RWHD Series No-Drill Mount

Product Information

The RWHD Series No-Drill Mount by Interactive Products
Corporation is a versatile, ergonomic, and rugged mobile computing
and communication mounting system. It is designed to meet and
exceed customer expectations, providing a specialized solution for
mobile mounting needs.

Interactive Products Corporation offers a range of options for
the No-Drill Mount, including shorter notch brackets, greater angle
notch brackets, and a dual seat bolt no-drill option specifically
for Ford Explorer. These options are readily available for
immediate shipment.

Please note that the laptop computer stand should never be used
when the vehicle is in motion. It is essential to safely park the
vehicle before using the stand to avoid any potential accidents.
Interactive Products Corporation will not be liable for any damages
resulting from improper use of their laptop stands.

WARRANTIES AND GUARANTEES:

All products are guaranteed to be free of manufacturers defects
for a period of one year from the date of purchase. The Laptop
Docking Stations are guaranteed not to crack or break within one
year from the date of purchase.

Interactive Products Corporation offers repair or replacement,
at their discretion and without charge, for any products that fail
to perform due to defects in material or workmanship. However, this
warranty does not cover defects resulting from damage or misuse,
such as excessive force or improper installation.

Interactive Products Corporation will not be responsible for any
incidental and/or consequential damage due to the failure of their
products. Customers may have additional rights that vary from state
to state.

RETURN POLICY:

To return a product under warranty, customers need to contact
Interactive Products Corporation toll-free at 1-888-552-7867. An
RMA (Return Materials Authorization) number will be issued, and no
product will be accepted without this number. The customer is
responsible for return shipping.

The merchandise should be packaged in the original shipping
container, if possible. Customers need to include a note detailing
the reason for return, along with a copy of the receipt, name,
address, and phone number.

Interactive Products Corporation will evaluate the defect and,
at their discretion, either replace or repair the item at no
charge. However, products returned due to customer error must be
returned within 30 days, in resalable condition, and in the
original container. A restocking charge of 20% of the purchase
price will be assessed.

UPGRADES:

If customers decide to upgrade to a heavy-duty model,
Interactive Products Corporation offers the option to swap the
product and apply the purchase price (excluding freight and taxes)
to the purchase of an upgraded unit. The returned product must be
in resalable condition. If any portion of the returned product is
damaged, Interactive Products Corporation will contact the customer
to determine the reduction in their credit.

AIRBAG FRIENDLY and AIRBAG COMPATIBLE:

The compatibility between installation systems (mounting
hardware) for mobile communications equipment and the airbag
deployment zones in automobiles is a crucial concern. While many
hardware manufacturers promote their products as airbag friendly or
airbag compatible, the ultimate responsibility lies with the
installer and/or end-user.

Product Usage Instructions

Park the vehicle safely before using the RWHD Series No-Drill
Mount.
Ensure that the laptop computer stand is not used while the
vehicle is in motion.
For warranty returns, contact Interactive Products Corporation
at 1-888-552-7867 to obtain an RMA number.
Package the product in its original shipping container, if
possible.
Include a note explaining the reason for return, along with a
copy of the receipt, name, address, and phone number.
Ship the product back to Interactive Products Corporation at
your own expense.
For products returned due to customer error, make sure to
return them within 30 days in resalable condition and in the
original container.
If upgrading to a heavy-duty model, contact Interactive
Products Corporation to arrange the swap and apply the purchase
price (excluding freight and taxes) to the upgraded unit.
Follow all airbag compatibility guidelines provided by the
installer and/or end-user when installing the mounting hardware for
mobile communications equipment.

