Luna IPx4 Ceiling Hoist with Multiple Solutions
Product Information:
The Luna IPx4 is a ceiling hoist designed for use in hospitals,
nursing homes, and home care settings. It is a part of Winncare’s
overhead lifting solutions, which are ideal for moving and handling
patients, the elderly, and individuals with physical disabilities.
The Luna ceiling lift is lightweight and versatile, providing
optimal room coverage when used with Winncare’s overhead tracking
systems. It is IPx4 tested for wet environments, ensuring safe
transfers in bathrooms even if the unit is showered with water. The
hand controls are also IPx4 and IPx7 tested, allowing them to
withstand exposure to showering and full immersion in water,
respectively. The Luna can be combined with Winncare’s extensive
range of ceiling and wall mounted tracks, offering complete lifting
and transfer solutions for the healthcare sector. Other notable
features include Winncare’s patented spreader bar and sling hook
system for safe and easy sling attachment, as well as an ergonomic
hand control with a charging function and optional top or bottom
cable exit.
Product Usage Instructions:
- To access Luna videos, manual lowering instructions, quick
guides, or the user manual, scan the QR code provided. - Ensure that the Luna ceiling hoist is installed securely
according to the installation instructions. - When using the Luna in wet environments, such as bathrooms,
rest assured that it is IPx4 tested and safe for operation even if
showered with water. - The hand controls are designed to withstand exposure to water.
The IPx4 hand control can tolerate showering, while the IPx7 hand
control can be fully immersed in water. - Combine the Luna with Winncare’s ceiling and wall mounted
tracks to create a complete lifting and transfer system that meets
the latest requirements in the healthcare sector. - To attach a sling, apply a minimum downward pressure to lock
the sling hook in place. To unlock the sling hook, pull
upwards. - In case of an emergency, the Luna offers both manual and
electrical emergency lowering functions. The manual emergency
lowering can be performed using the hand control or manually on the
Luna motor. - Refer to the user manual for detailed instructions on the
maintenance and operation of the Luna ceiling hoist.
Please note that for specific technical specifications,
accessories, and other inquiries, it is recommended to contact
Winncare directly.
Scan QR and see Luna video, manual lowering instructions, quickguide or user manual
Luna IPx4
Ceiling hoist with multiple solutions
Used in hospitals, nursing homes and home care, Winncare’s overhead lifting solutions are the perfect choice of moving and handling equipment for patients, the elderly and the physically challenged.
Our overhead lifting systems revolve around the lightweight and versatile Luna ceiling lift which installs in seconds and, together with our overhead tracking systems, offers optimal room coverage.
The Luna is IPx4 tested for wet environments, allowing safe transfers in bathrooms free of the risk of lift failure if the unit is inadvertently showered with water. The hand controls are both IPx4 & IPx7 tested, tolerating exposure to showering and full immersion in water, respectively.
A truly unique Luna feature, which differentiates it from the competition, is its ability to be used as either a fixed or portable ceiling hoist in one and the same unit; Simply reverse the Luna unit, select the appropriate spreader bar, and fixed Luna becomes portable Luna and visa versa. This is a cost effective incentive for institutions who need only invest in only one modular model to cover all their lifting requirements. Another distinctive Luna feature is the unique quick release mechanism: a simple twist and turn movement detaches the lift from the track in just a matter of seconds, without tools.
Combine Luna with Winncare’s extensive programme of ceiling and unique wall mounted tracks, and you have a system providing complete lifting and transfer solutions to meet the latest requirements in the health care sector.
Other noteworthy features include: Winncare’s patented spreader bar and sling hook system ensuring safe and simple sling attachment, and the ergonomic hand control with its charging function and optional top or bottom cable exit.
Key standard functions · IPx4 tested for wet environments · Weight capacity of 200kg / and 275kg. · One lift: fixed or portable options in the same modular
design. · Emergency lowering functions on hand control & Luna
motor. · Charging through the ergonomic hand control on wall
mounted docking station. · Patented Winncare sling hooks.
Combine Luna with Winncare’s extensive programme of ceiling and wall mounted tracks
New improved screw lock connector on hand control & motor.
IPx7 hand control tolerates immersion in water.
Options for top or bottom cable on IPX4 hand control. It is also possible to select the length of the cable.
Manual emergency lowering
Electrical emergency lowering
Manual emergency lowering functions: powered on hand control and manual on Luna motor.
Sling attachment: a minimum of downward pressure locks the sling hook.
Pull upwards to unlock sling hook.
MDD93/42/EEC Class I
date 23.03.2022 – ver.7
Version
Item no.
LunaIPx4/200 kg, portable (strap)
015-03020
LunaIPx4/275 kg, portable (strap)
015-03022
LunaIPx4/200 kg, fixed (bayonet)
015-03026
LunaIPx4/275 kg, fixed (bayonet)
015-03028
LunaIPx4/200 kg, fixed (bayonet), 2 ports
015-03032
LunaIPx4/275 kg, fixed (bayonet), 2 ports
015-03034
LunaIPx4/200 kg, room to room
015-03035
LunaIPx4/275 kg, room to room
015-03037
Accessories
Item no.
Hand control IPx4 with cable on top*
015-03105
Hand control IPx4 with cable on bottom*
015-03101
Hand control IPx7*
015-03109
2, 3, 4 points spreader bars
Contact Winncare
Wide sling range
Contact Winncare
Weigh scale
Contact Winncare
Extension strap in various lengths
Contact Winncare
TECHNICAL SPECIFICATION
*List of accessories can be modified.
Max. capacity Length of lifting strap Weight Measurements Battery operation Charging Chassis Housing Noise
Time of charging Lifting speed down Lifting speed up No. of lifts per charge Protection class
200 kg/275 kg 2200 mm 6,7 kg w/o spreader bar 320 x 130 mm 36 V, lead acid batteries 100- 240 V, 0,5 A Aluminium High impact, moulded ABS Lwa during lifting/lowering without load is 48dB(A) Lwa during lifting/lowering at maximum load is 52dB(A) appr. 4,5 – 5 hours to fully charge empty battery 44 mm/sec with 89 kg load 30 mm/sec with 89 kg load 50 lifts of 0,5m with 100 kg IPx4
· Soft start and stop motor control · Electrical and manual emergency lowering · Electrical emergency stop · Low battery indicator (visual LED) · Charging indicators · Power on indicators · Overload protection · Emergency brake system
All protection class tests are carried out by TÜV.
580 *
Fixed mode
320
580 *
Portable mode
320
170 430
155 465
1950
1950
* The size of the spreader bar varies depending on the model.
Consult the Technical manual for further specifications. All figures and measurements are for guidance only and may differ in actual situations. Winncare reserves the right to changes without notice.
Product photos may include accessories. Consult your dealer.
