The Carry Bag is a compact and durable accessory designed to
provide sturdy protection for your device. Made of Nylon/air mesh
fabric, it features an adjustable padded shoulder strap for maximum
comfort. The functional pockets inside offer an optimal solution
for transporting your laptop and accessories together in one case,
providing convenience and productivity on the go.

Dimensions: L 405 x W 330 x D 100mm
Weight: 1.335kg
Main Material: Nylon, air mesh fabric
SKU ID: GMBCX7

A140 Battery

The A140 Battery is designed with a physical battery indicator
that consists of green LEDs. The LEDs indicate the relative
percentage of the battery charge, with fully discharged indicated
by no glowing LEDs.

Battery Type: Li-ion
Voltage: 10.8V
Capacity: Typical 3220mAh ; min. 3120mAh
Dimensions: L 144 x W 72.4 x D 13.2 mm
Weight: 200g
SKU ID: GBM3X3

Dual Bay Battery Charger

The Dual Bay Battery Charger is an external charger designed to
charge up to 2 batteries simultaneously. It provides the benefit of
charging and storing the 2 main batteries together when space or
power sockets are limited. The charger supports high capacity
batteries.

AC Input: 100V~240V
DC Output: 13.05V, 2.4A Max.
Number of charge bay: 2 Bay
Dimensions: L 160 x W 180 x H 72.5mm
Weight: 1.2kg
SKU ID: GCMCEE (EU Power Cord), GCMCUE (US Power Cord), GCMCKE
(UK Power Cord), GCMCCE (CHN Power Cord), GCMCTE (TW Power
Cord)

A140 Multi-Bay Battery Charger 8-Bay

The A140 Multi-Bay Battery Charger is designed to charge
multiple battery packs simultaneously, providing users with an
efficient charging solution.

SKU ID: GCECEJ (EU Power Cord), GCECUJ (US Power Cord), GCECKJ
(UK Power Cord), GCECAJ (AU Power Cord)

65W AC Adapter with Power Cord

The 65W AC Adapter is designed to power the device and charge
its internal battery from an AC power source. It comes with a
country-specific power cord that fits the local power outlet in
your designated country.

Input: 100V-240V, 50~60Hz, 1.5A
Output: 19V, 3.42A, 65W
Dimensions: L 108.3 x W 46.3 x H 30mm
Weight: 250g
Input cable length: 1830mm
Output cable length: 1500mm
SKU ID: GAA6E5 (EU Power Cord), GAA6U5 (US Power Cord), GAA6K5
(UK Power Cord), GAA6A5 (AU Power Cord), GAA6C5 (CHN Power Cord),
GAA6T5 (TW Power Cord)

90W MIL-STD-461 AC Adapter

The 90W MIL-STD-461 AC Adapter has passed military standards and
testing specifications to ensure that it meets the requirements for
the control of electromagnetic interference. It is designed to
power the device and charge its internal battery.

Input: 100V-240V, 1.5A 50~60Hz
Output: 19V, 4.74A, 90W
Dimensions: L 147 x W 73mm x H 45.5mm
Weight: 750g (without power cord)
Input cable length: 1830mm
Output cable length: 1200mm

Product Usage Instructions:

Carry Bag:

To use the Carry Bag, follow these steps:

Open the Carry Bag.
Place your device inside the bag.
Adjust the padded shoulder strap to your desired length.
Close the bag securely.

A140 Battery:

To use the A140 Battery, follow these steps:

Insert the A140 Battery into your device.
Observe the physical battery indicator with green LEDs.
The glowing LEDs indicate the relative percentage of the
battery charge.
If no LEDs are glowing green, it means the battery is fully
discharged.

Dual Bay Battery Charger:

To use the Dual Bay Battery Charger, follow these steps:

Connect the charger to a power source using the provided power
cord.
Insert up to 2 batteries into the charger’s bays.
Wait for the batteries to charge. The charger supports high
capacity batteries.
Once the batteries are fully charged, remove them from the
charger for use.

A140 Multi-Bay Battery Charger 8-Bay:

To use the A140 Multi-Bay Battery Charger 8-Bay, follow these
steps:

Connect the charger to a power source using the appropriate
power cord.
Insert multiple battery packs into the charger’s bays.
Wait for the battery packs to charge simultaneously.
Once the battery packs are fully charged, remove them from the
charger for use.

65W AC Adapter with Power Cord:

To use the 65W AC Adapter with Power Cord, follow these
steps:

Connect the AC adapter to an AC power source.
Plug the power cord into the AC adapter and then into a power
outlet.
Connect the other end of the power cord to your device.
The adapter will power the device and charge its internal
battery.

90W MIL-STD-461 AC Adapter:

To use the 90W MIL-STD-461 AC Adapter, follow these steps:

Connect the AC adapter to an AC power source.
Plug the power cord into the AC adapter and then into a power
outlet.
Connect the other end of the power cord to your device.
The adapter will power the device and charge its internal
battery while meeting electromagnetic interference
requirements.

