any
parts or accessories.
(Original instructions)
ENGLISH
u Injuries caused by prolonged use of the appliance. When using any appliance for prolonged periods ensure you take regular breaks.
u Impairment of hearing. u Health hazards caused by breathing
dust developed when using your tool (example:- working with wood, especially oak, beech and MDF.) u If operating the mower in a damp location is unavoidable, use a residual current device (RCD) with a tripping current of not more than 30 mA. Use of an RCD reduces the risk of electric shock. u Never pick up or carry an appliance while the motor is running.
Guard against electric shock
u The appliance must be connected to a socket or extension cable containing an earth connection.
u Electric safety can be further improved by using a high-sensitivity (30 mA / 30 mS) residual current device (RCD).
u Your appliance is designed for use on AC (mains) electrical supplies only. Do not attempt to use it on any other supply.
Extension cables
u When using the appliance outdoors, only use extension cables intended for outdoor use.
u Up to 25 m 1.5 mm2 3-core extension cable can be used without loss of power.
u Always keep extension cords away from moving hazardous parts to avoid damages to the cords which can lead to contact with live parts.
Operation
u Before starting the appliance, look into the feeding chamber to make certain that it is empty.
u Keep your face and body away from the feed intake opening, long branches may lash out when being pulled in by the cutting gear. Do not allow hands or any other part of the body or clothing inside the feeding chamber, discharge chute, or near any moving part.
u Keep proper balance and footing at all times. Do not overreach. Never stand at a higher level than the base of the appliance when feeding material into it.
u Always stand clear of the discharge zone when operating this appliance.
u When feeding material into the appliance be extremely careful that pieces of metal, rocks, bottles, cans or other foreign objects are not included.
u If the cutting mechanism strikes any foreign objects or if the appliance starts making any unusual noise or vibration, turn the appliance off, remove the plug from the mains and allow the appliance to stop. u Inspect the appliance for damage. u Check for and tighten any loose parts. u Have any damaged parts replaced or repaired with original parts by an authorised repair agent.
5
ENGLISH
(Original instructions)
u Do not allow processed material to build up in the discharge zone; this may prevent proper discharge and can result in kickback of material through the feed intake opening.
u If the appliance becomes clogged, turn the appliance off, remove the plug from the mains and allow the appliance to stop before clearing debris.
u Keep all guards and deflectors in place and in good working condition.
u Do not transport or tilt the appliance whilst in operation.
u Do not leave the appliance unattended. Whenever you leave the work area, turn the appliance off, remove the plug from the mains and allow the appliance to stop. Children must be supervised to ensure they do not play with the appliance.
u Do not tilt the appliance while the power source is running.
u Always disconnect the supply: u before clearing a blockage; u before checking, cleaning or working on the machine; u after striking a foreign object to inspect the machine for damage; u if the machine starts to vibrate abnormally;
Maintenance and storage
u When the appliance is stopped for servicing, inspection, or storage, or to change an accessory, turn the appliance off and remove the plug from the mains.
Make sure that all moving parts have come to a complete stop before making any inspections, adjustments, etc. u Store the appliance in a dry and locked location. Children should not have access to stored appliances.
Labels on appliance
The following pictograms are shown on the tool along with the date code:
Warning! Read the manual prior to operation.
Danger – rotating blades. Keep hands and feet out of openings.
Do not use the tool in wet conditions or expose it to rain.
Wear safety glasses or goggles when operating this appliance. Wear suitable ear protectors when operating this appliance.
Always remove the plug from the socket before cleaning or maintenance. Be careful not to use your appliance if the cable is damaged. Disconnect the mains plug if > the cord becomes damaged or entangled. Wait until completely stopped before touching. Beware of flying objects. Keep bystanders away from the cutting area.
6
Wear gloves when operating this tool.
Do not use as a step.
Directive 2000/14/EC guaranteed sound power.
Electrical safety
Warning! This tool is double insulated; therefore no earth wire is required. Always check that the power supply corresponds to the voltage on the rating plate. u If the supply cord is damaged, it must be replaced by the manufacturer or an authorised BLACK+DECKER Service Centre in order to avoid a hazard. u Electric safety can be further improved by using a high sensitivity 30 mA Residual Current Device (RCD).
Features
This appliance includes some or all of the following features. 1. On/off switch 2. Direction selector 3. Overload protection button 4. Funnel 5. Stand 6. Collection bin 7. Adjustment knob 8. Plunger
Assembly
Warning! Before assembly, make sure that the appliance is switched off and unplugged.
Attaching the wheels to the stand (Fig. A) u Slide the sleeve (13) into the wheel (12). u Slide the wheel shaft (11) into the sleeve (13) and wheel
(12).
(Original instructions)
ENGLISH
u Slide the wheel shaft (11) into the washer (14) and insert into the stand (5).
u Secure the wheel shaft (11) into the stand with the screw (15).
u Secure the wheel (12) onto the wheel shaft with the spring clip (10).
u Secure the foot (16) onto the stand (5) using the screws (17).
u Repeat the above assembly on the revese side.
Attaching the motor unit to the stand (Fig. B) u Align the holes on the motor unit with the corresponding
holes on the stand (5). u Insert the screws (18) through motor unit and into the
stand.
Fitting the collection bin (Fig. C) u Slide the collection bin (6) into the stand (5) ensuring that
the safety switch locks securely. Note: The unit will not operate unless the safety switch is engaged.
Use Warning! Let the tool work at its own pace. Do not overload. u Do not switch the appliance off before it is completely
empty, as it may clog and be difficult to restart. u Remove soil and stones from plant roots before shredding. u Firmly hold branches when feeding them into the
shredder. u Use the plunger (8) when required to feed material into the
shredder as shown in figure E.
Switching on and off (Fig. D)
Switching on u Set the direction selector (2) to left position. u Press the I button of the on/off switch.
Switching off u Press the O button of the on/off switch. Warning! Do not operate the direction selector/switches in sequence using abrupt motions. Sudden switching may generate current spikes potentially damaging the shredder.
Clearing a blockage If the appliance becomes jammed by branches which are too thick or hard, or foreign bodies, the shredder will most of the time release itself automatically. The rotating direction will automatically reverse thereby releasing the material back through the top. To return the rotation back to normal, proceed as follows: u Switch off and wait until the cutting blade has stopped
completely. u Switch on again with the appliance set to forward rotation.
7
ENGLISH
(Original instructions)
When the material is jammed: u Switch the appliance off. u Set the direction selector (2) to the right position. u Press the I button until the blockage is removed. Warning! Branches may be ejected from the inlet funnel when the appliance is running in reverse. If the blockage has not cleared: u Switch off and unplug the appliance. u Use a piece of wood or the plunger (8) to loosen the
debris within the cutting chamber. u Replace the plug in the mains socket and operate the
appliance as described above to remove any debris. Warning! Always switch off and unplug the appliance when removing a blockage. Do not attempt to remove blockages by hand through the inlet funnel or outlet opening. Keep your hands clear of the cutting chamber.
Adjusting the cutter plate (Fig. F) The cutter plate needs to be adjusted if the appliance fails to shred material. u Turn the adjustment knob (7) clockwise half a turn into the
cutting position to cut through light material completely. u Turn the adjustment knob counter-clockwise half a turn
into the crushing position to shred heavy materials. The materials may need to be put through the appliance twice to crush the material before cutting it completely. u Make sure the cutting blade does not touch the anvil blade to avoid damage to the appliance. When the shredded material starts to hang like a chain, adjust as follows: u Switch the appliance on. u Turn very slowly and slightly the adjustment knob (7) clockwise until you hear a light grinding sound or a small amount of aluminium shavings will fall out of the discharge chute. The shredded material will now be separated. Warning! Ensure the appliance is switched on and working in normal forward direction. Adjusting the cutter plate while the appliance is switched off can lead to serious damage of the appliance.
Overload protection
This appliance has an overload protection. If the appliance becomes blocked and the motor stalls, the power will automatically be switched off. u Wait for about 5 minutes for the protection to reset. u Disconnect the appliance from the mains supply. u Clear the blockage as described above. u Connect the appliance to the mains supply. u Press the overload protection button (3). u Switch the appliance on.
