Opus Built In Ceiling Hood
Product Information: Manual Opus Built-In Ceiling Hood
The Manual Opus Built-In Ceiling Hood is a powerful and
efficient kitchen appliance designed to effectively remove smoke,
odors, and airborne grease particles from your cooking area. It
comes in two variants: VP-CH95BLK (black) and VP-CH95WHT
(white).
The hood operates in two modes – extraction mode and
recirculation mode. In extraction mode, indoor air is removed from
the kitchen and adjacent rooms through an exhaust pipe or chimney
to the outside. However, it is important to ensure adequate airflow
when using the extraction mode to prevent toxic gases from being
sucked back into the living spaces. If you exclusively use the hood
in recirculation mode, there are no airflow restrictions.
The installation of the hood requires proper preparation and
adherence to safety guidelines. It is recommended to connect the
hood to an extraction duct with an interior diameter of 150mm for
optimal performance. The dimensions and installation instructions
provided in the user manual should be followed carefully.
The product complies with European Directives, including
2014/30/EU (EMC), 2014/35/EU (LVD), 2011/65/EU (RoHS), and
2009/125/EC (ErP), ensuring its safety and environmental
compatibility.
Product Usage Instructions: Manual Opus Built-In Ceiling
Hood
- Ensure proper installation of the hood according to the
provided dimensions and guidelines. - If using the extraction mode, make sure there is adequate
airflow to prevent toxic gases from being sucked back into the
living spaces. Avoid simultaneous operation with open flue
combustion equipment unless sufficient air intake is
guaranteed. - If using the recirculation mode exclusively, there are no
airflow restrictions. - To switch the engine on and off, use the control panel and the
designated button. - For installation, follow these steps:
- If changing the air-outlet to another side, carefully follow
the instructions provided in the manual. - For ceiling installation, cut the indicated hole in the ceiling
and install the indicated screws and brackets onto the hood. - Push the extractor upwards until the brackets click open in the
false ceiling. If needed, use a screwdriver to help them click
open. - Tighten the screws securely to complete the installation.
- Adjust the length of the safety rope if necessary.
- Note: Install the ventilation pipe after adjusting the
extractor hood.
- If changing the air-outlet to another side, carefully follow
- Refer to the user manual for further information on control
panel functions, cleaning and care instructions, troubleshooting,
hints on disposal, warranty, and service.
Manual Opus Built-In Ceiling Hood
VP-CH95BLK VP-CH95WHT
CONTENT
Safety Instructions 2 Installation 4 Operation 8 Troubleshooting 10 Cleaning and Care 11 Hints on Disposal 11 Warranty & Service 11
TECHNICAL DATA
Item number Power supply
VP-CH95BLK VP-CH95WHT
220-240 V ~ 50/60 Hz
EN
DECLARATION OF CONFORMITY
This product is conform to the following European Directives: 2014/30/EU (EMC) 2014/35/EU (LVD) 2011/65/EU (RoHS) 2009/125/EC (ErP)
Page 1
EN
SAFETY INSTRUCTIONS
· Thank you for purchasing this cooker hood. Please read the instruction manual carefully before you use the cooker hood, and keep it in a safe place.
· The installation work must be carried out by a qualified electrician or competent person. Before you use the cooker hood, make sure that the voltage (V) and the frequency (Hz) indicated on the cooker hood are exactly the same as the voltage (V) and the frequency (Hz) in your home.
· The manufacturer and the agent will not bear any responsibility for the damage caused by inappropriate installation and usage.
· Never let children operate the cooker hood. · The cooker hood is for home use only. It is not suitable for barbecues, Roast shop
and commercial purposes. · The cooker hood and its filter mesh should be cleaned regularly in order to keep it
in good working order. · Before cleaning, switch the power off at the main supply. · Clean the cooker hood according to the instruction manual and keep the cooker
hood from the danger of burning. · Prohibit putting the cooker hood by fire. · If there is any fault with the appliance, please call the service department to request
a service engineer. · This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. · If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. · The instructions shall state the substance of the following: there shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room). · Do not flambé under the range hood. Accessible parts may become hot when used with cooking appliances.
