Product Information
The MTS Collective is a product that comes with various parts
and accessories for assembly. It includes the following
components:
- 1x Bedienungsanleitung (Instruction Manual)
- 1x BAG
- 1x BOX
- 1x Swivel and Quick Release Adapter
- 1x VPC Rotor TCS Mount (if ordered)
- 2x M6 slot nut
- 2x M6x16 black screw
- 2x black plug
- 2x M8 slot nut
- 2x M8x14 screw
- 2x washer
- 2x cap plug
- 1x axial ball bearing
- 1x swivel inlay
- 1x swivel cap
- 2x knob
- 4x M4x16 flat head screw
- 1x original VPC screw M8x25
- 3x M8 slot nut
- 1x set screw M8x10
- 2x loose fit double slot nut
- 4x universal connector
- 4x M8x30 very loose fit screw
Product Usage Instructions
Assembly for VPC Rotor TCS:
- Screw on the pre-assembled universal connector threads loosely
at first. It will be moved to the correct position later. - Attach the pre-assembled universal connector to the desired
position using 2x M8x14 screws and washers. - Attach the swivel and quick release adapter using 1x M8x10 set
screw. - Secure the assembly using the provided knobs.
Alternative Mounting for Higher Collective Positions:
- Use 2x M8 slot nuts to attach the assembly.
- Screw on the M8x14 screws loosely at first. They will be moved
to the correct position later. - Secure the assembly using the provided knobs.
Assembly for WinWing Gemini:
- Attach the pre-assembled universal connector to the desired
position using 4x M6x16 screws. - Mount the profile horizontally for WinWing Gemini.
- Secure the assembly using the provided cap plugs and slot
nuts.
Assembly for All Versions:
- Choose the desired distance to the seat for positioning.
- Attach the assembly using 3x M8 slot nuts.
- Tighten both knobs for secure fitting.
Note: For all assemblies, make sure to tighten the screws and
knobs properly for stability and safety.
MTS COLLECTIVE
Instruction Manual Bedienungsanleitung
Mode d`emploi
PARTS
1x
1x
80
4 0
80
230
1x
260
1x
80
1x
80
150
thr eads
40
40
2x
8 0
80
2x
Ø20
80
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL
2
8
Ø 8
BAG
6x
30
3x
22
3x
8,4 24
BOX
1x
6x
11x
M8
6
4x
16
4x
6,4 12
1x
4x
M6
8
8
1x M8 M8 60
2x
14
1x
10
2x
8,4 16
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL
3
Swivel and Quick Release Adapter
1x
1x
1x
4 0
80
1x
10 26,1
2x
8,1 16
VPC Rotor TCS Mount if ordered
1x
1x
8,4 24
6
2x
16
4x
black
4
16
2x
M6
2x black
6,4 12
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL
4
ASSEMBLY FOR VPC ROTOR TCS
pre-assembled universal connector
threads
pre-assembled universal connector
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL
5
2x slot nut
M6
2x M6x16 black
2x washer Ø12
black
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL
6
Alternative mounting allows for higher collective positions.
Alternative mounting to get the collective closer to the seat.
2x slot nut
M8
1.
Screw on loosely at first. Will be moved to the correct position
later.
2.
2x M8x14
2x washer
Ø16
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL
7
cap cap
2x plug
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL
8
detailed view
axial ball bearing
swivel inlay
axial ball bearing
swivel cap
loose fit
knob
knob
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL
9
4x M4x16 flat head
washer Ø24
original VPC screw M8x25
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 10
ASSEMBLY FOR WINWING GEMINI
Only different steps are shown.
2x pre-assembled universal connector
Mount this profile horizontally for WinWing Gemini. MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 11
4x slot nut
M6
cap plug
plug cap
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 12
4x M6x16
4x washer Ø12
Move to desired position before tightening screws.
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 13
ASSEMBLY FOR ALL VERSIONS
cap 3x slot nut M8
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 14
3x M8x22 3x washer Ø24
choose desired distance to seat
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 15
set screw M8x10
knob
loose fit double slot nut 2x M8
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 16
Detail
4x slot nut
M8
MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 17
4x universal connector 4x M8x30 very loose fit
choose desired position before tightening the bolts MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 18
tighten both knobs MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 19
Slide down until it touches the profile. Then fully tighten the screws.
Tighten set screw and knob. MTSIM MTS COLLECTIVE INSTRUCTION MANUAL 20
24-11-2022
