Heatcraft Pro3 Top Mount Packaged Refrigeration System User Guide (+ PDF)

AESTHETICS: Stucco-aluminum finish
PERFORMANCE:
- – Maximum vertical storage capacity
- – Ideal for holding temperature
- – Medium-temp air and electric defrost
- – Low-temp electric defrost
ENVIRONMENTALLY FRIENDLY: Pre-charged with R-513A (P1 cabinet)
& R-448A (P2 & P3 cabinet) refrigerant to meet CARB &
US Climate Alliance requirements
RELIABLE | DURABLE:
- – Liquid-line filter drier (Medium and large cabinet only)
- – Two-year parts warranty
ENERGY EFFICIENCY:
- – P1 units use single speed EC Evaporator motors
- – P2 & P3 units use 2 speed EC Evaporator motors
- – P2 & P3 units use single speed EC Condenser motors
  (except PT0046M uses PSC)
- – P2 & P3 units use a Microchannel condenser for higher
  efficiency & corrosion protection
EASE OF INSTALLATION:
- – Pre-charged with refrigerant
- – No refrigerant piping required
- – Evaporative condensate pan (indoor units only)
- – All units get a removable top panel with latches
- – All P1 & select P2 & P3 units come with a power
  cord
CONTROLS: Microprocessor control

Outstanding Features

– Energy Efficient Scroll/Recip. Compressors: Cabinet Size P1:
All Recips. Cabinet Size P2: 0046M-Recip All other units-Scrolls
Cabinet Size P3: All Scrolls
– Microchannel Coil on all DOE Compliant model sizes (Cabinet
Size P2 & P3)
– Unit Precharged with R-513A (P1 cabinet) & R-448A (P2
& P3 cabinet) for sustainability
– Energy Efficient Dual Speed EC Motor (Single speed EC for
Cabinet size P1)
– Durable Stucco Finish

Air & Electric Defrost – Medium Temperature/Cooler
(R-513A)

Model	Box Temperature
PT0024MAN#ESB	2,520
…	…

View Fullscreen

CC-PROTB | FEBRUARY 2023
PRO3 TOP MOUNT PACKAGED REFRIGERATION SYSTEM
Technical Guide
Now including DOE compliant models

PRO3 TOP MOUNT PACKAGED REFRIGERATION SYSTEM

TABLE OF CONTENTS

Nomenclature

Features & Benefits

Performance Data

4 Air & Electric Defrost

Medium Temperature

4 Electric Defrost

Low Temperature (R-448A)

AWEF Data

5 AWEF Medium & Low Temperature

Electrical Data

Replacement Parts

Dimensional Drawings

NOMENCLATURE

DESIGN ORIENTATION T = Top Mount

TEMPERATURE RANGE M = Medium L = Low

APPLICATION LOCATION N = Indoor T = Outdoor

EVAPORATOR MOTOR M = 2 Speed EC E = Fixed Speed EC

REVISION

P T 0097 M A T A M C A

PRODUCT LINE P = PRO3 Packaged Refrigeration System

BTU CAPACITY 0024 = 2,400 0027 = 2,700 0028 = 2,800 0032 = 3,200 0036 = 3,600 0042 = 4,200 0046 = 4,600 0062 = 6,200 0068 = 6,800 0069 = 6,900 0078 = 7,800 0097 = 9,700 0115 = 11,500

VOLTAGE A = 115/1/60 B = 208-230/1/60 C = 230/3/60

DEFROST A = Air E = Electric

PACKAGING C = Crate S = Standard

FEATURES & BENEFITS

The PRO3 Top Mount packaged refrigeration system combines evaporator and condensing unit into one unit expediting installation time and reducing refrigerant charge — saving time, money and energy.
This packaged system is designed to maximize storage space inside walk-in coolers or freezers and is ideal for small- to medium-sized restaurant and convenience store applications.
System is fully-assembled, evacuated, charged, run-tested and wired at the factory. No additional components are required.

AESTHETICS Stucco-aluminum finish
PERFORMANCE Maximum vertical storage capacity Ideal for holding temperature Medium-temp air and electric defrost Low-temp electric defrost
ENVIRONMENTALLY FRIENDLY Pre-charged with R-513A (P1 cabinet) & R-448A
(P2 & P3 cabinet) refrigerant to meet CARB & US Climate Alliance requirements
RELIABLE | DURABLE Liquid-line filter drier (Medium and large
cabinet only) Two-year parts warranty

ENERGY EFFICIENCY P1 units use single speed EC Evaporator motors P2 & P3 units use 2 speed EC Evaporator motors P2 & P3 units use single speed EC Condenser
motors (except PT0046M uses PSC) P2 & P3 units use a Microchannel condenser for
higher efficiency & corrosion protection
EASE OF INSTALLATION Pre-charged with refrigerant No refrigerant piping required Evaporative condensate pan (indoor units only) All units get a removable top panel with latches All P1 & select P2 & P3 units come with a
power cord
CONTROLS Microprocessor control

