PIXMA TS305
COMPACT, SMART, AND AFFORDABLE WI-FI PRINTER
Wirelessly print high-quality documents and vivid 4×6” photos from smart devices using this affordable, compact printer. Make copies using the Smartphone Capture and Copy function via the Canon PRINT app. Sales Start Date: January 2018
- Simple Wi-Fi connectivity to smart devices, cameras, and the cloud
- Make copies with Smartphone Capture and Copy via the Canon PRINT app
- Print high-quality documents and vivid 4×6”borderless photos
- Compact, functional design with simple buttons
- Create memories to share with the Message in Print app
PRODUCT RANGE
PIXMA TS305
PIXMA E304
PIXMA TS205
PIXMA E204
TECHNICAL SPECIFICATIONS
GENERAL SPECIFICATIONS
| Functions | Wi-Fi, Print |
PRINTER SPECIFICATIONS
| Print Resolution | Up to 4800[1] x 1200 dpi |
| Print Technology | 2 FINE Cartridges (Black and Colour) |
| Mono Print Speed | Approx. 7.7 ipm[2] |
| Colour Print Speed | Approx. 4.0 ipm[2] |
| Photo Print Speed | Borderless 10x15cm : Approx. 65 seconds3 |
| Borderless Printing | Yes (10x15cm) |
CARTRIDGES AND YIELDS
| Standard Ink Cartridges | PG-545 (Pigment Black) CL-546 (Colour) |
| Optional XL Ink Cartridges | PG-545XL (Pigment Black XL) CL-546XL (Colour XL) |
| Cartridge Yield (Plain paper) | A4 colour documents printing[4] Black: 180 pages Black XL: 400 pages Colour: 180 pages Colour XL: 300 pages |
| Cartridge Yield (Photo print) | 10x15cm colour photo printing5 Black: 1445* photos Black XL: 3520* photos Colour: 55 photos Colour XL: 90 photos * Estimated supplemental yield |
PAPER SUPPORT
| Paper Types | Plain Paper Photo Paper Plus Glossy II (PP-201) Glossy Photo Paper “Everyday Use” (GP-501) |
| Maximum Paper Input | Rear tray: Max.60 sheets (plain paper) |
| Paper Sizes | Plain paper: A4, LTR Photo paper: 10x15cm |
| Paper Weight | Plain Paper: 64-105 g/m2 , Canon speciality paper: max paper weight: approx. 275 g/m (Photo Paper Plus Glossy II (PP-201)) |
INTERFACE
| Display Type & Size | No display |
| Interface Type – PC / Mac | Hi-Speed USB (B Port) Wi-Fi: IEEE802.11 b/g/n Wi-Fi Security: WPA-PSK, WPA2-PSK, WEP, Administration password Wireless LAN Frequency Band: 2.4GHz |
| Interface Type – Other | Bluetooth Message In Print app PIXMA Cloud Link Canon PRINT Inkjet/SELPHY app Canon Print Service Plugin (Android) Google Cloud Print Apple AirPrint Access Point Mode WLAN PictBridge Mopria (Android) |
SOFTWARE
| Supported Operating Systems | Windows 10 , Windows 8.1, Windows 7 SP1 Note: For Windows, .NET Framework 4.5.2 or 4.6 is required OS X 10.10.5~OS X 10.11, macOS 10.12 |
| Supported Mobile Systems | iOS, Android, Windows 10 Mobile |
| Minimum System | Windows: 3.1GB disk space, Internet Explorer 8 |
| Requirements | Mac: Internet connection, 1.5GB disk space, Safari 5 Display: 1024 x 768 XGA |
| Software Included | Printer Driver My Image Garden with Full HD Movie Print[6] Quick Menu Easy-WebPrint EX (download) [7] |
PHYSICAL FEATURES
| Weight | approx. 2.9 kg |
| Dimensions (W x D x H) | approx. 430 x 282 x 143mm |
| Acoustic Noise Levels | approx. 45.0dB(A)[8] |
| Operating Temperature | 5-35°C |
| Operating Humidity | 10-90%RH (no dew condensation) |
| Power Source | AC 100-240V, 50/60Hz |
| Power Consumption | Off: Approx. 0.2 W Standby (Wireless LAN connection to PC): Approx. 1.2 W Standby (all ports connected): Approx. 0.9 W Time to enter Standby mode: 1 minutes Printing (Wireless LAN connection to PC): Approx. 10 W [9] |
Footnotes
- Ink droplets can be placed with a minimum pitch of 1/4800 inch
- A4 document print speed on plain paper is measured based on the average of ESAT in the Office Category Test of ISO/IEC 24734 standard.
- Photo print speed is based on default driver setting using ISO/JIS-SCID N2 standard on Canon Photo Paper Plus Glossy II and does not take into account data
processing time on the host computer. - Declared yield value in accordance with ISO/IEC 24711. Values are obtained by continuous printing.
- Declared yield value in accordance with ISO/IEC 29102. Values are obtained by continuous printing.
- Full HD Movie Print is available for MOV and MP4 movie files created by select Canon digital cameras and camcorders. Requires installation of software bundled
with Canon video or digital camera, from which the movie was captured. MOV files require: ZoomBrowser EX / ImageBrowser (version 6.5 or later), MP4 files require:
ImageBrowser EX (version 1.0 or later). - Easy-WebPrint EX requires Internet Explorer 8 or later
- When printing ISO/JIS-SCID N2 pattern on 10x15cm Photo Paper Plus Glossy II using default settings.
- When printing ISO/JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings.
Standard disclaimers
- All specifications are subject to change without notice.
- Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
- Ink yield may vary depending on texts/photos printed, applications software used, print mode and type of paper used. For yield information see www.canoneurope.com/ink/yield
- All brand and product names are trademarks of their respective companies.
- Microsoft, Windows and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.
COMPACT, SMART AND AFFORDABLE WI-FI PRINTER
PRODUCT DETAILS:
| Product Name | Mercury Code | EAN Code | Recommended Retail Price |
| PIXMA TS305 EUR | 2321C006AA | 4.55E+12 | <Please fill in RRP> |
CONSUMABLES:
| Product Name | Mercury Code | EAN Code | Recommended Retail Price |
| Standard size | |||
| PG-545 | 8287B001AA | 4.961E+12 | <Please fill in RRP> |
| CL-546 | 8289B001AA | 4.961E+12 | <Please fill in RRP> |
| XL size | |||
| PG-545XL | 8286B001AA | 4.961E+12 | <Please fill in RRP> |
| CL-546XL | 8288B001AA | 4.961E+12 | <Please fill in RRP> |
MEASUREMENT / LOGISTIC INFORMATION:
| Product Name | Mercury Code | Pack description | Quantity per pack | Length (mm) | Width (mm) | Height (mm) | Gross Weight (kg) | Net Weight (kg) |
| PIXMA TS305 EUR | 2321 C006AA | Individual | 1 | 501.0 | 207.0 | 398. | 4. | 3. |
| Pallet (Upper) | 30 | 1010.0 | 1043.0 | 1200. | 133. | 132. | ||
| Pallet (Bottom) | 30 | 1010.0 | 1043.0 | 1200. | 133. | 131.7 |
What’s in the box?
- Single function printer – PIXMA TS305
- 2 FINE cartridges
- Power cord
- Setup CD-ROM
- Manuals and other documents
Canon Inc. canon.com
Canon Europe
canon-europe.com
English edition
Canon Europa NV 2018
