KDSDM82143 Dishwasher

Product Information

This product is a dishwasher.
It has a width of 595 mm, height of 820 mm, and depth of 555
mm.
The dishwasher has a capacity of 14 standard
place-settings.
It features an upper rack, cutlery rack, foldable flaps, upper
rack height adjuster, upper sprayer arm, dynamic clean support,
lower rack, and lower sprayer arm.
The control panel of the dishwasher can be activated by pushing
the ON/OFF button.
For energy saving, the control panel automatically deactivates
after 10 minutes if no cycle has started.

Product Usage Instructions

Before using the appliance, carefully read the Health and
Safety guide in the user manual.
During installation, ensure that the appliance is kept in an
upright position. If necessary, it may be tilted onto its
back.
Connecting the water supply should only be performed by a
qualified technician. The water inlet and outlet hoses can be
positioned towards the right or left for optimal installation. Make
sure not to bend or squash the hoses with the dishwasher.
The water inlet hose should not be cut as it contains live
electrical parts.
Before inserting the plug into the electrical socket, ensure
that the electrical connection is correct.
Connect the outlet hose to a drain duct with a minimum diameter
of 2 cm. The outlet hose connection should be at a height ranging
from 40 to 80 cm from the floor or surface where the dishwasher
rests. Remove the plastic plug before connecting the water outlet
hose to the sink drain.
The dishwasher is equipped with an anti-flooding protection
system that blocks the water supply in case of anomalies or leaks.
Some models have a supplementary safety device called New Aqua Stop
for added protection. Do not cut the water inlet hose.
Position the dishwasher on a level sturdy floor. Adjust the
front feet of the appliance if the floor is uneven to reach a
horizontal position. This will ensure stability and reduce
vibrations and noise during operation.
If recessing the dishwasher, stick the adhesive transparent
strip under the wooden shelf to protect it from condensation.
Place the dishwasher so that its sides or back panel are in
contact with adjacent cabinets or the wall. It can also be recessed
under a single worktop.
To adjust the height of the rear foot, use a hexagonal spanner
with an opening of 8 mm. Turn it clockwise to increase the height
and anticlockwise to decrease it.

View Fullscreen

Instruction for use

Installation ………………………………………………………………………………………………………………………….. 4 Product description ……………………………………………………………………………………………………………… 5 First time use ……………………………………………………………………………………………………………………….. 6 Advice and tips ……………………………………………………………………………………………………………………. 8 Loading the racks ……………………………………………………………………………………………………………….. 8 Selecting a cycle and options ………………………………………………………………………………………………..10 Cycle table …………………………………………………………………………………………………………………………. 11 Options and settings ………………………………………………………………………………………………………….. 12 Settings menu …………………………………………………………………………………………………………………… 13 Care and maintenance ……………………………………………………………………………………………………….. 14 Troubleshooting …………………………………………………………………………………………………………………. 15 After-sales service …………………………………………………………………………………………………………….. 17
3

Before using the appliance carefully read Health and Safety guide.

INSTALLATION

ATTENTION: If the appliance must be moved at any time, keep it in an upright position; if absolutely necessary, it may be tilted onto its back.

CONNECTING THE WATER SUPPLY
Adaptation of the water supply for installation should only be performed by a qualified technician. The water inlet and outlet hoses may be positioned towards the right or the left in order to achieve the best possible installation. Make sure the dishwasher does not bend or squash the hoses.

CONNECTING THE WATER INLET HOSE
· Run the water until it is perfectly clear. · Screw the inlet hose tightly into position and turn on the tap. If the inlet hose is not long enough, contact a specialist store or an authorised technician. The water pressure must be within the values indicated in the Technical Data table – otherwise the dishwasher may be function properly. Make sure the hose is not bent or compressed. SPECIFICATIONS FOR THE CONNECTION OF THE WATER SUPPLY HOSE:

WATER SUPPLY

cold or hot (max. 60°C)

WATER INTAKE

3/4″

POWER OF WATER PRESSURE

0,05 ÷ 1 MPa (0.5 ÷ 10 bar) 7,25 145 psi

ELECTRICAL CONNECTION
WARNING: Under no circumstances should the water inlet hose be cut as it contains live electrical parts.
Before inserting the plug into the electrical socket, make sure that:
· The socket is earth and complies with current regulations; · The socket can withstand the maximum load of the appliance as
shown on the data plate located on the inside of the door (see PRODUCT DESCRIPTION). · The power supply voltage falls within the values indicated on the data plate on the inside of the door. · The socket is compatible with the plug of the appliance.
If this is not the case, ask an authorised technician to replace the plug (see AFTER-SALES SERVICE). Do not use extension cables or multiple sockets. Once the appliance has been installed, the power supply cable and the electrical socket should be easily accessible. The cable should not be bent or compressed. If the power supply cable is damaged, have it replaced by the manufacturer or its authorised Technical Assistance Service in order to prevent all potential hazards. The Company shall not be held responsible for any incidents, if these regulations are not observed.