OUTSTANDING FEATURES

Removable Top Panel with latches for ease of service Standard across all
cabinet sizes

Energy Efficient Scroll/Recip. Compressors: Cabinet Size P1: All Recips. Cabinet Size P2: 0046M-Recip
All other units-Scrolls Cabinet Size P3: All Scrolls

Microchannel Coil on all DOE Compliant model sizes (Cabinet Size P2 & P3)

Unit Precharged with R-513A
(P1 cabinet) & R-448A (P2 & P3 cabinet) for
sustainability

Energy Efficient Dual Speed EC Motor (Single speed
EC for Cabinet size P1)

Durable Stucco Finish

PRO3 TOP MOUNT PACKAGED REFRIGERATION SYSTEM

AIR & ELECTRIC DEFROST

Medium Temperature/Cooler (R-513A)
If model has a numerical value in the table below, the following statement applies: This refrigeration sy8s0te°FmAismdbeiesnigtned and c9e0r°tFifieAdmfobireunste in walk-9in5c°FooAlemrbaipepnltications 100°F Ambient

Model

Box Temperature

35°F

38°F

35°F

38°F

35°F

38°F

35°F

38°F

PT0024MAN#ESB

2,520

2,640

2,380

2,510

2,310

2,420

2,230

2,340

PT0028MAN#ESB 2,930

3,070

2,770

2,920

2,670

2,820

2,590

2,720

PT0032MAN#ESB

3,380

3,530

3,210

3,360

3,090

3,270

3,010

3,180

110°F Ambient

35°F 2,080 2,430 2,830

38°F 2,180 2,590 2,990

Medium Temperature/Cooler (R-448A)

Model
PT0046MAN#M§A PT0046MBN#M§A PT0068MB*#M§A PT0078MB*#M§A PT0097MB*#M§A PT0097MC*#M§A PT0115MB*#M§A PT0115MC*#M§A

80°F Ambient

35°F 4,640 4,820 7,120 8,240 9,980 10,030 11,830 12,070

38°F 4,910 5,140 7,460 8,660 10,390 10,450 12,490 12,570

90°F Ambient

35°F 4,410 4,550 6,770 7,760 9,560 9,730 11,510 11,580

38°F 4,660 4,820 7,150 8,270 10,100 10,190 12,160 12,080

95°F Ambient

Box Temperature

35°F

38°F

4,290

4,550

4,430

4,680

6,620

7,020

7,720

8,060

9,370

9,900

9,430

9,980

11,240

11,850

11,330

11,850

100°F Ambient

35°F 4,150 4,290 6,460 7,460 9,120 9,190 10,890 10,990

38°F 4,400 4,540 6,740 7,720 9,560 9,770 11,460 11,560

110°F Ambient

35°F 3,860 4,000 6,000 7,060 8,600 8,660 10,180 10,270

38°F 4,110 4,250 6,360 7,380 8,980 9,090 10,690 10,780

ELECTRIC DEFROST
Low Temperature/Freezer (R-448A)

Model
PT0027LB*EM§A PT0036LB*EM§A PT0042LB*EM§A PT0062LB*EM§A PT0062LC*EM§A PT0069LB*EM§A PT0069LC*EM§A

80°F Ambient
0°F -10°F -20°F 3,450 2,830 2,350 4,550 3,710 2,960 5,420 4,440 3,520 7,900 6,470 5,190 7,910 6,470 5,200 8,650 7,180 5,780 8,650 7,180 5,780

90°F Ambient

95°F Ambient

Box Temperature 0°F -10°F -20°F 0°F -10°F -20°F

3,270 2,730 2,230 3,200 2,680 2,210

4,360 3,570 2,800 4,250 3,460 2,740

5,210 4,220 3,390 5,100 4,110 3,230

7,670 6,170 4,870 7,450 6,030 4,830

7,610 6,170 4,870 7,440 6,030 4,830

8,350 6,860 5,600 8,150 6,680 5,500

8,360 6,860 5,610 8,160 6,690 5,500

100°F Ambient
0°F -10°F -20°F 3,110 2,590 2,110 4,150 3,340 2,690 4,890 3,980 3,170 7,130 5,880 4,710 7,290 5,880 4,710 7,850 6,500 5,220 7,850 6,500 5,220

110°F Ambient
0°F -10°F -20°F 2,960 2,430 2,010 3,860 3,120 2,480 4,570 3,670 2,900 6,810 5,480 4,340 6,810 5,480 4,340 7,390 6,030 4,960 7,390 6,040 4,960

Notes: # A = Air defrost, E = Electric defrost * N = Indoor, T = Outdoor § C = Crate, S = Standard
4

