Commercial Ceiling Fan
Product Information
This product is a fan designed to provide high-quality and
cost-effective comfort. It comes with a 5-year limited warranty,
guaranteeing that it is free from defects in workmanship and
material for a period of five years from the date of purchase.
Within the first year, any defective product can be returned to the
retail outlet with proof of purchase for a replacement. For the
remaining four years, the motor windings are covered by the
warranty. If there are any defects in the motor assembly during
this period, the product can be returned to the manufacturer with
proof of purchase and a $20.00 handling and labor charge.
It is important to note that the warranty does not cover damage
caused by accidents, misuse, improper installation, or the affixing
of any accessories. Additionally, changes in finishes such as
rusting, pitting, corroding, tarnishing, or peeling are not covered
due to varying climatic conditions. The warranty will also be void
if there is any alteration, abuse, installation not in accordance
with instructions, or removal of the CSA sticker.
Product Usage Instructions
Before starting the installation process, ensure that the power
is turned off at the main electrical service box. The electrical
connections must comply with local code ordinances, national
electrical codes, CEC, NEC, and ANSI/NFPA 70. If you are not
familiar with wiring, it is recommended to consult a qualified
electrician.
For optimum quietness, fully assemble the fan and let it run for
24 hours.
Here are the tools and materials required for installation:
- Philips Screw Driver
- Step Ladder
- Blade Screw Driver
- Wire Cutters
- Wiring supplies as required by electrical code
Choose an installation site that allows the fan blades to rotate
freely without any obstructions. When mounting the fan on a ceiling
outlet box, use an approved (CSA for Canada and UL for U.S.)
ceiling fan box marked “FOR FAN SUPPORT.” Ensure that the outlet
box is securely installed and capable of supporting the weight of
the fan.
It is important to note that most outlet boxes commonly used for
lighting fixtures may not be acceptable for fan support and may
need to be replaced. If there is any doubt, consult a qualified
electrician.
If you have any questions or concerns, you can contact the
following numbers before returning the product to the store:
1-800-265-1833 (English) / 1-800-567-2513 (French), Monday through
Friday from 8:00 AM to 5:00 PM E.S.T.
Please refer to the original user manual for complete
instructions and safety guidelines.
5 YEAR LIMITED WARRANTY
“Thank you” for purchasing our product. It is our policy to furnish you with high quality
products at a fair price. With proper installation your fan should provide you with years of
money saving comfort.
This fan is guaranteed to be free from defects in workmanship and Material for a period
of five (5) years from date of purchase. Within the first (1) year from date of purchase any
defective product should be returned to your RETAIL OUTLET along with proof of purchase.
For the balance of the warranty, four (4) years, the MOTOR WINDINGS ONLY shall be free
of defects. We will correct such defects or replace the motor assembly at our option if the
product is returned, FREIGHT PREPAID , to us. The returned fan must be accompanied by
your proof of purchase and a cheque for $20.00 for handling and labour charges. All costs of
removing and re-installing the product are YOUR RESPONSIBILITY damage to any part as
such by accident, misuse, improper installation or by affixing any accessories IS NOT covered
by this warranty. As a result of varying climatic conditions in our area this warranty does not
cover any changes in finishes, including rusting, pitting, corroding, tarnishing or peeling.
WARRANTY VOID: In cases of alteration, abuse, installation not in accordance with
instructions or REMOVAL of the CSA Sticker.
11/16
CP-4 NLGT 11 /19
Questions or Concerns Contact At The Following Numbers Before Returning Product To The Store:
1-800-265-1833 (English) / 1-800-567-2513 (French) Monday through Friday 8:00 AM to 5:00 PM E.S.T.
INSTALLATION INSTRUCTIONS
DOWNROD MOUNT SERIES
INSTRUCTIONS PERTAINING TO RISK OF FIRE OR INJURY TO PERSONS READ ALL INSTRUCTIONS
IMPORTANT SAFETY
! INSTRUCTIONS SAVE THESE INSTRUCTIONS INSTALLATION AND WIRING TO BE IN ACCORDANCE WITH CEC, NEC, LOCAL ELECTRICAL CODES and ANSI/NFPA 70. Consult a qualified electrician if you are not familiar with wiring.
TOOLS AND MATERIALS REQUIRED
– Philips Screw Driver – Step Ladder – Blade Screw Driver – Wire Cutters – Wiring supplies as required by electrical code.
NOTE: FOR OPTIMUM QUIETNESS, FULLY ASSEMBLE FAN AND RUN 24 HOURS
2157 Parkedale Ave., Brockville, Ontario K6V 5V6 PH: (613) 342-5424 FX: (613) 342-8437
2555 Rue Bernard Lefebvre Laval, Quebec
H7C 0A5 PH: (450) 665-2535 FX: (450) 665-0910
SAFETY PRECAUTIONS
1. Turn off power at main electrical service box before starting installation. 2. Electrical connections must comply with local code ordinances, national
electrical codes, CEC, NEC and ANSI/NFPA 70. 3. Make sure the installation site you choose allows the fan blades to rotate
freely without any obstructions. 4. When mounting the fan on a ceiling outlet box, Use an approved (CSA for
Canada and UL for U.S.) ceiling fan box marked “FOR FAN SUPPORT”. Ensure the outlet box is securely installed in place such that it is able to support at least the fan weight.