CONNECTING THE WATER OUTLET HOSE
Connect the outlet hose to a drain duct with a minimum diameter of 2 cm A. The outlet hose connection must be at a height ranging from 40 to 80 cm from the floor or surface where the dishwasher rests. Before connecting the water outlet hose to the sink drain, remove the plastic plug B.
ANTI-FLOODING PROTECTION
Anti-flooding protection. To ensure floods do not occur, the dishwasher: – is provided with a special system which blocks the water supply in the event of anomalies or leaks from inside the appliance. Some models are also equipped with the supplementary safety device New Aqua Stop, which guarantees anti-flooding protection even in the event of a supply hose rupture. Under no circumstances should the water inlet hose be cut as it contains live electrical parts.

POSITIONING AND LEVELLING
1. Position the dishwasher on a level sturdy floor. If the floor is uneven, the front feet of the appliance may be adjusted until it reaches a horizontal position. If the appliance is levelled correctly, it will be more stable and much less likely to move or cause vibrations and noise while it is operating.
2. Before recessing the dishwasher, stick the adhesive transparent strip under the wooden shelf in order to protect it from any condensation which may form.
3. Place the dishwasher so that its sides or back panel are in contact with the adjacent cabinets or the wall. This appliance can also be recessed under a single worktop.
4. To adjust the height of the rear foot, turn the red hexagonal bushing on the lower central part at the front of the dishwasher using a hexagonal spanner with an opening of 8 mm. Turn the spanner in a clockwise direction to increase the height and in an anticlockwise direction to decrease it.

MAX 80 cm MIN 40 cm

DIMENSIONS AND CAPACITY:

WIDTH

595 mm

HEIGHT

820 mm

DEPTH

555 mm

CAPACITY

14 standard place-settings

The control panel of this dishwasher activates pushing by ON/OFF button. For energy saving the control panel deactivates automatically after 10 minutes if no cycle has started.

PRODUCT DESCRIPTION
8 9
10 11
12
Service: 0000 000 00000
13

1. Upper rack 2. Cutlery rack

3. Foldable flaps

4. Upper rack height adjuster

5. Upper sprayer arm

6. Dynamic Clean support

7. Lower rack

8. Lower sprayer arm

9. Filter Assembly

10. Salt reservoir

11. Detergent and Rinse Aid dispensers

12. Rating plate

13. Control panel

CONTROL PANEL

1. ON-OFF button 2. CYCLES 6 buttons for direct acces popular cycles 3. EXTRA CYCLES button. Access to other cycles 4. INFO button. Provide info for selected cycle 5. DISPLAY – Indicators area 6. DISPLAY – Information area 7. PREVIOUS button for options/settings 8. SET button. Select/change options and settings 9. NEXT button for options/settings 10. START button

9 10

DISPLAY – INDICATORS

A BC I H GF

A. START DELAY B. ECO CYCLE
D C. MULTIZONE – Cutlery rack E D. CLOSED WATER TAP
E. ADD SALT F. MULTIZONE – Upper Rack G. MULTIZONE – Lower Rack H. ADD RINSE AID I. TABLET

FIRST TIME USE

After connecting the appliance to the power supply for the first time, the display will guide you to set up the appliance for first use.

1. The language selection

LANGUAGE: ENGLISH? To select preferred language please

<> = CHANGE

OK = YES press button ,,<” or ,,>”.

ENGLISH

Confirm by pressing,,SET” button.

SELECTED

After language confirmation, the appliance will go through the first time use configuration menu.

2. Setting the water hardness

WATER HARDNESS (1=MIN, 5=MAX)

The water hardness is by default set to level 3. To change water hardness level press button ,,<” or ,,>” repeatedly.

WATER HARDNESS = 3 To confirm your choice press ,,SET”

<> = CHANGE

OK = YES button. The level must be set

according to the table below.

To allow the water softener to work in a perfect way, it is essential that the water hardness setting is based on the actual water hardness in your house. This information can be obtained from your local water supplier.