Hints for optimum use
u Shred dry materials last, as this will help to clear moist material from the shredder.
8
u Do not allow material to pile up and compost prior to shredding.
u You may feed shreddings into the shredder for a second time to further reduce their volume.
u Refer to the chart at the end of this text.
Maintenance
Your BLACK+DECKER corded/cordless appliance/tool has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool/appliance care and regular cleaning. Warning! Before performing any maintenance on corded/ cordless power tools: u Switch off and unplug the appliance/tool. u Regularly clean the ventilation slots in your tool/appliance
and charger using a soft brush or dry cloth. u Regularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
Mains plug replacement (U.K. & Ireland only)
If a new mains plug needs to be fitted: u Safely dispose of the old plug. u Connect the brown lead to the live terminal in the new
plug. u Connect the blue lead to the neutral terminal. Warning! No connection is to be made to the earth terminal. Follow the fitting instructions supplied with good quality plugs. Recommended fuse: 5 A.
Protecting the environment
Separate collection. Products and batteries
Z marked with this symbol must not be disposed of with normal household waste. Products and batteries contain materials that can be recovered or recycled, reducing demand for raw materials. Please recycle electrical products and batteries according to local provisions. Further information is available at www.2helpU.com
Technical data
Voltage
V
Frequency
Hz
Power input
W
No-load speed (blade) /min
No-load speed (motor) /min
Max cutting diameter mm
Weight
Kg
BEGAS5800 230 – 240 50 2800 46 2850 45 29.6
(Original instructions)
ENGLISH
EC declaration of conformity
MACHINERY DIRECTIVE OUTDOOR NOISE DIRECTIVE
Please visit our website www.blackanddecker.co.uk to register your new Black & Decker product and receive updates on new products and special offers.
%
BEGAS5800 Shredder
Black & Decker declares that these products described under “technical data” are in compliance with:
2006/42/EC, EN 60335-1:2012 + A11:2014, EN 50434:2014
2000/14/EC, Shredder, Annex V, Level of sound power according to 2000/14/EC
(Article 13): Sound power level: LWA: 93,0 dB(A), K=1,7 dB(A) The guaranteed sound power level, LWA: 95 dB(A). These products also comply with directive 2014/30/EU,
2011/65/EU. For more information, please contact Black & Decker at the
following address or refer to the back of the manual.
The undersigned is responsible for compilation of the technical file and makes this declaration on behalf of Black & Decker.
R. Laverick Director of Engineering Black & Decker Europe, 210 Bath Road, Slough,
Berkshire, SL1 3YD United Kingdom 24/09/2018
Guarantee
Black & Decker is confident of the quality of its products and offers consumers a 24 month guarantee from the date of purchase. This guarantee is in addition to and in no way prejudices your statutory rights. The guarantee is valid within the territories of the Member States of the European Union and the European Free Trade Area.
To claim on the guarantee, the claim must be in accordance with Black & Decker Terms and Conditions and you will need to submit proof of purchase to the seller or an authorised repair agent. Terms and conditions of the Black & Decker 2 year guarantee and the location of your nearest authorised repair agent can be obtained on the Internet at www.2helpU. com, or by contacting your local Black & Decker office at the address indicated in this manual.
9
10
11
Australia
New Zealand
United Kingdom & Republic Of Ireland www.blackanddecker.co.uk [email protected]
Black & Decker (Australia) Pty. Ltd. 20 Fletcher Road, Mooroolbark, Victoria, 3138
Black & Decker 5 Te Apunga Place Mt Wellington Aukland 1060
Black & Decker 210 Bath Road Slough, Berkshire SL1 3YD
Tel.
03-8720 5100
Fax
03-9727 5940
Tel.
+64 9 259 1133
Fax
+64 9 259 1122
Tel.
01753 511234
Fax
01753 512365
N642596 REV-0
11/2018
2helpU
Power Tools | Garden Tools | Household Products | BLACK+DECKER