View Fullscreen

GETAC A140 FULLY RUGGED TABLET ACCESSORY SPEC BROCHURE
Getac (UK) Ltd.
Getac House, Stafford Park 12, Telford, Shropshire TF3 3BJ, United Kingdom Tel : +44 (0) 1952 207 222 [email protected] I www.getac.com/en/ Copyright © 2022 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.

Rugged Mobile Computing Solutions
SEE MORE DO MORE.

CARRY BAG
FEATURES & BENEFITS
Constructed of durable Nylon/air mesh fabric and featuring an adjustable padded shoulder strap, this compact carry bag provides sturdy protection for your device while giving maximum comfort. The functional pockets inside offer the optimal solution to transport the laptop and needed accessories together in one case, delivering extra convenience and go-anywhere productivity to mobile professionals.
Product Information Dimensions : L 405 x W 330 x D 100mm Weight : 1.335kg Main Material : Nylon, air mesh fabric
SKU ID GMBCX7

A140 BATTERY
FEATURES & BENEFITS
The A140 battery is designed with a physical battery indicator. The value of the corresponding green LEDs indicate the relative percentage of the battery charge. The battery pack is fully discharged when you see no LEDs glowing green.
Product Information Battery Type : Li-ion Voltage : 10.8V Capacity : Typical 3220mAh ; min. 3120mAh Dimensions : L 144 x W 72.4 x D 13.2 mm Weight : 200g
SKU ID GBM3X3

DUAL BAY BATTERY CHARGER
FEATURES & BENEFITS
This external dual-bay main battery charger is designed to charge up to 2 batteries at the same time. It provides you the benefit of charging and storing the 2 main batteries together when there is limited space or power sockets. The dual-bay Charger supports the high capacity battery.
Product Information AC Input : 100V~240V DC Output : 13.05V, 2.4A Max. Number of charge bay : 2 Bay Dimension : L 160 x W 180 x H 72.5mm Weight : 1.2kg
SKU ID GCMCEE (EU Power Cord) GCMCUE (US Power Cord) GCMCKE (UK Power Cord) GCMCCE (CHN Power Cord) GCMCTE (TW Power Cord)

A140 MULTI-BAY BATTERY CHARGER 8-BAY
FEATURES & BENEFITS
The 8-bay multi-battery charger is designed to charge multiple battery packs simultaneously and provide users an efficient charging solution.

Product Information
Input Voltage : 100V-240V AC Operating Temperature : 5 ~35°C AC Input : 100V~240V AC, 4.2A , 50~60Hz DC Output : 19.5V, 16.9A * w / 330W AC Adapter Number of charge bays : 8 bays Dimension : L 465 x W 245 x H 95.3~111.3 mm Weight : 4.7 kg ,not including battery packs
SKU ID
GCECEJ (EU Power Cord) GCECUJ (US Power Cord) GCECKJ (UK Power Cord) GCECAJ (AU Power Cord)

65W AC ADAPTER WITH POWER CORD
FEATURES & BENEFITS
This adapter is designed to power the device and charge its internal battery from an AC power source. A country-specific power cord is included with the adapter to fit the local power outlet in your designated country.

Product Information
Input : 100V-240V, 50~60Hz, 1.5A Output : 19V, 3.42A, 65W Dimensions : L 108.3 x W 46.3 x H 30mm Weight : 250g Input cable length : 1830mm Output cable length. : 1500mm
SKU ID
GAA6E5 (EU Power Cord) GAA6U5 (US Power Cord) GAA6K5 (UK Power Cord) GAA6A5 (AU Power Cord) GAA6C5 (CHN Power Cord) GAA6T5 (TW Power Cord)

90W MIL-STD-461 AC ADAPTER
FEATURES & BENEFITS
This MIL-STD-461G AC adapter has passed the military standard and testing specification to ensure the conducted emissions (CE), conducted susceptibility (CS), radiated emissions (RE), and radiated susceptibility (RS) of the adapter can meet the requirements for the control of electromagnetic interference.
Product Information Input : 100V-240V, 1.5A 50~60Hz Output : 19V, 4.74A, 90W Dimensions : L 147 x W 73mm x H 45.5mm Weight : 750g (without power cord) Input cable length : 1830mm Output cable length : 1200mm
SKU ID GAAGE5 (EU Power Cord) GAAGU5 (US Power Cord) GAAGK5 (UK Power Cord) GAAGC5 (CHN Power Cord) GAAGT5 (TW Power Cord)

100W TYPE-C AC ADAPTER
FEATURES & BENEFITS
The 100W Type-C AC adapter as an additional charging solution to charge Getac rugged tablets and laptops with inherent USB type-C ports as well as the power delivery functionality. The Type-C adapter features a reversible connector type that reduces connector damages due to misuse.

