CO2G-xx External Probe
Product Description
The External probe CO2G-xx is used for measuring the
concentration of CO2 in the air. The product is available in the
following model: Probe CO2G-10, with a range of (0 to 10,000)
ppm.
Technical Parameters
- Temperature dependency: (0 to 10,000) ppm
- Pressure dependency (1): t90 < 200 s
- Response time: 15 s (the measuring interval depends on the
settings of the instrument to which the probe is connected) - Operating relative humidity range: (0 to 95) % RH (without
condensation) - Operating barometric pressure range: (700 to 1100) hPa
- Probe connection: M12 circular connector
(1) … it is a residual dependency (the measured value is
automatically compensated to the current barometric pressure)
Dimensions
The CO2G-xx probe is manufactured by COMET SYSTEM, s.r.o.
Bezrucova 2901, 756 61 Roznov pod Radhostem, Czech Republic.
Installation
To install the probe, connect it to a newly purchased U2422
using an extension cable. Cables are available in 1 m (UWP001), 2 m
(UWP001-2), or 4 m (UWP001-4) lengths. The probe does not require
any special service or maintenance. It is recommended to
periodically verify the accuracy of measurement by calibration.
Important notice:
- If you want to connect this probe to a U2422 datalogger which
you have previously purchased with an older SN220 probe type, you
may need to upgrade the device firmware and change probe settings.
In this case, contact the service department. - If you want to connect this probe to any other Comet device,
first check www.cometsystem.com to see if this probe is suitable
for this device or what cables you will need. Older devices did not
support this type of probe!
Technical Support and Service
Technical support and service are provided by the distributor.
For contact information, see the warranty certificate.
Warning
Specifications are subject to change without notice. Please
refer to the warranty certificate for information on the
distributor and serial number.
External probe CO2G-xx for measuring of CO2 concentration in the air
PRODUCT DESCRIPTION
CO2G-xx probe with the I2C output is designed to measure carbon dioxide concentration in the air in chemically non-aggressive environments. The CO2 measurement is based on the dual wavelength NDIR principle, which automatically compensates for ageing effects. The probe is IP65 rated and the replaceable filter offer protection in harsh environment. It is designed for connection to COMET devices equipped with input for external CO2 probes. The probe is interchangeable, the calibration constants are saved in the internal memory of the probe.
List of models in production: Probe CO2G-10, range (0 to 10 000) ppm.
TECHNICAL PARAMETERS
· Carbon dioxide concentration: Range: Accuracy:
Temperature dependency:
Pressure dependency (1):
Response time:
(0 to 10 000) ppm
± (100 ppm + 5 % of measured value) at 25 °C and 1013 hPa
± (1 + measured value [ppm] / 1 000) [ppm/°C] in the temperature range (-20…45) °C
± 0.014 % of measured value [ppm] / hPa (referenced to 1 013 hPa)
t90 < 200 s
(1) … it is a residual dependency ( the measured value is automatically compensated to the current barometric pressure)
· Measuring interval:
15 s the measuring interval depends on the settings of the instrument to which the probe is connected
· Operating temperature range :
(-40 to +60) ºC
Operating relative humidity range: (0 to 95) % RH (without condensation)
Operating barometric pressure range: (700 to 1100) hPa
· Supply voltage: Current consumption:
Probe connection:
(3.3 to 5) V DC ± 5 % 67 mA typically during measurement, 170 µA between measurements
M12 circular connector
· Recommended calibration interval: 5 years
· Storage temperature: Storage relative humidity:
(-40 to +60) ºC (0 to 95) %RV (without condensation)
COMET SYSTEM, s.r.o. Bezrucova 2901
1
756 61 Roznov pod Radhostem, Czech Republic
Specifications are subject to change without notice
ie-snd-CO2G-01
· Electromagnetic compatibility: · Protection: · Sensor cover filter: · Working position: · Weight: · Material:
EN 61326-1 (tested with device) IP65 (probe with connected cable) PTFE Filtering ability 0.025 mm without restriction 35 g approx. body of probe Ertalyte, filtering cover PTFE
DIMENSIONS
COMET SYSTEM, s.r.o. Bezrucova 2901
2
756 61 Roznov pod Radhostem, Czech Republic
Specifications are subject to change without notice
ie-snd-CO2G-01
INSTALLATION
Connect the probe to your newly purchased U2422 using an extension cable (see optional accessories). Cables are available in 1 m (UWP001), 2 m (UWP001-2) or 4 m (UWP001-4) lengths. The probe does not require any special service or maintenance. We recommend you periodically to verify the accuracy of measurement by calibration.
Important notice:
if you want to connect this probe to a U2422 datalogger which you have previously purchased with an older SN220 probe type, you may need to upgrade the device firmware and change probe settings. In this case, contact the service department.
if you want to connect this probe to any other Comet device, first check www.cometsystem.com to see if this probe is suitable for this device or what cables you will need. Older devices did not support this type of probe!
TECHNICAL SUPPORT AND SERVICE
Technical support and service is provided by distributor. For contact see warranty certificate.
WARNING
· It is not recommended to use the probe for long time under condensation conditions.
· Don’t use the probe in chemically aggressive environments.
· Don’t connect or disconnect the probe cable while the device is turned on incorrect values could be recorded to the device memory.
· Don’t use and don’t store the probe without the sensor cover.
· The probe contains electronic components, it needs to liquidate them according to legal requirements.
COMET SYSTEM, s.r.o. Bezrucova 2901
3
756 61 Roznov pod Radhostem, Czech Republic
Specifications are subject to change without notice
ie-snd-CO2G-01
Warranty certificate
This product has three years warranty since the date of sale to the end user. Defects due defective materials, defective manufacturing or design will be repaired free of charge by the manufacturer. The location of repair is at manufacturer’s. No warranty is given to products operated in conditions not matching the conditions specified by the manufacturer in instruction manual. Also no warranty is given to products which were modified by the user, products with broken seal, products which were connected to power or input signals not matching the technical specification (Instruction manual). No warranty is given to consumables, e.g. batteries, fuses and eventual changes of parameters created by wear (influence of aggressive environment etc.).
Serial number: Sale date:
