Product Usage Instructions

To use the Mecanum Wheels 80mm, follow these steps:

Attach the wheels to the desired vehicle or platform.
Ensure that the wheels are securely fastened.
To move straight ahead, activate the wheel drive in the desired
direction indicated by the blue arrow, and the vehicle will move in
the direction indicated by the red arrow.
To move sideways, activate the wheel drive in the desired
direction indicated by the blue arrow, and the vehicle will move to
the side.
To move diagonally, activate the wheel drive in the desired
direction indicated by the blue arrow, and the vehicle will move
diagonally.
To move around a bend, activate the wheel drive in the desired
direction indicated by the blue arrow, and the vehicle will
maneuver around the bend.
To rotate, activate the wheel drive in opposite directions on
both sides of the vehicle.
To rotate around the central point of one axle, activate the
wheel drive in opposite directions on one side of the vehicle.

View Fullscreen

Handson Technology

User Guide

Mecanum Wheels 80mm

This is 80mm rubber omni-directional wheel for DIY robotics car project. The wheels rim is made of the reinforced nylon material. The rubber of the wheels is high quality. It is wearresistance and deep groove for high grip anti-skid. You can find the matching motor shaft coupler for Ø5~Ø8mm shaft motors. With these wheels you will be able to get almost any beginners robot project moving.

SKU: ROB1000
Brief Data:
Item Name: Mecanum Wheel. Wheel Type: Right & Left. Inner diameter: Ø6.5mm. Outer wheel diameter: Ø80mm. Thickness: 37mm. Number of sub-wheels: 9. Weight: 100g (single). Load Capacity: ~10kg (4 together).
1

www.handsontec.com

Mechanical Dimensions:
Unit: mm

www.handsontec.com

Application Note:
The mecanum wheel is a form of tireless wheel, with a series of rubberized external rollers obliquely attached to the whole circumference of its rim. These rollers typically each have an axis of rotation at 45° to the wheel plane and at 45° to the axle line. Each Mecanum wheel is an independent non-steering drive wheel with its own powertrain, and when spinning generates a propelling force perpendicular to the roller axle, which can be vectored into a longitudinal and a transverse component in relation to the vehicle.

Movements to any directions: blue: wheel drive direction; red: vehicle moving direction a) Moving straight ahead, b) Moving sideways, c) Moving diagonally, d) Moving around a bend, e) Rotation, f) Rotation around the central point of one axle
