Id Tech Neo 3 Payment Devices User Guide

The VP3350 will remain connected via Bluetooth to the host
device indefinitely when powered via the USB cable. If operating on
battery power, it will go to sleep after 30 seconds of idling to
extend battery life. To perform a transaction again, press the
power button to re-establish the Bluetooth connection.

When connecting to an iOS device, please install a compatible
payment application and follow the instructions provided by that
application’s maker.

iOS Connectivity: BLE and VP3350

The VP3350 uses Bluetooth Low Energy (BLE) for iOS connectivity.
Unlike other operating systems, Apple iOS does not require users to
first pair their devices through the Bluetooth Settings. If a
payment application provider has enabled BLE scanning in their
application, Apple iOS will automatically scan and locate all BLE
devices in range to connect with the VP3350.

Note: If the VP3350 is paired via the iOS Settings page, it will
display as a connected device but will not function with a payment
app. Apple iOS calculates a unique identifier to allow direct
connection with the selected device based on its friendly name.

NEO 3
P L AT F O R M O F P R O D U C TS

VP3350 QUICK START GUIDE
Overview The VP3350 is ID TECH’s latest PCI 6.X SRED certified mobile reader. The VP3350 supports Magstripe, EMV contact, and contactless using either USB-C, Lightning, and/or Bluetooth connections.
Contact your acquirer, gateway, or POS partner for instructions on setting up and pairing the VP3350 to a compatible payment application and host device.
Note that the full VP3350 Integration Manual is available free of charge on the ID TECH Knowledge Base: https://atlassian.idtechproducts.com/confluence/display/KB/Knowledge+Base+-+Home

MAGNETIC STRIPE READER

FRONT VIEW

NFC READER
LED INDICATORS
LEFT SIDE
EMV READER

PASS-THROUGH CHARGING & DATA COMMUNICATION PORT
BOTTOM
*Lightning & USB-C Models Only

POWER BUTTON
*Bluetooth Model Only
RESET BUTTON

ROTATING CONNECTOR

NEO 3
P L AT F O R M O F P R O D U C TS
Before You Begin Using the VP3350 The VP3350 should be charged four to six hours before the first use. After charging the device, follow the pairing instructions below to use the device in BLE.
Note: If the device is plugged into a host system via the USB cable, the unit will communicate via USB, even if it is still connected to Bluetooth.
Bluetooth Pairing Instructions In addition to the following instructions, see the section on iOS Connectivity for more information on using an iPad or iPhone with the VP3350.
1. Enable the Bluetooth device search function on the host device (smart phone or tablet). 2. Make sure the VP3350 is charged or connected to a power source via USB.
a. When connected to a power source, the VP3350 automatically activates Bluetooth. 3. When not connected to a power source, press the VP3350’s power button to automatically activate
Bluetooth. 4. Find a Bluetooth device named IDTECH-VP3350-XXXXX on the host smart phone or tablet and select Pair. 5. Enter the password for pairing. The default password is 123456. 6. Follow the payment transaction instructions provided by a compatible payment application maker to
complete a transaction.
The VP3350 will remain connected via Bluetooth to the host device indefinitely when powered via the USB cable. If the unit is operating on battery power, it will go to sleep after 30 seconds of idling to extend battery life. To perform a transaction again, press the power button to re-establish the Bluetooth connection.
When connecting to an iOS device, please install a compatible payment application and follow the instructions provided by that application’s maker.
iOS Connectivity: BLE and VP3350 The VP3350 uses Bluetooth BLE (Bluetooth Low Energy). BLE does not require users to first pair their devices through the Bluetooth Settings in Apple iOS. If a payment application provider has enabled BLE scanning in their application, Apple iOS scans and locates all BLE devices in range to automatically connect with the VP3350.
Note: If the VP3350 is paired via the iOS Settings page, it will display as a connected device but not function with a payment app.
Unlike other operating systems that detect BLE devices by MAC address, Apple does NOT allow users to specify BLE devices this way for security reasons. Instead, after a device is selected by its “friendly” name, the Apple iOS calculates a unique identifier to allow that device to connect directly.
The VP3350 has a default friendly name of IDTECH-VP3350-XXXXX.

NEO 3
P L AT F O R M O F P R O D U C TS

VP3350 LED and Sound State Indicators

Device State

LED 1 LED 2 LED 3 LED 4

Sound

*Battery Charging Full

on

on

on

on

None

Bluetooth Connected

on

on

on

on

Unit Beeps Once

Bluetooth Connection Failed

on

on

on

on

Unit Beeps Twice

Unit Ready

blink

off

off

off

Unit Beeps Once

Transaction Started

on

off

off

off

None

Transaction Successful

blink

blink

blink

blink

Unit Emits One Long Beep

Transaction Failed

off

off

off

off

Unit Beeps Twice

Unit Tampered

blink

blink

blink

blink

Unit Beeps

Device Deactivated
Power Off / Low-Power Consumption Mode

blink

blink

blink

blink

off

off

off

off

Unit Beeps None

*The device displays three LEDs to indicate 75% battery power and two LEDs for 50% battery power, and a red LED below 25% battery power.

VP3350 Mounting Guidelines To optimize performance, install VP3350 readers away from or in front of any metal surfaces or materials that have metallic content, which can interfere with the RF field. VP3350 readers perform optimally when mounted away from metal surfaces.
VP3350 Security ID TECH recommends checking the VP3350 units for evidence of tampering on a regular basis.
Decommissioning SRED Devices All PCI devices require proper decommissioning prior to device disposal in order to ensure the protection of all sensitive financial card data. For instructions on decommissioning your device, see Decommissioning of SRED Devices on the ID TECH Knowledge Base.

NEO 3
P L AT F O R M O F P R O D U C TS

Troubleshooting See the VP3350 Integration Manual (available on the ID TECH Knowledge Base) for a full list of troubleshooting suggestions or contact [email protected].

Symptom

Probable Cause

No communication and all LEDs off

· Power off · Battery out of charge · Host device not connected

Solution
· Charge the battery · Press the device Reset button · Make sure to enter the correct
paring password

Device is connected to iOS device but not communicating with payment app

· Incorrect Bluetooth pairing method for iOS

· See “iOS Connectivity: BLE and VP3350” above for iOS-specific pairing instructions

Bluetooth paring failed (Android)

· Host device running Android 6.x · Make sure the host device is

or earlier

running Android 6.X or later
