256818 AC TrueTone Effect Pedal for Electric Guitar
Product Information
The AC TrueTone is a sound processing device designed for use
with musical instruments that have electromagnetic pickups. It
features various controls and connections to adjust the frequency
response, distortion, and output level of the instrument’s sound.
The device can be powered either by an external power supply or by
batteries.
Important safety instructions should be followed to ensure
proper and safe operation of the product. The device should only be
used for its intended purpose, and any other use may result in
personal injury or property damage. It is essential to keep the
device away from children to prevent choking hazards and to dispose
of plastic bags and packaging properly.
When using the device with an external power supply, it is
crucial to match the input voltage with the voltage rating of the
device and ensure the AC outlet is protected by a residual current
circuit breaker. Failure to do so may lead to damage to the device
and potential harm to the user. Additionally, precautions should be
taken during electrical storms or when the device is not in use for
an extended period.
Inserting batteries correctly is essential to avoid damage to
the device or batteries. Leaking batteries can cause permanent
damage, so it is recommended to remove them if the device will not
be used for a longer period.
Product Usage Instructions
- Connect your instrument to the device using a 1/4 jack cable
into the “IN” jack socket. - If using batteries, ensure proper polarity when inserting them
into the device. - If using an external power supply, connect it to the “DC 9V”
socket on the device. - Adjust the various controls to customize your sound:
- Use the “LOW” control to set the low frequencies.
- Use the “MID” control to set the mid frequencies.
- Use the “HIGH” control to set the high frequencies.
- Use the “LEVEL” control to set the output level.
- Use the “VOICE” control in combination with the “DRIVE” control
to simulate different amplifier sounds.
- The LED indicator will light up when the effects pedal is
active. If the LED is off or dim, it indicates that the battery
needs to be replaced. - Connect the device to an amplifier using a 1/4 jack cable into
the “OUT” jack socket. - To enable or disable the pedal function, use the “TRUE BYPASS”
foot switch.
Remember to refer to the user manual for more detailed
information and safety instructions.
AC TrueTone
Quick Start Guide
This quick start guide contains important information on the safe operation of the product. Read and follow the safety advice and instructions given. Retain the quick start guide for future reference. If you pass the product on to others please include this quick start guide.
EN
Safety instructions
Intended use
This device is intended to be used for sound processing of signals from musical instruments with electromagnetic pickups. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts from the product. They could swallow the pieces and choke! Never let children unattended use electrical devices.
External power supply
The device is powered by an external power supply. Before connecting the external power supply, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly the user. Unplug the external power supply before electrical storms occur and when the device is unused for long periods of time to reduce the risk of electric shock or fire.
Risk of fire due to incorrect polarity
Incorrectly inserted batteries may destroy the device or the batteries. Ensure that proper polarity is observed when inserting batteries.
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period.
Where to use the product
Never use the product · in conditions of extreme temperature or humidity · in extremely dusty or dirty areas · at locations where the unit can become wet
General handling
· To prevent damage, never use force when handling the product. · Never immerse the product in water. Just wipe it with a clean dry cloth. Do not use
liquid cleaners such as benzene, thinners or flammable cleaning agents.
Features
· Effects pedal for electric guitars · Overdrive · Analogue · Level, Voice and Drive controls
· Low, Mid and High 3-band-EQ controls · Power supply via 9-V block battery (not included, item no. 417473) or power
adapter (not included, item no. 409939)
Controls and connections
1 IN
1/4″ jack socket to connect instruments
2
This LED lights when the effects pedal is used. When the LED is
off or dim while the effects pedal is used, the battery is exhaust-
ed and must be replaced.
3 TRUE BYPASS Foot switch for enabling or disabling the pedal function
4 OUT
1/4″ jack socket to connect an amplifier
5 DC 9V
Connection for the external power supply with 9 V DC.
When an external power supply is used, the battery supply is cut
off automatically.
6 LOW
Turn this control to set the low frequencies.
7 MID
Turn this control to set the mid frequencies.
8 HIGH
Turn this control to set the high frequencies.
9 LEVEL
Turn this control to set the output level.
10 VOICE
Sets the frequency response and distortion. In combination with
[DRIVE], it can simulate many kinds of amplifiers.11 DRIVE
Turn this control to set the degree of distortion.
‘ ()
+ *
% $
TR OUT
LOW
MID
HIGH
LEVEL
VOICE
DRIVE
UE BYPA
AC TONE
S S I N
DC 9V
& ,
ö #
Technical specifications
· Input connections
· Input impedance · Output connections · Output impedance · Current consumption · Power supply · Power adapter
Socket for connecting a power adapter
1/4″ jack socket
1 M
1/4″ jack socket
1 k
3.8 mA
External power adapter, 100 – 240 V ~ 50/60 Hz
Secondary current 200 mA
Secondary voltage 9 V
Polarity
centre negative
· Battery · Degree of protection · Dimensions (W × H × D) · Weight · Ambient conditions
A detailed user manual is available to download on the product website on our homepage www.thomann.de.
9-V block battery IP20 97 mm × 55 mm × 120 mm 390 g Temperature range 0 °C…40 °C Relative humidity 20 %…80 %
(non-condensing)
For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the notes and markings on the packaging.
Batteries must not be disposed of as domestic waste or thrown into fire. Dispose of the batteries according to national or local regulations regarding hazardous waste. To protect the environment, dispose of empty batteries at your retail store or at appropriate collection sites.
This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version. Do not dispose of your old device with your normal household waste. Dispose of this product through an approved waste disposal firm or through your local waste facility. Comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility.