View Fullscreen

INTERACTIVE PRODUCTS CORPORATION
148 Bluff Road, Dayton, TN 37321 Phone: 888-552-7867 Fax:. 423-775-0611
RWHD SERIES NO.DRILL MOUNT INSTALLATION INSTRUCTIONS
lnteractive Products Corporation manufactures the most versatile, ergonomic and rugged mobile computing and communication mounting systems available. We strive to meet and exceed our customer’s expectations. We will manufacture specialized units to meet your
mobile mounting needs.
No-Drill Note: Shorter notch brackets, greater angle notch brackets and dual seat bolt no-drill for Ford Explorer are in stock and ready for immediate shipment.
lf you have any questions, call us toll-free at: 888-552-7867.
CAUTION: NEVER USE LAPTOP COMPUTER STAND WHEN VEHICLE lS lN MOTION! SAFELY PARK VEHICLE PRIOR TO USE.
INTERACTIVE PRODUCTS CORPORATION WILL NOT BE LIABLE FOR ANY DAMAGES RESULTING FROM IMPROPER USE OF OUR LAPTOP STANDS.
Thank you for your business.
WARRANTIES AND GUARANTEES:
All products are guaranteed to be free of manufacturers defects for a period of one year from the date of purchase. All Laptop Docking Stations are guaranteed not to crack or break for a period of one year from the date of purchase.
lnteractive Products Corporation will repair or replace, at our discretion, without charge, any of our products which fail to perform due to defects in material or workmanship. Defects which result from damage or misuse, such as excessive force or improper installation, are not covered by this warranty.
lnteractive Products will not be responsible for any incidental and/or consequential damage due to failure of any lnteractive Products Corporation product.
lmportant: This Warranty gives you specific legal rights. You may have other rights which vary form state to state.

RETURN POLICY:
To return a product under warranty, contact lnteractive Products toll free at 1-BBB-552-7867. lnteractive Products will issue an RMA (Return Materials Authorization) number. No product will be accepted without an RMA number. The customer is responsible fqr return shipping. Package the merchandise in the original shipping container, if possible, and include a note detailing the reason for return along with a copy of your receipt. Please include your name, address and phone number.
lnterbctive Products will evaluate the defect and, at our discretion, either replace or repair the item and return it to the customer at no charge.
Products returned due to customer error must be returned within 30 days, in resalable condition, in the original container. A restocking charge of 20% of the purchase price will be assessed.
UPGRADES:
Should the customer decide to upgrade to a heavy-duty model, lnteractive Products will swap the product and apply the purchase price (excluding freight and taxes) to the purchase of an upgraded unit. Product must be returned in resalable condition. Should any portion of the returned product be damaged, lnteractive Products will contact the customer to determine the reduction to their credit.
“AIRBAG FRIENDLY ” and “AIRBAG COMPATIBLE”
Much has been discussed, advertised and promoted regarding the compatibility between installation systems (mounting hardware) for mobile communications equipment and the “airbag deployment zones” in automobiles. Although many hardware manufacturers promote their products as being “airbag friendly” or “airbag compatible” the ultimate responsibility lies with the installer and/or end-user.
Any combination of installation hardware and mobile communication equipment that is not installed and positioned properly within the suggested dimensional parameters as defined by the vehicle manufacturer could potentially interfere with the deployment of the airbag(s). As a hardware manufacturer, lnteractive Products Corporation can make suggestions and recommendations for the correct positioning and installation of our mounting systems. However, lnteractive Products Corporation cannot control the ultimate placement and/or quality of the installation; nor can we control the type, size, style or placement of mobile communication equipment which the end-user chooses to mount onto, or with our products.
Manufacturers of public safety and law enforcement automobiles have provided, over the past few years, detailed information regarding the “airbag deployment zone(s)” in their specific vehicles. ln printed material and via videotapes, car manufacturers have outlined and

illustrated the area within each vehicle that is considered a safe zone for installing mobile communications equ ipment.
Note: Although airbag templates are available to assist in positioning equipment, they may not give you an exact image of the actual “deployment zone” of a rapidly inflating airbag. We strongly suggest you supplement the use of templates with the informatioh provided by the vehicle manufacturer for a more accurate representation of available installation space.
WARNING!
Do not install the mount system or position the equipment in the deployment path of an airbag. ln the event of airbag deployment, mounting systems and/or equipment located within the airbag deployment zones can damage the airbag, prevent proper airbag inflation and/or become projectiles which could potentially cause personal injury or death. To determine airbag deployment zones and the area recommended for equipment installation, refer to vehicle manufacturer’s manual. lnteractive Products Corporation makes no warranties except for intended use and will not be held liable or responsible for any loss or damage, whether direct, indirect, incidental, special or consequential arising from the sale, use or misuse of lnteractive Products Corporation products or the user’s inability to use such products.
SUGGESTED LAPTOP POSITIONS

