DE0004 Type-C Converter HDMI Adapter

Product Information

The Type-C to HDMI/USB-Ax3/Type-C PD is a versatile adapter that
allows you to connect your Type-C enabled device to an HDMI
display, as well as providing additional USB-A ports and Type-C PD
charging capabilities. It supports DP1.2 Alt mode and HDMI max
4K/30Hz resolution. The adapter also supports HDCP 2.3 and HDCP 1.4
for content protection. With three USB-A 3.0 ports, you can connect
multiple peripherals and enjoy high-speed data transfer at a
maximum bandwidth of 5Gbps. The Type-C PD Charging port supports
charging up to 100W (20V/5A) and features Fast Role Swap of PD 3.0,
ensuring uninterrupted power supply even when plugging or
unplugging the adapter.

Features

• Type-C Male x1 (Connect to host)
• HDMI Female x1 (Supports HDMI max 4K/30Hz resolution, HDCP 2.3
  & HDCP 1.4)
• USB-A Female x3 (Supports USB-A 3.0 with a maximum bandwidth of
  5Gbps)
• Type-C Female x1 (for PD Charging, supports up to 100W
  charging, Fast Role Swap of PD 3.0)
• 8W power dedicated to the functioning of the product, remaining
  power (max 92W) used to charge the host

Specifications

Warranty: 1 Year

Environmental:

• Operating Temperature: 0 to +45°C
• Operating Humidity: 10% to 90% RH (no condensation)
• Storage Temperature: -10 to +70°C
• Storage Humidity: 10% to 90% RH (no condensation)

Power Supply: USB-C PD Charging Port (100W, 20V/5A)

Regulatory Approvals: FCC, CE

Certifications: English Version

Package Contents

Main unit x1

User Manual x1

Product Usage Instructions

1. Check the packaging and ensure that you have received the main
   unit and the user manual.
2. Connect the Type-C male connector of the adapter to your host
   device.
3. If you wish to connect an HDMI display, connect the HDMI female
   connector of the adapter to the HDMI input of your display. This
   supports a maximum resolution of 4K at 30Hz and is compatible with
   HDCP 2.3 and HDCP 1.4 for content protection.
4. You can also connect up to three USB-A devices to the adapter
   using the USB-A female connectors. These USB-A ports support USB
   3.0 and offer a maximum bandwidth of 5Gbps for high-speed data
   transfer.
5. If you want to charge your device using the adapter, connect
   the Type-C female connector of the adapter to a power source that
   supports PD charging. The adapter supports PD charging up to 100W
   (20V/5A) and features Fast Role Swap of PD 3.0, ensuring
   uninterrupted power supply even when plugging or unplugging the
   adapter.
6. Make sure the connected host device has sufficient power to
   operate the adapter. The adapter requires 8W for its functioning,
   and the remaining power (up to 92W) will be used to charge the host
   device.

Please refer to the user manual for further instructions and
safety information. Keep the user manual for future reference.

Type-C to HDMI/USB-Ax3/Type-C PD
User Manual
Contents
1.0 INTRODUCTION ……………………………………………………..1 2.0 FEATURES ………………………………………………………………. 1 3.0 SPECIFICATIONS ………………………………………………….. 2 4.0 PACKAGE CONTENTS …………………………………………… 2

DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or using this product. Please keep this manual for future reference.
1.0 INTRODUCTION
This is a Type-C 5-in-1 hub with HDMI, 3 USB-Aand Type-C female port, providing an ideal solution for extending the port of Type-C/Thunderbolt 3 host (PC/Laptop/Mobile phone,etc.), especially for those host with a single Type-C port. Capable of outputting HDMI video up to 4K 30Hz and supporting US B 3.0 data transfer rates up to 5Gbps, 3 USB-A ports allow you to connect 3 USB devices simultaneously. Besides, the Type-C female supports PD 3.0 with max 100W PD Charging. It can work on all Type-C and ThunderboltTM3 host that supports DP Alt mode. When working on Thunderbolt TM 3 host, this product transmits DP signal.
2.0 FEATURES
Upstream: Type-C Malex1(Connect to host) Support DP1.2 Alt mode
Downstream: HDMI Support HDMI max 4K/30Hz Support HDCP 2.3&HDCP1.4
USB-A 3.0 X3 Max 5Gbps bandwidth
Type-C Female x1(for PD Charging) Support PD Charging 100W (20V/5A) Support Fast Role Swap of PD 3.0, the connected device will not

get disconnected while plugging in and out PD Adapter 8W is dedicated to the functioning of this product, the rest power
(max 92W) will be used to charge the Host

3.0 SPECIFICATIONS
Input/Output Connector Input Output
Warranty Limited Warranty Environmental Operating Temperature Operating Humidity Storage Temperature Storage Humidity Power Supply USB-C PD Charging Port Regulatory Approvals Certifications Accessory Adapter User Manual

Type-C Male x1 HDMI Female x1 USB-A Female x3 Type-C female x1PD Charging)
1 Year
0 to +45 10% to 90 % RH (no condensation) -10 to +70 10% to 90 % RH (no condensation)
100W(20V/5A)
FCC,CE
English Version

4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton: Main unit x1 User Manual x1
