Digitus Dn-3024 Usb Type-c Gigabit Ethernet Adapter User Manual

DN-3024 USB Type-C Gigabit Ethernet Adapter

USB Type-CTM Gigabit Ethernet Adapter

The USB Type-CTM Gigabit Ethernet Adapter is designed to extend
the functionality of your USB Type-CTM laptop by adding a Gigabit
Ethernet connector. It is a plug-and-play device that does not
require any drivers or system settings changes to function.

How to Connect

To use the USB Type-CTM Gigabit Ethernet Adapter, follow these
steps:

  1. Connect the adapter directly to your computer’s USB Type-CTM
    port.
  2. Connect your Cat 5e/6 network cable to a LAN or router.
  3. No external software drivers are needed for this adapter to
    function.
  4. No external power is required as the adapter draws power
    directly from your computer’s USB port.

Supported Systems

The USB Type-CTM Gigabit Ethernet Adapter is compatible with the
following systems:

  • MacBook (USB Type-C) OS X system
  • Windows 11, 10, 8, 7
  • Chromebook Pixel

Product Features

The USB Type-CTM Gigabit Ethernet Adapter has the following
features:

  • LAN adapter with a speed of 10/100/1000Mbps
  • Cable length of 15cm
  • Dimensions of 58x24x16mm
  • Weighs 19.6g
  • Chipset: RTL8153
  • Operating temperature range: 0 to 40 degrees Celsius (35 to 100
    degrees Fahrenheit)
  • Operating humidity range: 20% RH to 80% RH

Package Content

The package includes the following:

  • 1 x USB Type-CTM Gigabit Ethernet Adapter
  • 1 x Instruction manual

Note: The Declaration of Conformity is part of the shipping
content. If it is missing, you can request it by post from the
manufacturer’s address.

USB Type-CTM Gigabit Ethernet Adapter
Manual DN-3024 Rev. 3-0

Description
With the USB Ethernet adaptor you can extend your USB Type-CTM laptop to add a Gigabit Ethernet connector. Thanks to the easy plug-and-play configuration, you don’t have to install drivers or change system settings.
How to connect
Connect the adapter directly to your computer Connect your Cat 5e/6 network cable to a LAN or router No external software drivers needed No external power required

Supported Systems
MacBook (USB Type-C) OS X system Windows 11, 10, 8, 7 Chromebook Pixel

Product Feature
LAN adapter Cable Length: Dimension: Weight: Chipset: Operating Temperature: Operating Humidity:

1x 10/100/1000Mbps 15cm 58x24x16mm 19.6g RTL8153 0 to 40 (35 to 100) 20% RH to 80% RH

Package content
1 x USB Type-CTM Gigabit Ethernet Adapter 1 x Instruction manual

Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is part of the shipping content. If the Declaration of Conformity is missing, you can request it by post under the below mentioned manufacturer address.
www.assmann.com Assmann Electronic GmbH Auf dem Schüffel 3 58513 Lüdenscheid Germany