Water Hardness Table

Level

German degrees °dH

French degrees °fH

Soft

Medium

Average

Hard

Very hard

0 – 6 7 – 11 12 – 17 18 – 34 35 – 50

0 – 10 11 – 20 21 – 30 31 – 60 61 – 90

3. Filling the water softener

POUR WATER OPERATION

When water hardness is set, it is required to fill water softener with

INSERT 1,5 LITER OF water and special regeneration salt. OK = DONE Remove the lower rack and unscrew

WATER IN THE

the reservoir cap (anticlockwise)

OK = DONE As a first step it is needed to fill

WATER SOFTENER

reservoir with water ( ~1.5 litres).

OK = DONE Once done, proceed to the next

step by pressing,,SET” button.

INSERT SALT OPERATION

ADD 1KG OF SALT OK = DONE

IN THE SALT DISPENSER OK = DONE

Position the funnel (see figure) and fill the salt reservoir right up to its edge (approximately 1 kg); it is not unusual for some water will spill out.
Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into the container during the wash program (this could damage the water softener beyond repair). Once done, proceed to the next step by pressing,,SET” button.
Only use salt that has been specifically designed for dishwashers.
Whenever you need to add salt, it is mandatory to complete the procedure before the beginning of the washing cycle. Residual saline solution or grains of salt can lead to corrosion, irreparably damaging the stainless steel components. The guarantee is not applicable if faults are caused by such circumstances. If the salt container is not lled, the water softener and the heating element may be damaged as a result.

4. Setting the brightness level

ADJUST BRIGHTNESS (1=MIN, 5=MAX)

The brightness level is by default set to level 5. To change brightness level

press button ,,<” or ,,>” repeatedly.

BRIGHTNESS = 5

To confirm Your choice press,,SET”

<> = CHANGE

OK = YES button.

5. Detergent type operation

DETERGENT TYPE OPERATION

DO YOU USE

<> = NO

OK = YES

“ALL IN ONE”

<> = NO

OK = YES

DETERGENT?

<> = NO

OK = YES

In this step it is very important to choose what type of detergent will be used (tablet/capsule or gel/powder).
If you prefer to use All-in-one detergent in tablet or capsule for washing – press,,SET”, then go to step 7. Open tap operation on the next page.

The symbol

on display will be lit. If you prefer to use gel or po-

wder detergent for washing, press ,,<” or ,,>”, then go to step 6. Rinse

aid operation.

6. Rinse aid operation*
*If All-in-one detergent was chosen in the previous step, this step will be skipped by the appliance.
RINSE AID OPERATION
INSERT RINSE AID OK = DONE
IN THE DISPENSER OK = DONE

35 25
MAX

1. Open the dispenser B by pressing and pulling up the tab on the lid. 2. Carefully introduce the rinse aid as far as the maximum (110 ml) re-
ference notch of the filling space A – avoid spilling it. If this happens, clean the spill immediately with a dry cloth. 3. Press the lid down until you hear a click to close it. 4. Confirm operation by pressing,,SET” button.
NEVER pour the rinse aid directly into the tub.
Setting rinse aid level (not necessary when using tablets/capsules) The rinse aid dosage can be adjusted to the detergent used. The lower the setting, the less rinse aid is dispensed. The factory setting is for (5) level. To change, follow instructions in section “SETTINGS / MENU”.

8. First cycle operation

FIRST CYCLE OPERATION

Before normal use of appliance it is recommended to run Intensive cyc-

le first, to calibrate the appliance.
REMEMBER TO RUN THE
OK = EXIT Insert a detergent into dispenser

INTENSIVE

CYCLE OK = EXIT

chamber B (see below), then press ,,SET” button.

WITH

EMPTY

BASKETS OK = EXIT

Intensive cycle will be selected automaticly. Press,,START” button

and close the appliance door.

COMPLETE OK =

EXIT

This first cycle can be up to 20

minutes longer as a result of the

THE

FIRST

SET OK

UP = EXIT

automatic calibration process.

After this process the appliance is ready for normal use.

7. Open tap operation
OPEN TAP OPERATION
OPEN THE OK = DONE
WATER TAP OK = DONE
Check water tap is open. If closed, open it then confirm by pressing ,,SET” button.