AWEF DATA MEDIUM TEMPERATURE
Walk-In Cooler (R-513A)
If model has a numerical value in the table below, the following statement applies: This refrigeration system is designed and certified for use in walk-in cooler applications

Model PT0024M PT0028M PT0032M

Indoor — — —

Walk-In Cooler (R-448A)

Model PT0046M PT0068M PT0078M PT0097M PT0115M

Indoor 5.61 5.61 5.61 5.61 5.61

Outdoor X X X
Outdoor X
7.60 7.60 7.60 7.60

AWEF DATA LOW TEMPERATURE
Walk-In Freezer (R-448A)
If model has a numerical value in the table below, the following statement applies: This refrigeration system is designed and certified for use in walk-in freezer applications

Model PT0027L PT0036L PT0042L PT0062L PT0069L

Indoor 2.04 2.11 2.17 2.32 2.38

Outdoor 2.89 2.94 2.98 3.08 3.13

Notes: X = Model not available in outdoor — = Model is not DOE AWEF compliant
5

PRO3 TOP MOUNT PACKAGED REFRIGERATION SYSTEM

ELECTRICAL DATA
All ModelsPlease consult AWEF table on page 27 to confirm DOE compliance per model

Model
PT0024MANEE§B PT0024MANAE§B PT0028MANEE§B PT0028MANAE§B PT0032MANEE§B PT0032MANAE§B PT0027LBNEM§A PT0036LBNEM§A PT0042LBNEM§A PT0046MANEM§A PT0046MBNEM§A PT0046MANAM§A PT0046MBNAM§A PT0068MBNEM§A PT0068MBNAM§A PT0078MBNEM§A PT0078MBNAM§A PT0027LBTEM§A PT0036LBTEM§A PT0042LBTEM§A PT0068MBTEM§A PT0068MBTAM§A PT0078MBTEM§A PT0078MBTAM§A PT0062LBNEM§A PT0062LCNEM§A PT0069LBNEM§A PT0069LCNEM§A PT0097MBNEM§A PT0097MCNEM§A PT0097MBNAM§A

Defrost
E A E A E A E E E E E A A E A E A E E E E A E A E E E E E E A

Voltage
115/1/60 115/1/60 115/1/60 115/1/60 115/1/60 115/1/60 208-230/1/60 208-230/1/60 208-230/1/60 115/1/60 208-230/3/60 115/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60

MCA

MOPD

Unit Amps

Evaporator CFM

Plug Supplied

Matching NEMA
Receptacle

9.9

8.2

190

YES

5-20R

9.9

8.2

190

YES

5-20R

10.2

8.4

180

YES

5-20R

10.2

8.4

180

YES

5-20R

11.6

9.5

180

YES

5-20R

11.6

9.5

180

YES

5-20R

8.5

7.1

330

YES

6-15R

10.9

9.2

550

YES

6-15R

12.4 20 10.4

550

YES

6-20R

12.9 20 10.9

330

YES

5-20R

7.4

6.3

330

YES

6-15R

12.9 20 10.9

330

YES

5-20R

7.4

6.3

330

YES

6-15R

9.3

8.0

550

YES

6-15R

9.3

8.0

550

YES

6-15R

9.7

8.2

500

YES

6-15R

9.7

8.2

500

YES

6-15R

9.4

8.0

330

—

10.9

9.2

550

—

12.4 20 10.4

550

—

9.3

8.0

550

—

9.3

8.0

550

—

9.7

8.2

500

—

9.7

8.2

500

—

19.5 30 16.5

825

—

14.7 20 12.6

825

—

19.8 30 16.7

825

—

14.0 20 12.1

825

—

14.5 20 12.3

610

YES

6-20R

12.3 15 10.5

610

—

14.5 20 12.3

610

YES

6-20R

Dimensions Figure
1 1 1 1 1 1 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 3 3 3 3 3 3 3

Aprox. Net Weight
Lbs. kg 90 41 90 41 92 42 92 42 94 43 94 43 215 98 220 100 225 102 195 88 195 88 195 88 195 88 215 98 215 98 220 100 220 100 230 104 235 107 240 109 230 104 230 104 245 111 245 111 275 125 275 125 275 125 275 125 260 118 260 118 260 118

Notes: § C = Crate, S = Standard
6

ELECTRICAL DATA
All Models (cont.)Please consult AWEF table on page 27 to confirm DOE compliance per model

Model
PT0097MCNAM§A PT0115MBNEM§A PT0115MCNEM§A PT0115MBNAM§A PT0115MCNAM§A PT0062LBTEM§A PT0062LCTEM§A PT0069LBTEM§A PT0069LCTEM§A PT0097MBTEM§A PT0097MCTEM§A PT0097MBTAM§A PT0097MCTAM§A PT0115MBTEM§A PT0115MCTEM§A PT0115MBTAM§A PT0115MCTAM§A

