R2DSPOT60 60W Mini Moving Head Spot

R2DSPOT60

60W Mini Moving Head Spot

User Manual

1. INTRODUCTION

Thank you for selecting the R2DSPOT60. This LED Moving Head is
equipped with one 60W high power white LED, making it extremely
bright. It offers DMX, Auto, Sound, Master/Slave modes and is ideal
for small clubs, bars, parties, etc. Please read the user manual
carefully before use to optimize the performance of this
product.

1.1 Unpacking

The following items are included in the box:

1 x R2DSPOT60
1 x Power Cord
1 x User Manual

Carefully unpack the carton and check the contents to ensure
that all parts are present and received in good condition. Contact
your supplier immediately and retain packing material for
inspection if any part is missing or damaged.

1.2 Safety Instructions

Warning!!! To reduce the risk of fire, electric
shock, or injury to persons, follow these important safety
instructions:

Caution! Avoid looking directly into the LED light beam at a
close distance!

1.3 Features

DMX, Auto, Sound, Master/Slave modes
60W high power white LED
Ideal for small clubs, bars, parties, etc.

1.4 Product Overview

The R2DSPOT60 is a 60W Mini Moving Head Spot that is extremely
bright and versatile in use.

2. SETUP

Control Panel

The control panel has DMX In/Out and Fuse/Power In.

2.1 Mounting

The Moving Head is fully operational in any mounting position,
hanging upside-down, side mounted, or set on a flat level surface.
However, safety cables must always be used when the unit is ceiling
or truss mounted. The safety cable must be capable of holding 10
times the weight of the fixture.

IMPORTANT!!! All fixtures must be connected to
circuits with a suitable Earth Ground.

2.3 AC Power

The R2DSPOT60 operates on AC 90-240V 50-60Hz and must be powered
directly from a switched circuit. This unit cannot be run on a
rheostat or dimmer circuit even if used solely for a 0% to 100%
switching.

3. OPERATION INSTRUCTIONS

3.1 Menu Map

The menu map allows you to scroll through the main menu, exit
from the current sub-menu, select the currently selected menu, or
confirm the current function value. It offers various options such
as DMX Address, DMX Mode, Speed Mode, Run Mode, Internal Program,
Sound Control, X Reverse, Y Reverse, Display Reverse, Reset
Default, and Home Position Setting.

3.2 DMX Channels

The R2DSPOT60 offers 5Ch and 15Ch DMX channels for various
functions such as Pan, Pan Fine, Tilt, Tilt Fine, XY Speed from
fast to slow, Dimmer 0-100%, Strobe closed, Strobe from slow to
fast, White (Open), Color1-7, Forward color wheel rotating from
fast to slow, Color wheel rotating stop, and Backward color wheel
rotating from slow to fast.

Follow the above instructions carefully to optimize the
performance of your R2DSPOT60. If you have any further questions or
concerns, please refer to the user manual or contact our customer
support team.

View Fullscreen

R2DSPOT60
60W Mini Moving Head Spot
User Manual

1. INTRODUCTION
Thank you for selecting this product. Equipped with one 60W high power white LED, this LED Moving Head is extremely bright. It offers DMX, Auto, Sound, Master/Slave. Ideal for small clubs, bars, parties, etc. To optimize the performance of this product, please read the user manual carefully before use. 1.1 Unpacking The following items are included in the box:
1 x R2DSPOT60 1 x Power Cord 1 x User Manual
Carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Contact your supplier immediately and retain packing material for inspection if any part is missing or damaged.
1.2 Safety Instructions
Warning!!! To reduce the risk of fire, electric shock, or injury to persons,
! follow these important safety instructions:
The product is for indoor use only. Always turn off, unplug power and allow fixture to cool before servicing. Ensure that fixture is properly grounded. Please keep this User Guide for future consultation. Always make sure that you are connecting to the proper voltage and that the line voltage you are connecting to is not higher than that stated on decal or rear panel of the fixture. Always disconnect from power before servicing or replacing fuse. Make sure power cord is never crimped or damaged.
Caution! Avaid looking directly into the LED light beam at a close distance!
1

1.3 Features
LED Spot moving head 1 color wheel: 7 colors + white, rainbow 1 Gobo wheel: 5 gobos + open, shaking 1 3-facet prism Motorized focus 4 working modes: DMX, Auto, Sound, Master/Slave DMX modes: 5/15 channels Pan : 540° Tilt: 270° Reverse Pan/Tilt movement 0-100% linear dimmer 1-25 fps strobe 4-button LED display
1.4 Product overview

2. SETUP

Control Panel

DMX In/Out Fuse/Power In

2.1 Mounting
The Moving Head is fully operational in any mounting position, hanging upside-down, side mounted, or set on a flat llevel surface, etc.