Important Hints on Installation
· The air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room).
· Regulations concerning the discharge of air have to be fulfilled.
Page 2
Important notes about the extraction mode
WARNING Risk of poisoning from exhaust gases sucked back. Never operate the device in extraction mode simultaneously with an open flue appliance when there is not adequate airflow guaranteed.
Open flue combustion equipment (for example, gas, oil, wood or coal-fired heaters, tankless water heaters, water heaters) pulls combustion air from the room and runs it through an exhaust pipe or chimney to the outside. In the extraction mode, indoor air is removed from the kitchen and the adjacent rooms – without sufficient air intake this creates a vacuum. Toxic gases from the chimney or extraction flue can thereby be sucked back into the living spaces.
· Always ensure that a sufficient supply of fresh air is guaranteed and that the air can circulate.
· An air supply / extractor box alone does not ensure compliance with the limit value.
Safe operation is only possible when the negative pressure in the room where the appliance is located does not exceed 4 Pa (0.04 mbar). This can be achieved when the air required for combustion can flow through openings that are not closable, for example in doors, windows, in conjunction with an air supply/ extractor box or through other technical measures. In any case, consult a qualified chimney sweep who can assess the entire ventilation of your house and propose appropriate measures for adequate ventilation.
If the hood is used exclusively in the recirculation mode, unrestricted operation is possible.
WARNING Fire hazard from flying sparks. Only install equipment on a fireplace for solid fuels (for example, wood or coal), if a closed, non-removable cover is available.
EN
Page 3
EN
INSTALLATION
Preparation If you have an outlet to the outside, your cooker hood can be connected as below picture by means of an extraction duct (enamel, aluminium, flexible pipe or inflammable material with an interior diameter of 150mm)
· Before installation, turn the unit off and unplug it from the outlet. · The cooker hood should be placed at a distance of 65~150cm above the cooking
plane for best effect.
Installation (Vent outside)
Note: When the range hood and appliance supplied with energy other than electricity are simultaneously in operation, the negative pressure in the room must be not exceed 4 Pa (4 x 10-5 Bar).
Dimensions
Page 4
EN
Before installtion
If you want to change the air-outlet to another side, see below how to do this Remark: only do one 90-degree rotation
1. Take out the aluminum filter, then remove these 8 screws
2. When you want to turn the motor, you must also turn the carbon filter’s support kit& carbon filter.(If installed)
Page 5
EN
3. Install 8 screws at indicated places, then this step is done.
Ceiling installtion
1. Cut the indicated hole in the ceiling. 2. Install indicated 4 screws in & the four
You may need to create a frame to support the hood.
brackets onto the hood, but not too tight yet.
Page 6
EN
3.Install the hood into the ceiling. Push the extractor upwards until the brackets click open in the false ceiling. (see image 4)
4. If they don’t, use a screwdriver to push into the 4 holes in the lower corners of the hood to help them click open.
5.Tighten the screws now, installation is finished.
6.The hood with safety rope in the light panel; pressing this part can adjust the safety rope’s length.
Note: Note: The ventilation pipe should be installed after adjusting the extractor hood.
Page 7
EN
· When mounting a non-return valve, it must be ensured that the valve can be opened freely. If the valve cannot be opened freely, it can reduce the suction power and increase the noise from the extractor hood.
· If the extractor hood is used for recirculation and there is no external ventilation (exhaust air), it is important that the ventilation is not blocked or impaired, as this can damage the extractor hood, reduce capacity and increase noise. In addition, no non-return valve can be installed in recirculation mode.
· Charcoal filter is only required when installing in recirculation mode.
OPERATION
Control Panel and Button Functions
Switch the engine on and off.
The motor runs at low speed.
The motor runs at medium speed.
The motor runs at high speed.
Switch the light on and off.