Option A: Center / Low No encroachment into airbag zone; least amount of room for other equip-
ment

Option B: Offset / High May encroach airbag zone zone when screen is upright; most amount of room
for other equipment

NOTE: Assembly order: 1.No-Drill 2. Pedestal 3. Laptop Docking Station
NOTE: MAKE SURE ALL PARTS ARE PRESENT AND READ ALL INSTRUCTIONS
PRIOR TO ASSEMBLY (SEE NO-DRILL DETAIL, PAGE 5).
First determine the best configuration to suit your vehicle seat bolt. The most common seat bolt configurations are as follows:
Configuration 1: Seat bolt straight down in floor.

Configuration 2: Seat bolt straight back from glove
box, toward seat.

Configuration 3:

45″ angle from glove box to seat.

NO.DRILL DETAIL

{5-2 3,,8-18 HEF HUT

I,”T-20 BUTTOH HEAD EOLT

.- ***-is_ril.ir..’,

15-l

1,’4-201{EP HUT

1S-2 HEX STOCH

I
I
7?.-1
HEX HEY FOR 1.,4-20 BOLTS

I
I
4
SHOCH COHTROL PAD

I
I I
ts-3
FLf,T PLATE

m*- zfi

*trsHER ffi;#REHE

5Ji1188–1188 SsEET SCREW

-*- t3 FLf,T HE*D fiLLEH BOLT

NO.DRILL HARDWARE

PACKET INCLUDES:

PART #:

DESCRIPTION:

Qtv:

4 Shock control pad

B Neoprene washer

13 Flat head allen bolt

15-1 %-20 kep nuts

15-2 3/8-16 keo nuts

1B-1 %-20 Button head bolt 2

1s-1 Fork bracket

19-2 Hex stock

19-3 Flat plate

20 Glider

21 3-pronq knob

22-1 Hex kev for To-20 bolts 1

26 5116-18 Set screw

NO-DRILL INSTALLATION INSTRUCTIONS
ASSEMBLE NO-DRILL BASE MOUNT:
1. Loosen seat bolt and insert fork bracket (19-1) under seat tragk or seat bolt (Under
seat track is most desirable, but if this is not possible, under seat bolt is sufficient). Retighten seat bolt.
2. Attach hex stock (19-21 to fork bracket using three-prong knob (211 or
5116-18 set screw (26). Choose the hole on the fork bracket that prevents three-prong knob from interfering with vehicle seat. lf knob causes a conflict with the seat position, use the 5116-18 set screw in place of the three-prong knob.
NOTE: Make sure grooved portion of hex stock is lined up perfectly with the hole in the fork bracket so that the knob seats completely. lf this is not done correctly, the hex stock may become deformed, which will cause it to get stuck in the fork bracket.
3. Attach flat plate (19-3) underneath hex stock using 114-20 button head bolts (18-1)
and 114-20 kep nuts (15-1). Use hex key (22-1) to tighten. Make sure button head
bolts are tightened completely.
4. Make sure flat plate is as close to the vehicle floor as possible. This allows you to
screw swivel gliders (20) toward floor, and receive back pressure against seat track or seat bolt. This will substantially stabilize your laptop stand, Flat plate can have a downward slope toward vehicle floor. This will also help you receive more back pressure with the swivel gliders for added stability.
5. Screw two of the 3/8-16 kep nuts (15-2) onto swivel gliders with washer facing up.
lnsert swivel gliders into flat plate from the bottom. Screw the last two 3/B-16 kep nuts
onto swivel gliders with washer facing down toward flat plate. Use wrench to hold bottom kep nut in place while using a flat-head screwdriver to screw swivel gliders
toward vehicle floor. Once flat plate is rigid, tighten the top and bottom kep nuts so
swivel gliders are locked in place.
6. You are now ready to install your pedestal to the No-Drill base.