Product Information
Input : 100V-240V Output : 20V, 5A, 100W Dimensions : L 140 x W 65 x H 25mm Weight : 326g Input cable length : 1830mm Output cable length : 1500mm
SKU ID
GAT1E1 (EU Power Cord) GAT1U1 (US Power Cord) GAT1K1 (UK Power Cord) GAT1A1 (AU Power Cord) GAT1C1 (CHN Power Cord) GAT1T1 (TW Power Cord)

CAPACITIVE HARD TIP STYLUS & TETHER
FEATURES & BENEFITS
This capacitive hard tip stylus is lightweight and easy to control, allowing smooth and comfortable interaction with the touch screen without worrying about scratching the screen or leaving fingerprints on it. The stylus comes with a detachable tether to keep the stylus attached to the tablet, so it doesn’t get lost or misplaced.
Product Information Stylus Dimensions : 123 x Ø9mm Tip size : 3.8mm ; Ø3.5mm Tether Length : 304 mm
SKU ID GMPSXJ

PROTECTION FILM
FEATURES & BENEFITS
This screen protection film is cut precisely to fit the A140 tablet and is easy to install and remove without leaving a sticky residue. With anti-glare coating, it not only protects the screen from the rigors of daily use but also helps to diffuse light on the screen and reduces glare, providing effortless readability for displayed information under common ambient lighting conditions.
Product Information Dimension : L 309.4 x W 173.95 x D 0.19mm
SKU ID GMPFXC

A140 ROTATING HAND STRAP WITH KICK STAND
FEATURES & BENEFITS
This wearable A140 Rotating Hand Strap allows you to carry your tablet in the palm of your hand. The hand strap is adjustable to fit virtually all hand sizes and it could be converted to a used-anywhere kickstand providing comfortable viewing and editing. When docking the A140 to the trolley dock (office dock), the A140 Rotating Hand Strap needs to be removed.
Product Information Nylon, Rubber, Steel Dimensions : L 480 x W 372 x D 8mm Weight : 186g
SKU ID GMHRX8

RUBBER HAND STRAP
This rubber hand strap provides instant support for users holding the tablet with one hand.
Product Information Material : Rubber Dimensions : L 144 x W 72.4 x D 13.2mm Weight : 200g SKU ID GMHSXB

2-POINT SHOULDER STRAP
FEATURES & BENEFITS
The 2-point shoulder strap provides a quick and comfortable handsfree carrying option of the A140. The strap length is adjustable by using the slide adjusters for height. Also, it fits most body sizes for both cross-body and shoulder carry.
Product Information Length : 1590mm Main Material : Nylon SKU ID GMS2X6

4-POINT SHOULDER STRAP
FEATURES & BENEFITS
This shoulder harness has four snap hooks that attach to the D-rings on the four corners of the A140 and can be easily detached as well. This wearable strap allows you to carry your tablet handsfree, which allows you to view the screen while working with two hands. In addition, the length of the strap can be adjusted freely using the slide adjusters to provide maximum comfort.
Product Information Nylon, Rubber, Steel Vest Dimensions : L 480 x W 372 x D 8mm Weight : 186g
SKU ID GMS4X2

A140 TROLLEY ( OFFICE ) DOCK
FEATURES & BENEFITS
A140 Trolley dock duplicates most of your computer’s ports and provides extra ports. With peripherals such as a keyboard, mouse, monitor, and printer all connected to the office dock, you have a handy work area on your desk or diagnostic environment. The adjustable latch also provides multiple viewing angles for the A140. This product consists of a base dock and an adapter. The two should be assembled before usage.

Product Information
Serial Port x 1 Display Port x 1 Microphone x 1 Audio Output x 1 DC in Jack x 1 USB x 3 LAN x 1 HDMI x 1 Printer Port x 1 * w / 90W AC Adapter
SKU ID
GDOFEU (EU Power Cord) GDOFUU (US Power Cord) GDOFKU (UK Power Cord) GDOFAU (AU Power Cord) GDOFCU (CHN Power Cord) GDOFTU (TW Power Cord)

GETAC RUGGED KEYBOARD
FEATURES & BENEFITS
The Getac Rugged Keyboard is designed with VESA and AMPS mounting capability that allow it to be placed firmly in the vehicle. It has gone through vigorous test that comply with MIL-STD 810G and IP65. It also features with 88 full sized keys, red LED backlight with five levels of brightness and impressive key response that will truly enhance user experience.

Product Information
Dimension : 307.7 x 194 x 32 mm Weight : 870g Compatibility : Windows 10 Pro, Windows 11 Pro Backlit : Red LED. five levels of brightness Coiled Cable Length : USB 2.0 interface, 1.83m

SKU ID
Getac Rugged Keyboard
GDKBU9 (US) GDKBC9 (UK) GDKBB9 (DE) GDKBD9 (FR)

Getac Rugged Keyboard with Smart card and USB 2.0
GDKBU6 (US) GDKBC6 (UK) GDKBB6 (DE) GDKBD6 (FR)

Getac Rugged Keyboard with Smart card and LF/HF RFID
GDKBU7 (US) GDKBC7 (UK) GDKBB7 (DE) GDKBD7 (FR)