ADDING A DETERGENT
Only use detergent which has been speci cally designed for dishwashers.
To achieve the best washing and drying results, the combined use of detergent, rinse aid liquid and refined salt is required. We recommend using detergents that do not contain phosphates or chlorine, as these products are harmful to the environment.
Good washing results also depend on the correct amount of detergent being used. Exceeding the stated amount does not result in a more effective wash and increases environmental pollution. The amount can be adjusted to the soil level. In the case of normally soiled items, use approximately either 35g (powder detergent) or 35ml (liquid detergent) and additional tea spoon of detergent directly inside the tub. If tablets are used, one tablet will be enough. If the crockery is only lightly soiled or if it has been rinsed with water before being placed in the dishwasher, reduce the amount of detergent used accordingly (minimum 25 g/ml) e.g. skip the powder/gel putted inside the tub.

To open the detergent dispenser, press button A. Introduce the detergent into the dry dispenser B only. Place the amount of detergent for pre-washing directly inside the tub. B
1. When measuring out the deter- A gent refer to the mentioned earlier information to add the proper quantity. Inside the dispenser B there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the closing device is secured in place.
The detergent dispenser automatically opens up at the right time according to the program.
If you are using a All-in-one detergents, we recommend that you add salt in any case, especially if the water is hard or very hard (follow the instructions given on the packaging).

ADVICE AND TIPS

TIPS Before loading the baskets, remove all food residues from the crockery and empty the glasses. You do not need to rinse beforehand under running water. Arrange the crockery so that it is held in place firmly and does not tip over; and arrange the containers with the openings facing downwards and the concave/convex parts placed obliquely, thus allowing the water to reach every surface and flow freely. Warning: lids, handles, trays and frying pans do not prevent the sprayer arms from rotating. Place any small items in the cutlery basket. Very soiled dishes and pans should be placed in the lower basket because in this sector the water sprays are stronger and allow a higher washing performance. After loading the appliance, make sure that the sprayer arms can cotate freely.
HYGIENE To avoid odour and sediment which can be accumulated in the dishwasher please run a high temperature program at least once a month. Use a tea spoon of detergent and run it without the loading to clean your appliance.

UNSUITABLE CROCKERY · Wooden crockery and cutlery. · Delicate decorated glasses, artistic handicraft and antique crockery.
Their decorations are not resistant. · Parts in synthetic material which do not withstand high temperatures. · Copper and tin crockery. · Crockery soiled with ash, wax, lubricating grease or ink. The colours of glass decorations and aluminium/silver pieces can change and fade during the washing process. Some types of glass (e.g. crystal objects) can become opaque after a number of wash cycles too.
DAMAGE TO GLASS AND CROCKERY · Only use glasses and porcelain guaranteed by the manufacturer as
dishwasher safe. · Use a delicate detergent suitable for crockery · Collect glasses and cutlery from the dishwasher as soon as the wash
cycle is over.

LOADING THE RACKS
CUTLERY RACK
The third rack was designed tohouse the cutlery. Arrange the cutlery as shown in the figure. A separate arrangement of the cutlery makes collection easier after washing and improves washing and drying performance.
Knives and other utensils with sharp edges must be positioned with the blades facing downwards.
The geometry of the rack makes it possible to place such small items as coffee cups in the area in the middle.

The cutlery basket is equipped with two sliding side trays to make the most of the height of the space below and enable the loading of high items into upper rack.

UPPER RACK
Load delicate and light dishes:glasses, cups, saucers, low salad bowls. The upper rack has tip-up supports which can be used in a vertical position when arranging tea/ dessert saucers or in a lower position to load bowls and food containers.
(loading example for the upper rack)
FOLDABLE FLAPS WITH ADJUSTABLE POSITION The side foldable flaps can be positioned at three different heights to optimize the arrangement of crockery inside the rack. Wine glasses can be placed safely in the foldable flaps by inserting the stem of each glass into the corresponding slots. For optimum drying results incline the foldable flaps more. To change the inclination, pull up the foldable flap, slide it slightly and position it as you wish.

ADJUSTING THE HEIGHT OF THE UPPER RACK The height of the upper rack can be adjusted: high position to place bulky crockery in the lower basket and low position to make the most of the tip-up supports by creating more space upwards and avoid collision with the items loaded into lower rack. The upper rack is equipped with a Upper Rack height adjuster (see figure), without pressing the levers, lift it up by simply holding the rack sides, as soon as the rack is stable in its upper position. To restore to the lower position, press the levers A at the sides of the rack and move the basket downwards. We strongly recommend that you do not adjust the height of the rack when it is loaded. NEVER raise or lower the basket on one side only.

LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should ideally be placed at the sides to avoid interferences with the spray arm. The lower rack has tip-up supports which can be used in a vertical position when arranging plates or in a horizontal position (lower) to load pans and salad bowls easily.
(loading example for the lower rack)

DYNAMIC CLEAN IN LOWER RACK Dynamic Clean uses the special water jets in the rear of cavity to wash more intensively the high dirty items. Placing the pots/casseroles faced to the Dynamic Clean® component please activate the DYNAMIC CLEAN on the panel. The lower rack has a Dynamic Clean, a special pull-out support in the rear of the rack that can be used to support frying pans or baking pans in upright position, thus taking up less space. How to use Dynamic Clean: 1. Adjust the Dynamic Clean area (G)
folding down the rear plate holders to load pots. 2. Load pots and casseroles inclined vertically in Dynamic Clean area. Pots have to be inclined towards the power water jets.

GLASS CARE Dedicated accessory that allows you to safely store different types of stem glasses in the lower rack. It enables cleaning & drying results by allowing an optimised and stable positioning of the glasses.

23
1
1 2
3
B A

SELECTING A CYCLE AND OPTIONS

The list of available cycles and options can be found in Cycle Table on next page. Eco cycle is selected by default. If you want to have Last Used cycle selected by default, you can change it in ,,Settings Menu”.

It is possible to select a cycle by pressing 1 of 6 cycles direct access buttons or by pressing ,,Extra Cycles” button repeatedly. When the last one is reached a further press goes back to the first.

Press cycle button to choose cycle in accordance with the level

of soiling of the dishes and with Cycle Table. Information will be

shown on the display:

ECO CYCLE

1. Indicators

2. Name of the selected cycle

3. Vertical bar showing the position of the extra cycle list only

4. Energy consumption of the selected cycle

5. Water consumption of the selected cycle

50°

4:05h

POWER CLEAN

Three seconds after selecting a cycle, its time and temperature will be displayed

(if available).

Press ,,INFO” button to display a brief description of the cycle and its water / energy consumption.

NORMALLY SOILED CROCKERY. STANDARD PROGRAM,

WATER

ENERGY

MODIFYING A RUNNING PROGRAM If a wrong program was selected, it is possible to change it, provided that it has only just begun: open the door, press and hold the ,,ON/OFF”
button, the machine will switch off. Switch the machine back on using the ,,ON/OFF” button and select the new wash cycle and any desired options; start the cycle by pressing the,,START” button and closing the door.
TO PAUSE THE CYCLE (ADDING EXTRA ITEMS) Open the door and place the crockery inside the dishwasher, (beware of HOT steam!). Press,,START” button and close the door within 4 sec. to resume the cycle from the point at which it was interrupted.
ACCIDENTAL INTERRUPTIONS If the door is opened during the wash cycle, or if there is a power cut, the cycle stops. To resume the cycle from where it was interrupted, press the,,START” button and close the door within 4 sec.
After the cycle finishes, there is an acustic signal and the dispaly shows:
CYCLE FINISHED
On the display additional information can be shown: · ADD SALT – refill salt reservoir. · ADD RINSE AID – refill rinse aid. · DEGREASE AND CLEAN MACHINE WE RECOMMEND WPRO –
every 50 cycle, will be recommended to use the WPRO cleaner (according to instruction on the consumable).

During the selection phase the,,START” LED blinks.

Additional options are available for most cycles (see ,,Options and Settings” section). When any option is selected, its name is shown on the display on the right.

50°

4:05h

DYNAMIC CLEAN

If more than one option is selected one bullet point for each option is displayed.

Each option name is displayed for 3 sec.

with its bullet point fulled.

Open appliance door (beware of hot steam!) and unload the racks, starting from the lower rack first. If it is needed to refill salt reservoir or rinse aid dispenser, it is recommended to do this operations right before start of the next cycle.

When the cycle and option selection is complete, press,,START” button and close the door within 4 seconds to start chosen cycle.

After 10 minutes the appliance switches off.

CYCLES TABLE

Drying phase

CYCLE

Available options *

Detergent dispenser
B TUB

Duration of wash cycle
(h:min)*

Water

Energy

consumption cosumption

(l/cycle) (kWh/cycle)

ECO 50°

TABLET, START DELAY, DYNAMIC CLEAN, BOOST

DYNAMIC SENSOR 50-60°

TABLET, START DELAY, MULTIZONE, DYNAMIC CLEAN, BOOST

PROFESSIONAL 65°

TABLET, START DELAY, MULTIZONE, DYNAMIC CLEAN

DAILY 50°

TABLET, START DELAY, MULTIZONE

1H WASH & DRY 55°

TABLET, START DELAY, MULTIZONE

FAST 30′ 50°

TABLET, START DELAY, MULTIZONE

EXTRA CYCLES – available by pressing button
