HE-15C-24E-US Electric Honey Extractor2-4/4 8frames

Product Information: Electric Honey Extractor

The Electric Honey Extractor is a tool designed to extract honey
from beehives with ease. It is available in two different models –
HE-15C-24E-US and HE-18C-48E-US, both made of 201 stainless steel.
The extractor features a speed regulation range of 0-100r/min and
can hold 2-4 or 4-8 frames depending on the model.

Safety Instructions:

Before operating the Electric Honey Extractor, it is important
to read the user manual carefully. The extractor features automatic
stop when the lid is open and has overload protection to prevent
locked rotor current. Make sure to follow all the safety
instructions mentioned in the user manual.

Assembly and Use:

1. Installation of Support Legs: First, place the barrel on the
   ground and install the three legs by aligning the holes on the
   barrel with the corresponding holes on the legs. Insert screws into
   the holes and tighten them with a screwdriver.
2. Installation of Honey Valve: Erect the barrel and unscrew the
   honey outlet connector. Put the honey outlet at the corresponding
   outlet outside the barrel, put the plastic nut into the barrel,
   connect it with the honey outlet connector, and tighten it.
3. Installation of Honey Extractor Lid: Assemble the two lids with
   screws.
4. Put Beehive Frames: Put the beehive frames with honey into the
   corresponding frames in the barrel.
5. Connect Power Cord: Connect the power cord to the electrical
   port to power up the honey extractor.
6. Turn On Honey Extractor: Turn the key to position 1, power on,
   and adjust the speed control knob to start the honey
   extractor.
7. Automatic Stop: If you open the lid, the motor will stop
   working automatically. And if you close the lid, the motor will
   work normally.
8. Take Out Honey: To take out honey, loosen the screw, hold the
   handle of the honey outlet connector, lift it to open the honey
   outlet, and let the honey flow out.

Troubleshooting Instruction:

For any product questions or technical support, please contact
VEVOR at [email protected]. Please read the user manual
carefully before operating the product.

Support and E-Warranty Certificate https://www.vevor.com/support
Electric Honey Extractor 2-4/4-8frames USER MANUAL
We continue to be committed to provide you tools with competitive price. “Save Half”, “Half Price” or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully when you are placing an order with us if you are actually saving half
in comparison with the top major brands.

Honey Extractor HE-15C-24E-US HE-18C-48E-US HE-15C-24E-US HE-18C-48E-US
NEED HELP? CONTACT US! Have product questions? Need technical support? Please feel free to contact us:
[email protected] This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if
there are any technology or software updates on our product.
-1-

SAFETY INSTRUCTIONS
For your safety and the safety of others, the following precautions must be observed when operating the honey extractor: 1.Make sure the honey extractor is clean before use; 2. The speed of the honey extractor must not be too high or too low. Adjust the speed according to the amount of nectar or usage habits; 3.Connect to the grounding pile to fix the honey extractor; 4.First turn off the switch, then power on the honey extractor, and then adjust the speed knob to control the speed of the honey extractor; WARNING: 1.Turn off the power when not in use. 2.Do not disassemble or change this machine.
MODEL AND PARAMETRS

Model
Voltage/frequency Speed regulation range
Capacity Height from the bottom of the
barrel to the ground Frames
Fit frame size
Main materials

HE-15C-24E-US HE-18C-48E-US
110V-120V~60Hz 0-100r/min
15±1kg/18±1kg 32-40cm(lifting) 2-4/4-8 frames
Large frame: L415mm * W200mm
Small frame: L415mm * W135mm
201 stainless steel

-2-

Automatic stop when open the lid
Locked rotor current (overload protection)

possess 1.404-1.648A

STRUCTURE DIAGAM

1 2 3 4
5 6

-3-

No

Parts name

1

Motor

2

Speed Control Knob

3

Lid

4

Barrel Body

5

Support Leg

6

Honey Valve

ASSEMBLY AND USE
Step 1: Installation of Support Legs.

-4-

First, take out the three legs and place the barrel on the ground. Next, align the holes on the three legs with the corresponding three holes on the barrel, insert screws into the holes, and tighten them with a screwdriver. Step 2: Installation of the Honey Valve.
First, erect the barrel and unscrew the honey outlet connector. Then, put the honey outlet at the corresponding outlet outside the barrel. Finally, put the plastic nut into the barrel, connect it with the honey outlet connector, and tighten it. Step 3: Installation of Honey Extractor Lid.
Assemble the two lids with screws.
-5-

Step 4: Put the beehive frames of different sizes with honey into the corresponding frames in the barrel. Step 5: Connect the power cord to the electrical port to power the honey extractor. Step 6: Turn the key to position 1, power on, and adjust the speed control knob to start the honey extractor.
-6-

Step 7If you open the lid, the motor will stop working automatically. And if you close the lid, the motor will work normally.

Step 8 : Take out the honey

First, loosen the screw. Then hold the handle of the honey outlet connector, lift it to open the honey outlet, and let the honey flow out.

TROUBLESHOOTING INSTRUCTION

Problem

Reason

Solutions

-7-

The motor does not start after the power is turned on
Barrel shaking

The plug is not tightly plugged
in
The switch is not turned to 1
The speed control knob is not adjusted
The frames are not placed symmetrically The feet are
not fixed on the ground

Insert the plug firmly
Turn the switch to 1 Adjust the control knob Place the
frames symmetrically Fix the feet on
the ground

CLEAN,CARE AND STORAGE RULES
Care and cleaning : The honey extractor shall be thoroughly cleaned and dried before use. Especially the one that has not been used for a long time, shall be disassembled and cleaned. Otherwise, the honey stains and other impurities left in the honey shaker will pollute the honey. After using the honey extractor, clean the inner and outer walls of the barrel and its stainless steel frame. And dry them with a clean and dry cloth, use a hair dryer, or let them air dry to keep them clean to prepare for the next use. Storage : Please store it out of the reach of children; After using the honey extractor, place it in a cool place and cover it with a large cloth to prevent dust from entering.
ManufacturerChangge Xinao Bee Industry Co. Ltd
-8-

AddHe Shang Yang Village, Da Zhou Town, Changge City, Xuchang City, Henan Province Made in China
-9-

Support and E-Warranty Certificate https://www.vevor.com/support
