Joyor A5 Electric Scooter Instruction Manual

A5 Electric Scooter

Product Information

  • Model: G1
  • Battery: 36V7.8Ah
  • Range: 20-25km
  • Max. Speed: 30km/h
  • Motor: 500W
  • Frame Material: Aluminum Alloy
  • Brake: Rear Drum Brake
  • Shock Absorber: Front and Rear
  • Tires: 9-inch Solid Tire
  • Max. Load: 120kg
  • Charging Hour: 3.5-4h
  • Open Size: 1120*560*1245mm
  • Folding Size: 1050*180*440mm
  • Net Weight: 16.5kg
  • Gross Weight: 19.7kg
  • Package Size: 1100*235*440mm

Product Usage Instructions

  1. Before using the G1 electric scooter, make sure the battery is
    fully charged for a minimum of 3.5-4 hours.
  2. To turn on the electric scooter, press and hold the power
    button located on the handlebar until the display screen lights
    up.
  3. To accelerate, twist the right handlebar grip towards you. To
    brake, squeeze the left handlebar lever.
  4. The G1 electric scooter has a maximum speed of 30km/h and a
    range of 20-25km. Be sure to observe local traffic laws and
    regulations while riding.
  5. When not in use, the G1 electric scooter can be folded down to
    a compact size for easy storage and transportation. To fold, loosen
    the locking mechanism near the base of the stem and fold the
    handlebars down towards the deck. Secure the stem with the locking
    mechanism to keep it folded.
  6. When riding the G1 electric scooter, it is recommended to wear
    appropriate safety gear such as a helmet, elbow pads, knee pads,
    and closed-toe shoes.
  7. Regularly check the tire pressure and brakes to ensure they are
    in good working condition. If any issues are observed, contact a
    qualified technician for repairs.
  8. The G1 electric scooter is designed to carry a maximum load of
    120kg. Do not exceed this weight limit as it may cause damage to
    the scooter or compromise safety.

C
Es

Model

G1

Batter y

36V7.8Ah

Ra nge

20-25km

Max.Speed

30km/h

Motor

500W

Fra me Material Brake

Shockabsorber-Front

Shock absorber-Rear

lires

Max.Load

120kg

Charging hour 3.5-4h

Open Size

Folding Size N.Weight G.Weight

16.5kg 19.7kg

Package Size

G3 36Vl3Ah 25-35km 30km/h
500W Alumi nium alloy Rear drumbrake
Yes
Yes 9-inchSolid tire
120kg 6.5-7h
1120*560*1245mm 1050*180*440mm
17.05kg 20.25kg
1100*235*440mm

65 48Vl3Ah 45-55km 36km/h 600W
120kg 6.5-7h
17.8kg 21.0kg

JOYOR