IMPORTANT!!! Safety cables must always be used when unit is celling or truss mounted. The safety cable must be capable of holding 10 times the weight of the fixture.

2.3 AC Power The fixture is designed to work on AC 90-240V 50-60Hz. All units must be powered directly from a switched circuit. This unit cannot be run on a rheostat or dimmer circuit even if used solely for a 0% to 100% switching.

WARNING!!! All fixtures must be connected to circuits with a suitable Earth Ground.

3. OPERATION INSTRUCTIONS

3.1 Menu Map
MENU DOWN UP ENTER

MENU DOWN UP ENTER

Scroll through the main menu or exit from the current sub-menu the currently selected menu or confirm the current function value Scroll through the menu list or decrease the value of the current function value Scroll through the menu list or increase the value of the current function

1 Addr 2 ChMd 3 SPMd 4 SLMd 5 SHMd
6 Soun 7 PAN 8 TIL 9 dISP 10 rFAC 11 Ad t
12 rST

DMX Address 001-512

DMX Mode

.=CH10

.=CH15

Speed Mode

.=Low

.=High

Run Mode

.=Master

.=Slave

Internal Program .=001

.=002

.=003

.=004

.=005

.=006

.=007

.=008

Sound Control .=OFF

.=ON

X Reverse

.=OFF

.=ON

Y Reverse

.=OFF

.=ON

Display Reverse .=OFF

.=ON

Reset Default .=OFF

.=ON

Home Position

Setting

Delt

P(PAN)

t(TILT)

C(Color)

g(Gobo)

F(Focus)

Reset Motor

10CH DMX mode 15CH DMX mode Low speed mode High speed mode
Show mode
Sound Activation mode
Clear PAN and TILT Home Position(3s) .=0-120 .=0-120 .=0-120 .=0-120 .=0-120

3.2 DMX Channels

5Ch 15Ch DMX Value Func on

1 000 – 255 Pan

000-255 Pan Fine

3 000 – 255 Tilt

000-255 Tilt Fine

5 000 – 255 XY Speed from fast to slow

000-255 Dimmer 0-100%

000-004 Strobe closed

005-250 Strobe from slow to fast

251-255 Strobe open

000-013 White (Open)

014-031 Color1

032-049 Color2

050-067 Color3

068-085 Color4

086-103 Color5 8
104-121 Color6

122-130 Color7

131-139 White (Open)

140-195 Forward color wheel rota ng from fast to slow

196-199 Color wheel rota ng stop

200-255 Backward color wheel rota ng from slow to fast

000-008 Open(White)

009-033 Gobo1

034-058 Gobo2

059-083 Gobo3

084-108 Gobo4

109-133 Gobo5

134-194 Gobo rainbow CW from fast to slow

225-255 Gobo rainbow CcW from slow to fast

000-009 No func on

010-129 Forward Gobo rota on from fast to slow 10
130-134 No rota on

135-255 Backward Gobo rota on from slow to fast

11 000-255 Focus 0 – 100%

000-007 No func on 12
008-127 Prism on

128-192 Gobo rota ng CW from fast to slow

193-255 Gobo rota ng CCW from slow to fast

000-007 No func on

008-047 Auto program 1

048-087 Auto program 2

088-127 Auto program 3 3 13
128-167 Auto program 4

168-207 Auto program 5

208-247 Auto program 6

248-255 Color & Gobo run to Sound

000-007 No func on

008-032 X/Y auto run 1

033-058 X/Y auto run 2

059-084 X/Y auto run 3

085-110 X/Y auto run 4

111-136 X/Y auto run 5

137-162 X/Y auto run 6

163-188 X/Y auto run 7

189-240 X/Y auto run 8

241-255 X/Y auto run to sound

51-100 6S for High speed mode

5 15 151-200 6S for Low speed mode (For fade movement effect)

251-255 6S to RESET the fixture

4. Specifications Source: 1 x 60W white LED Beam angle: 13° Power consumption: 80W Max. Power supply: 100~240V, 50-60Hz Dimensions: 195 x 145 x 280 mm Weight: 4.5 kg
IMPORTANT INFORMATION!
In order to optimize the recovery and recycling of the materials that old appliances contain and reduce the impact on human health and the environment, ensure that this product is recycled at the end of its life.
6