RemarkIf you need extra strong power, you can long press the button “3” on the panel to enter Booster mode. The booster setting will run 5 mins max.; after 5 mins, the speed will turn back to 3rd speed.
Page 8
Remote Control
EN
1
Press button (1) to switch the motor on or off.
2
Press button (2) to decrease power or speed.
3
Press button (3) to increase power or speed.
4
Press the button (4) to turn the light on or off.
Press the key (5) when the power is on
to activate the timer mode. The pre-set
5
time for the timer is 5 minutes. When the timer has expired, the cooker hood
will automatically turn off.
To calibrate the remote control In standby mode, long press the on/off button on the hood panel for 3 seconds till it flashes, then immediately press the on/off button on the remote control to complete
· If the calibration was successful, an acoustic signal sounds. · If the calibration was not successful, the cooker hood switches to
standby mode.
Remark: The Sequences of speed: 1st speed, 2nd speed, 3rd speed & booster. Booster: the booster setting will run 5 mins max.; after 5 mins, the speed will turn back to 3rd speed.
Page 9
EN
TROUBLESHOOTING
Fault Light on, but fan does not work Both light and fan do not work
Serious Vibration of the unit
Suction performance not good
Cause
Solution
The fan blade is jammed. The motor is damaged.
Switch off the unit and repair by qualified service
personnel only.
light bulb burn.
Replace the bulb with correct rating.
Power cord loose.
Plug in to the power supply again.
The fan blade is damaged.
The fan motor is not fixed tightly.
Switch off the unit and repair by qualified service personnel only.
The unit is not hung properly on the bracket.
Too long distance between the unit and the cooking plane
Take down the unit and
check whether the bracket
is in proper location.
Ensure hood is between 65-150cm from hob and 150mm ducting is used.
Page 10
CLEANING AND CARE
Monthly Cleaning for Grease Filter
Clean the filter every month can prevent any risk of fire. The filter collects grease, smoke and dust, so the filter is directly affecting the efficiency of the cooker hood. If not cleaned, the grease residue (potential flammable) will saturate on the filter. Clean it with household cleaning detergent.
Annual Cleaning for Activated Filter
Apply solely to unit that installed as a recirculation unit (not vented to the outside). This filter traps odours and must be replaced at least once a year depending on how frequent the cooker hood is used.
Replacing carbon filter
1. Open the light panel 2. Take out the Alum. filter 3. Take out the carbon filter and place a new one.
Replacing Bulbs
1 Switch the unit off and unplug the appliance. 2 Remove the lamp cover by unscrewing the 2 screws. 3 Unscrew the incandescent bulb. Replace with the same type and rated bulb.
HINTS ON DISPOSAL
According to the European waste regulation 2012/19/EU this symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailled information about recycling of this product, please contact your local council or your household waste disposal service.
EN
Page 11
TECHNICAL DATA Type Material Installation width mm Ceiling Installation Control Type Recirculation Annual energy consumption (AEChood) Energy efficiency category Fluid dynamical efficiency (FDEhood) Fluid dynamical efficiency category Lighting efficiency (LEhood) Lighting efficiency category Grease separation Grease separation category Air flow Maximum air flow Qmax Airflow at boost setting
A-rated noise emission
Power consumption off (Po) Power consumption standby (Ps) Power Consumption lighting system (W) Connected load Illuminant Power consumption per illuminant unit Voltage / frequency Height Adjustment in mm Grease filter / material / dishwasher safe Carbon filter Installation material Instruction manual Dimension appliance HxWxD mm Weight net / gross kg
Ceiling Cooker Hood Stainless Steel & Glass
900
Touch & Remote Optional 41.4 kW/h A 32.7 A 20.0 lux/W C 77% C
254.5m³/hr 562.1m³/hr 603.5m³/h 751.1
47dB 65dB 71dB at boost
0.48W -W
9.0W 129W / LED 3 * 3W 220 240 V AC /50Hz 200 2 / aluminium / Optional
217 x 500 x 900 17 / 21
EN
Page 12
