HE-1800 PD Quartz Heaters HE-PD Serie
Quartz Heaters HE-PD Serie
The Quartz Heaters HE-PD Serie is an infrared wall-mounting
heater designed for both outdoor and indoor installations. It is
specifically created to provide localised heat through short-wave
infrared emissions, making it an ideal choice for smoking areas.
The product is available in two models, HE-1800 PD and HE-2400
PD.
Product Characteristics
- Made from aluminium and stainless steel
- Provides localised heat that warms people and solid
objects - Equipped with soft light lamps that reach maximum temperature
in a few seconds - Can be operated via handle, switch, or remote control
- Comes with a 3-meter presence detector that automatically stops
the heater when there is no movement detected for 30 seconds to
save energy - The presence detector can be disabled if desired
Installation
The Quartz Heaters HE-PD Serie can be installed on walls using
the provided wall anchor. It also comes with a swivelling support
to allow you to adjust the direction of the heat. The product is
ideal for use in bar and restaurant terraces.
Area of Influence
The area of influence of the Quartz Heaters HE-PD Serie depends
on the height, length, and width of the area to be heated. The
radiation intensity of the area to be heated is also a factor in
determining the area of influence. Please refer to the table in the
user manual for specific details.
Technical Characteristics
| Model | Voltage (V) | Power (W) | Absorbed current of bars (A) | Kind of bars | Type of remote control switch | Cable length (mm) | Insulation/Swivelling Protection | Colour | Weight (kg) | Dimensions L x W x H (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| HE-1800 PD | 230 | 1800 | 7.8 | Halogen | Tirador | 1900 | Class I / IP55 | Aluminum | 3.3 | 705x300x290 (with bracket) |
| HE-2400 PD | 230 | 1800 | 7.8 | Halogen | Tirador | 1900 | Class I / IP55 | Aluminum | 4.5 | 705x430x290 (with bracket) |
Product Usage Instructions
- Select the appropriate model based on the size of the area to
be heated and the radiation intensity of the area. - Install the heater on the wall using the provided wall anchor
or swivelling support. - Connect the heater to a power source.
- Turn on the heater using the handle, switch, or remote
control. - The presence detector will automatically stop the heater when
there is no movement detected for 30 seconds to save energy. If you
want to disable the presence detector, refer to the user manual for
instructions. - Adjust the direction of the heat using the swivelling support
if necessary.
QUARTZ HEATERS HE-PD Serie
HE-1800 PD
HE-2400 PD
Infrared wall-mounting heater for outdoor or indoor installations, especially designed to create comfort areas in outdoor enclosures, providing localised heat via short-wave infrared emissions. Ideal for smoking areas.
Characteristics: Manufactured from aluminium and stainless steel. Localised heat: it only warms people and solid objects. Soft light lamps that reach the maximum temperature in a few seconds. Operation by means of handle, switch or remote control. 3 meters presence detector. When the sensor does not detect movement for 30 seconds, the heater automatically stops in order to save energy. It is possible to disable the sensor.
INSTALLATION
APPLICATIONS
Remote control
Swivelling support
Control panel
Bar and restaurant terraces.
www.solerpalau.com
Quartz Heaters HE-PD
QUARTZ HEATERS HE-PD Serie
DIMENSIONS (mm)
4 x Ø8
B
120 98
A
Model
A
HE-1800 PD
300
HE-2400 PD
300
58 80
B
Wall anchor.
250
375
AREA OF INCLUENCE
ALTURA
ÁNGULO MONTAJE
LONGITUD
AMPLITUD
Radiation intensity of the area to
heat (W/m2)
125 100
75
125 100
75
Height (m)
2 2,3 2,7
2,6 2,9 3,5
HE-1800 PD
Radiation
Length (m)
Width (m)
intensity of the area to
heat (W/m2)
Height (m)
At an angle of 30° from the vertical
3,3
3,6
3,8
4,1
4,5
4,7
125
2,3
100
2,7
75
3,1
At an angle of 45° from the vertical
2,6
4,6
3
5,1
3,5
6,1
125
3
100
3,4
75
4
HE-2400 PD Length (m)
4,1 4,7 5,4
3,2 3,6 4,2
Width (m)
4 4,6 5,3
5,2 5,9 6,9
TECHNICAL CHARACTERISTICS
Model
Voltage Power Absorberd Number (V) (W) current of bars (A)
Kind of bars
HE-1800 PD 230
1800
7,8
HE-2400 PD 230
1800
7,8
1
Halogen
1
Halogen
Type of Remote switch control
Cable length (mm)
Tirador
·
1900
Tirador
·
1900
Insulation/ Swivelling Colour Weight Dimensions
Protection
(kg) L x W x H
(mm)
Class I / IP55 Class I / IP55
·
Aluminum
3,3
705x300x290 (with bracket)
·
Aluminum
4,5
705x430x290 (with bracket)
Quartz Heaters HE-PD