Defrost
A E E A A E E E E E E A A E E A A

Voltage
208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60 208-230/1/60 208-230/3/60

MCA

MOPD

Unit Amps

Evaporator CFM

Plug Supplied

Matching NEMA
Receptacle

12.3 15 10.5

610

—

18.5 25 15.6

825

YES

6-20R

15.9 25 13.6

825

—

18.5 25 15.6

825

YES

6-20R

15.9 25 13.6

825

—

19.5 30 16.5

825

—

14.7 20 12.6

825

—

19.8 30 16.7

825

—

14.0

12.1

825

—

14.5 20 12.3

610

—

12.3

10.5

610

—

14.5 20 12.3

610

—

12.3

10.5

610

—

18.5 25 15.6

825

—

15.9 25 13.6

825

—

18.5 25 15.6

825

—

15.9 25 13.6

825

—

Dimensions Figure
3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3

Aprox. Net Weight
Lbs. kg 260 118 260 118 260 118 260 118 260 118 295 134 295 134 295 134 295 134 280 127 280 127 280 127 280 127 280 127 280 127 280 127 280 127

Notes: § C = Crate, S = Standard
7

PRO3 TOP MOUNT PACKAGED REFRIGERATION SYSTEM

www.interlinkparts.com 800.686.7278

Right source. Right parts. Right now.
InterLinkTM is your link to a complete line of dependable and certified commercial refrigeration parts, accessories and innovative electronic controls for all Climate Control equipment. At InterLink, we provide our wholesalers with a comprehensive selection of product solutions and innovative technologies for the installed customer base. And every product is built to ensure the same high performance standards with which all Heatcraft Refrigeration Products brands are built — backed by a dedicated team to serve every customer need, delivering at the best lead times in the industry.
Dependable. Versatile. Courteous.
Finally, one simple source for all your replacement needs from a name you can trust.

REPLACEMENT PARTS

Model
Motor – Condenser Motor – Evaporator Fan blade – Condenser Fan blade – Evaporator Motor Mount – Condenser Motor Mount – Evaporator Contactor Temperature Controller Room Temp Sensor Defrost Temp Sensor Heater Limit Thermostat Defrost Heaters Fan Pressure Control Fan Temp Control Drain Line Heater Drain Line Heater T’stat Weatherhood

P1, 115/1 25308501 25319301 22900601 23100501 23101101 23101401 2252303 21301101 28913702 28913701
5708L 24751901
N/A N/A N/A N/A N/A

P2, 115/1 25308501 25329001
5110E 22901901 23103301 23103301 2252303 21301101 28913702 28913701
5708L 24712101
N/A N/A N/A N/A N/A

Cabinet, Voltage/Phase

P2, 230/1

P3, 230/1

25322404

25329101

22901601

22901901

23106101

23103301

R034915200

21301001

28913702

28913701

5708L

4312F

4313F

28917302

N/A

5521R

24753401

28917401

59332801

50087601

P3, 230/3 25322404 25329101 22901601 22901901 23106101 23103301 2259996 21301001 28913702 28913701
5708L 4313F 28917302 5521R 24753401 28917401 50087601

DIMENSIONAL DRAWINGS
FIGURE 1 P1 CABINET DESIGN/INDOOR ONLY
14.25″ X 20.75″ PANEL OPENING REQUIRED FOR EVAPORATOR SECTION OF “P1″ CABINET SIZES.
9

PRO3 TOP MOUNT PACKAGED REFRIGERATION SYSTEM
DIMENSIONAL DRAWINGS
FIGURE 2 P2 CABINET DESIGN

* 17.5″
(44.5 cm)
4″ (10.16 cm)

24.75″ (62.84 cm)
52″ (132 cm)
28.5″ 72.4cm WITH WEATHERHOOD: 33.8″ (85.85 cm)

20″ 50.9cm

24.75″ (62.87 cm)
25″X25” PANEL OPENING REQUIRED FOR EVAPORATOR SECTION OF “P2″ CABINET SIZES. * – 23.5″ (59.69 cm) ON OUTDOOR MODELS WITH WEATHERHOOD
10

DIMENSIONAL DRAWINGS
FIGURE 3 P3 CABINET DESIGN
25″X38.5” PANEL OPENING REQUIRED FOR EVAPORATOR SECTION OF “P3″ CABINET SIZES. * – 25.5” (64.77 cm) ON OUTDOOR MODELS WITH WEATHERHOOD
11

2175 West Park Place Blvd. Stone Mountain, GA 30087 Phone: 800.537.7775 · Fax: 770.465.5900
heatcraftrpd.com
Since product improvement is a continuing effort, we reserve the right to make changes in specifications without notice. CC-PROTB-0223 | Version 002
©2023 Heatcraft Refrigeration Products LLC