LapTraveler@ RWHD SERIES NO-DRILL MOUNT PEDESTAL & DOGKING STATION ASSEMBLY INSTRUCTIONS
NOTE: MAKE SURE ALL PARTS ARE PRESENT AND READ ALL INSTRUCTIONS PRIOR TO ASSEMBLY.
ATTACH PEDESTAL TO NO.DRILL BASE (SEE PEDESTAL DETAIL, PAGE 9):
1. Set tilt & rotate mechanism (2) on top of Absorb-lt shock control pad (a). Attach to No-Drill (19) using flat head allen bolts (13), galvanized neoprene washers (8) and
114-20 kep nuts (15-1). Tighten allen bolts with hex key (22-11.
2. Slide telescoping tube portion of pedestal (3-1 , 3-2 or 3-3) into straight tube (3)
portion of pedestal. (Pedestal height can be adjusted by loosening two-prong knob (9),
raising or lowering telescoping tube, and retightening two-prong knob.)
NOTE: TELESCOPING TUBE lS COMPLETELY REMOVABLE – USE CAUTION WHEN ADJUSTING HEIGHT – TUBE MAY COME OUT AND LAPTOP MAY BE DAMAGED IF
YOU DROP IT!
3. lnsert second tilt & rotate mechanism onto telescoping tube portion of pedestal, and
tighten with two-prong knob.
ASSEMBLE DOCKTNG STATTON (SEE DOCKING STATION DETAIL, PAGE 10):

DOCKING STATION

HARDWARE PACKET INCLUDES:

PART #:

DESCRIPTION:

QTY:

4 Shock control oad

10 L-bracket

11 Quick release strap

13 Flat head allen bolt

15-1 %-20 kep nut

15-3 6/32 kep nut

16 knob

1B-3 6/32 Button head bolt 2

22-3 Hex kev for 6/32 bolt

23 Note pad clip

4. Position laptop docking station (1) face up with the lip at the bottom.
5. Line up holes in the notepad clip (23) (clipping mechanism toward the lip) with the top
two holes in the docking station (SEE CLIP DETAIL, PAGE 10).

6. Attach notepad clip by inserting two button head bolts (18-3) through the notepad clip and docking station from the top, and securing with two kep nuts (15-3) screwed on from underneath. Make sure the teeth on the kep nut are touching the back of the docking station. Tighten with hex key (22-31.
7. lnstall Compu-Loc computer fastening system to docking statioh as follows (SEE
DOCKING STATION DETAIL, PAGE 10): Attach plastisol coated L-brackets (10) to top of the docking station using knobs (16) inserted from underneath.
8. lnsert the quick release strap (11) through the slots in the docking station. Feed from underneath into the right slot, across top of docking station, and then down through the
left slot.
ATTACH DOCKING STATION TO PEDESTAL:
9. Set Absorb-lt shock control pad on top of tilt & rotate mechanism. Set docking station on
top of shock control pad and attach using flat head allen bolts and 114-20 kep nuts as in step 1. Tighten allen bolts with hex key.
SIZE COMPU.LOC COMPUTER SECURING SYSTEM:
10.Place laptop onto docking station and adjust L-brackets so they rest against the back of the laptop when laptop is resting on the front lip of the docking station.
11.Remove laptop and move L-brackets 1/8″ to 1/4″ closer to the front lip and tighten
L-brackets with knobs.
*Your Compu-Loc Computer Fastening System is now set up so that the laptop will snap on and off of the docking station.
12. Re-attach laptop to docking station. Open clamshell. Lay quick release strap
across the keyboard, above the function keys so as not to impede any keys. Thread strap
through buckle and synch laptop to docking station. Laptop can now be used without
releasing the buckle.

RWHD SERIES PEDESTAL ASSEMBLY DETAIL t7

@t/e ffi “.,

]

Mritgrytr-)*;:” I *;i 1:

*lt!

.#s

f. d #

r*-‘t 3 lr

;, $. z, 3*[email protected] DETAIL} {SEE DOCHIHG STATIOH ASSEIuIBLY nt

lw-13
* ffi

?2-1

17_F ffi –% ,c*.*l id