5. WARNING: To reduce the risk of fire, electric shock, or personal injury, mount fan only to an outlet box marked acceptable for fan support and use mounting screws provided with the outlet box. Most outlet boxes commonly used for the support of lighting fixtures are not acceptable for fan support and may need to be replaced. Consult a qualified electrician if in doubt.
6.Total Fan Weight For Reference: 120″approximate 15.0 kgs(33.08lbs).
WARNING
1. To reduce the risk of personal injury DO NOT bend the blade brackets when installing the brackets, balancing the blades or cleaning the fan. Also, DO NOT insert foreign objects in between rotating fan blades.
2. Remove fan from the carton carefully and check for shipping damage. Check blades for bends and dents. In case assistance is required please contact our service centre.
3. Mount with the lowest moving parts at least 3.05 Meters (10 Feet) above floor or grade level.
4. All set screws must be checked and re-tightened where necessary after installation. No lubricants should be used on screws or hooks.
5. To reduce the risk of personal injury install the safety cable (per Fig.1). 6. DO NOT attach blades before hanging the fan.
INSTRUCTIONS
æ ON/OFF the fan ç Short press: ON/OFF the light
Long press(hold for 3 seconds): Dimming è Speed of the fan (ælow speed — êhigh speed) é Direction of the fan (reverse switch) ê Timing control of the fan ë LED indicated light ì 12V battery should be used in emitter
Pg. #2
TROUBLE 1. Fan will not start 2. Fan sounds noisy
3. Fan wobbles or shakes excessively.
TROUBLESHOOTING
SUGGESTIONS
– Check wiring connections to fan. – Check fuses and circuit breakers. – Check wiring connections in switch housing. CAUTION: Turn power off for last two items.
– Check to make sure that all screws in motor housing are snug. – Check to make sure that blade bracket screws are tight. – Check to make sure that wire nuts in switch housing
are not rattling against wall of switch housing. – If fan has a light kit make sure switch housing
screws and set screws are tight. – Some fan motors are sensitive to signals from solid
state variable controls. If solid state controller is used, change to an alternative control. (See a representative for a list of available controls.) – Allow a 24 hour break in period to eliminate most noises.
– Check that all blades are screwed firmly into blade brackets. – Check that blade brackets are secured firmly to motor. – Check distance from tip of blades to ceiling. – Check distance between blade tip to blade tip. All
measurements should be equal. Loosen blade screws and position blade until even then re-tighten. – Check that the downrod hemisphere notch is engaged in canopy – Check to make sure that jam screws in downrod are tightened. . – Make sure canopy and mounting bracket are tightened securely to wooden joist. – Make sure warpage has not occurred in wooden blades. If so, contact the customer service department for replacement parts.
Pg. #11
8. OPTIONAL FEATURE: LIGHT ADAPTABLE
– This fan is light adaptable. Please approach your dealer for the light kit certified for this model.
WARNING: BE SURE TO TURN OFF POWER BEFORE INSTALLING
– Carefully tuck electrical wires back into housing, align housing cover with housing and secure with three housing screws and washers.
Motor
Housing
Fig.10
Housing Screws
Housing Cover Star washer
WARNING: Ensure that all connections, set screws and screws are securely tightened before the next step.
To clean the fixture, turn off the power, wait for it to cool, and wipe the fixture with a clean, soft cloth.
Pg. #10
ASSEMBLY DRAWING
A. Mounting Bracket
B. Canopy
A.
C. Downrod Assembly
D. Yoke Cover
E. Fan Motor Assembly
F. Housing Cover
B.
G. Blade Bracket
H. Remote Control
I. Fan Blade
C.
D. E.
F. G. H.
Pg. #3
I.
Fig.1
1. MOUNTING
A DOWNROD MOUNT
– Take out fan motor housing. – Remove cotter pin and bolt from yoke. – Loosen jam screw in yoke until it is flush with the inside surface. – Obtain downrod, canopy and yoke cover. – Place downrod inside canopy and yoke cover. – Route wires exiting motor through yoke cover, canopy and downrod. – Insert bolt through hole in shaft and downrod. Be careful not to
damage or cut the fan wires. – Tighten flat washer and bolt. Secure with cotter pin through hole in the
end of the bolt. – Secure downrod in position by tightening jam screws. Slide yoke cover
down so it is flush with the motor housing.
Fig.2a Flat
Washer
Jam Screw
Cotter Pin Bolt
Yoke
Fig.2b
Yoke
Jam Screw
Fig.2c
Downrod Canopy
Yoke Cover
Fig.2d
Cotter Pin
Flat Washer
Fig.2e
Jam Screw
Bolt
Motor
Pg. #4
7. MOUNTING BLADES TO MOTOR
– Insert the blade arm into the fan as shown. – Tighten the blade arm to motor with the screw and lock washer as shown. – Slightly turn the blade after installation and repeat the same step for the other blades.
