Smith Fixture Support Selection Guide For

URINAL SUPPORTS

FIXTURE NUMBER	SIZE	FLOOR MOUNTED WITH BEARING PLATES
2158T-EB	22 X 13	0636 & 0637
WH2158-W-SLPT-EB	24 X 13	0636 & 0637
WH2158-T-EB	22 X 13	0636 & 0637
2159-EB	21 X 14	0636 & 0637

SCRUB SINK SUPPORTS

FIXTURE NUMBER	SIZE	FLOOR MOUNTED WITH BEARING PLATES
4101	23 X 27	0758-M31
4102	63 X 27	0758-(42-M31)
4103	97 X 27	0758-(43-M31)
4111	23 X 30	0848-M31
4112	26 X 60	0849-3-M31
4113	26 X73	0849-3-M31
4114	26 X 90	0849-4-M31
4121ADA	23 3/4 X 36	0849-M31
4122ADA	26 X 72	0849-3-M31
4123ADA	23 3/4 X 108	0849-4-M31
4171	22 X 30	0848-M31
4172	22 X 72	0849-3-M31
4173	22 X 96	0849-4-M31

CORNER LAVATORIES

FIXTURE NUMBER	SIZE	FLOOR MOUNTED WITH BEARING PLATES
WH3741L	29 X 21 3/4	0816
WH3741R	29 X 21 3/4	0816
WH3776L	29 X 21 3/4	0816
WH3776R	29 X 21 3/4	0816
4160	24 X 24	0814

LIGATURE RESISTANT

FIXTURE NUMBER	SIZE	FLOOR MOUNTED WITH BEARING PLATES
WH3778L	29 X 21 3/4	0848
WH3778R	29 X 21 3/4	0848
WHD-BSN	24 X 20	0869-M31

BASIN SUPPORTS

FIXTURE NUMBER	SIZE	FLOOR MOUNTED WITH BEARING PLATES
WH3775	20 X 21	0848 & 0864
WH3740	24 X 13	0805
WH3740BAR	22 X 13	0848-M31

SINK SUPPORTS

FIXTURE NUMBER	SIZE	FLOOR MOUNTED WITH BEARING PLATES
4150	21 X15	0802
4151	25 X 20	0802

WATER CLOSET SUPPORTS

FIXTURE NUMBER	FLOOR MOUNTED
WH2105BAR	0211Y-M54-XK

NOTE: Whitehall numbers specified with various options or suffixes can affect the applicable Smith figure number shown in comparison guide. When suffix options are added, verify fixture support with Smith SE department.
