BOSCH BQ7S0P960T Built-in Set
How To Use
Instructions
| ID | Gas | Nz | Qn (kW) | m3/h | g/h | Z (mm) | Y (mm) | M |
| G20/20 mbar | 72 | 1,10 | 0,105 | – | – | – | B | |
| G20/25 mbar | 65 | 1,10 | 0,105 | – | – | – | B | |
| G25/20 mbar | 79 | 1,10 | 0,122 | – | – | – | B | |
| G25/25 mbar | 78 | 1,10 | 0,122 | – | – | – | B | |
| G25.1/25 mbar | 78 | 1,10 | 0,122 | – | – | – | B | |
| G25.3/25 mbar | 78 | 1,10 | 0,119 | – | – | – | B | |
| G30/29 mbar | 53 | 1,10 | – | 80 | – | – | A | |
| G30/37 mbar | 53 | 1,10 | – | 80 | – | – | A | |
| G30/50 mbar | 48 | 1,10 | – | 80 | – | – | A | |
| G31/37 mbar | 53 | 1,10 | – | 79 | – | – | A | |
| G20/20 mbar | 93 | 1,90 | 0,181 | – | – | – | B | |
| G20/25 mbar | 91 | 1,90 | 0,181 | – | – | – | B | |
| G25/20 mbar | 105 | 1,90 | 0,211 | – | – | – | B | |
| G25/25 mbar | 104 | 1,90 | 0,211 | – | – | – | B | |
| G25.1/25 mbar | 104 | 1,90 | 0,21 | – | – | – | B | |
| G25.3/25 mbar | 104 | 1,90 | 0,21 | – | – | – | B | |
| G30/29 mbar | 70 | 1,90 | – | 138 | – | – | A | |
| G30/37 mbar | 68 | 1,90 | – | 138 | – | – | A | |
| G30/50 mbar | 60 | 1,90 | – | 138 | – | – | A | |
| G31/37 mbar | 70 | 1,90 | – | 136 | – | – | A | |
| G20/20 mbar | 125 | 2,80 | 0,267 | – | – | – | B | |
| G20/25 mbar | 109 | 2,80 | 0,267 | – | – | – | B | |
| G25/20 mbar | 141 | 2,80 | 0,31 | – | – | – | B | |
| G25/25 mbar | 118 | 2,80 | 0,31 | – | – | – | B | |
| G25.1/25 mbar | 118 | 2,80 | 0,31 | – | – | – | B | |
| G25.3/25 mbar | 118 | 2,80 | 0,304 | – | – | – | B | |
| G30/29 mbar | 83 | 2,80 | – | 203 | – | – | A | |
| G30/37 mbar | 82 | 2,80 | – | 203 | – | – | A | |
| G30/50 mbar | 74 | 2,80 | – | 203 | – | – | A | |
| G31/37 mbar | 83 | 2,80 | – | 200 | – | – | A | |
| G20/20 mbar | 1 – 141 2 – 58 | 4,20 | 0,4 | – | 7,5 | open | B | |
| G20/25 mbar | 1 – 132 2 – 54 | 4,20 | 0,4 | – | 3 | 4,5 | B | |
| G25/20 mbar | 1 – 156 2 – 63 | 4,20 | 0,466 | – | 1,5 | 1,5 | B | |
| G25/25 mbar | 1 – 145 2 – 60 | 4,20 | 0,466 | – | 2 | 3 | B | |
| G25.1/25 mbar | 1 – 145 2 – 60 | 4,00 | 0,443 | – | 2 | 3 | B | |
| G25.3/25 mbar | 1 – 145 2 – 60 | 4,20 | 0,455 | – | 2 | 3 | B | |
| G30/29 mbar | 1 – 97 2 – 39 | 4,20 | – | 305 | 8 | open | A | |
| G30/37 mbar | 1 – 88 2 – 37 | 4,20 | – | 305 | 5 | 5 | A | |
| G30/50 mbar | 1 – 82 2 – 35 | 4,20 | – | 305 | 5 | 2 | A | |
| G31/37 mbar | 1 – 97 2 – 39 | 4,20 | – | 300 | 8 | open | A | |
| 29 | ||||||||