Fig.9a
Fig.9b
Motor Screw & Lock Washer
INSTALLATION
NOTE: All screws must be checked and
retightened where necessary, before and after installation.
Pg. #9
5. ENGAGE HEMISPHERE (Downrod Mount Only)
– Carefully rotate fan assembly until groove in hemisphere locks over tab of canopy assembly.
WARNING: Failure to seat tab in groove could cause damage to electrical wires and possible shock or fire hazard.
(B)
(A)
Washers
(A)
(B)
Hemisphere
Groove
Fig.7a
Downrod
Fig.7b
NOTE: When installing fan on sloped ceiling, make sure tab on hanger bracket faces towards the top of the slope. Depending on the slope, a longer downrod may be required to prevent fan blades from hitting the ceiling.
6. MOUNT BLADE BRACKETS TO BLADES
– Place blade bracket screw through flat washer, fibre washer and blade. – Align with corresponding hole in blade bracket. – Repeat with (2) remaining screws and tighten.
Hex Nut Lock Washer Metal Washer
Blade Bracket
Blade Bracket Screw
Blade
Fig.8
Pg. #8
2. INSTALL MOUNTING BRACKET
WARNING: To Reduce The Risk Of Fire, Electric Shock, Or Personal Injury, Mount To UL/CSA Listed Outlet Box Marked Acceptable for Fan Support And Use Mounting Screws Provided With The Outlet Box.
– Install J-Hook through centre of outlet box and into the wooden joist. – Secure mounting bracket and rubber gaskets to outlet box. – Hang the safety cable onto the J-hook. – Hang fan on temporary hook or mounting bracket.
Wood Joist Outlet Box
J-Hook
J-Hook
Rubber Gasket Mounting Bracket
Ceiling
Fig.3a
Outlet box Screws
(not provided)
Canopy
Safety Cable
Fig.3b
3. ELECTRICAL HOOK-UP – There are several different wiring combinations that can be used in controlling your ceiling fan to meet your specific requirements. Should the following method not meet your requirements call or visit your nearest distributor for a full list of fan accessories.
CAUTION
Green Wire – GROUND
Black Wire (Fan) – POWER White Wire (Fan) – COMMON
SEE SAFETY PRECAUTIONS ON PG. #2 BEFORE WIRING
After making the wire connections, ensure the wires should be spread apart with the grounded conductor and the equipment-grounding conductor on one side of the outlet box and the ungrounded conductor on the other side of the outlet box. Ensure the splices after being made should be turned upward and pushed carefully up into the outlet box.
Pg. #5
3. ELECTRICAL HOOK-UP
A CONNECTING THE (GREEN) GROUND WIRE
DOWNROD MOUNT
Wire nut
– Connect ground wire from outlet box
to green wire from mounting bracket
and downrod using a wire nut
(not supplied).
Fig.4
NOTE: Once ground wires are connected, carefully tuck wires and wire nut into the outlet box making sure that the wires are clear of the hemisphere and downrod when positioned in mounting bracket (Downrod Mount Only).
B CONNECTING BLACK, WHITE, AND (RED OR BLUE) WIRES
Black Wire
– Connect white wire from outlet box to white White Wire wire from fan using wire nut (not supplied).
– Connect black wire from outlet box to black wire from fan using a wire nut (not supplied).
White Wire
Fig.5
NOTE: Once wires are connected, carefully tuck wires and wire nuts into the outlet box making sure that the wires are clear of the hemisphere and downrod when positioned in mounting bracket (Downrod Mount Only).
Pg. #6
3. ELECTRICAL HOOK-UP FUNCTION INSTRUCTION OF EMITTER
– Learning code and matching mode is used between transmitter and receiver.
C – Turn “ON” the supply power. Within 30 seconds, press “FAN ON/OFF” button on the transmitter for 5 seconds.
Transmitter and receiver are connected
after hearing a long “beep”.
– If the transmitter cannot control the fan,
check to ensure all wiring connections
are properly connected according to the
instruction manual. Check to ensure the
batteries are in the right position. Check
whether there are any similar remote
controls in use nearby. Check whether
they work with the same frequency.
– Low voltage of battery will affect the
sensitivity of the transmitter. The indicator light will flash when battery voltage is low.
Fig. 6
Replace the batteries for better performance.
– Take out the batteries from the transmitter when leaving unused for long periods.
of time.
– Ensure to connect the ground wire accordingly.
D INSTALLING THE REMOTE CONTROL WALL BRACKET
If desired, the wall bracket can be installed
to house the remote control.
– Use the screws to secure the wall
Cap
bracket at the desired mounting location.
– Place the remote control into the wall
bracket.
– Mount the cap onto the top of remote control as shown by the 2 screws if
Remote control
necessary.
Screw
Screw
Wall bracket
Fig.6b
4. MOUNTING FAN ASSEMBLY – Place two screws and washers on mounting plate (marked B on diagram) which correspond with slots in canopy. Screw in two turns. – Position canopy to mounting plate aligning slots to screws (marked B on diagram) then turn to lock. – Position and tighten the two screws and washers (marked A on diagram) then tighten the two screws (marked B on diagram). Pg. #7
