CAF80DI Dual Zone Digital Air Fryer
Product Information
The Dual Zone Digital Air Fryer is a kitchen appliance designed
for cooking food using hot air circulation. It features two
separate cooking zones, allowing you to cook multiple dishes
simultaneously. The air fryer comes with preset cooking options for
various types of food, as well as manual temperature and time
adjustment settings. The fryer also has a dehydrate function for
drying food items. The product model is CAF80DI.
To ensure optimal cooking results, the air fryer should be
preheated for 15 minutes before use to remove any film on the
heating element. The fryer has a temperature range of 80-200°C and
a timer range of 1-60 minutes. The frying drawer can be removed
halfway through cooking to turn or shake the food items on the wire
rack for even cooking.
Product Usage Instructions
- Place the air fryer on a stable, flat, and heat-resistant
surface. Ensure that the air outlet (C5) is at least 15 cm away
from the wall. - Insert C2 into C3 and C6 into C7.
- Plug the power cable into a mains socket outlet.
- Place the food into C3 and/or C7.
- Slide C3 and/or C7 back into the product using the handles
(C4). - Press the power button to turn on the air fryer.
- Press the left drawer button (G7), L=R button (G10), or right
drawer button (G11) to select the desired drawer. - Press the desired preset button (G3) to set the cooking
program. - Press G6 to start cooking. The temperature and time can still
be adjusted if needed. - Alternatively, manually set the time and temperature following
these steps:- Press the timer up button (G4) or timer down button (G5) to set
the required time according to the food packaging. - Press the temperature up button (G2) or temperature down button
(G1) to set the required temperature according to the food
packaging.
- Press the timer up button (G4) or timer down button (G5) to set
- Press G6 to start cooking.
- Do not touch any hot parts of the drawers and tray. Use the
handle (C4) to move the drawer. - When the cooking timer ends, the air fryer will emit a beeping
sound. - Slide out C3 and/or C7 using C4. Be cautious of hot steam.
- If the food is not ready yet, slide C3 and/or C7 back into the
product using C4 and reset the timer and temperature. - Use kitchen tongs to remove the cooked food from C3 and/or
C7. - To ensure even cooking, remove the frying drawer halfway
through cooking and turn or shake the items on the wire rack. - Always make sure the air fryer is switched off when removing
the frying drawer. Reload it once the drawer is back in the fryer,
and it will resume cooking within 10 minutes.
Note: Always defrost frozen meat before cooking
in the air fryer.
Instruction Manual
Dual Zone Digital Air Fryer
Please read this manual before use and save for future reference.
MODEL: CAF80DI
PLEASE REGISTER YOUR NEW APPLIANCE AT WWW.COOKOLOGY.COM
KNOW YOUR AIRFRYER
Image C
USING YOUR AIRFRYER FOR THE FIRST TIME · Remove all packaging materials, labels and/or stickers. · Remove all the detachable parts, wash them in soapy water, then rinse with clean water and dry. · Assemble all the parts of the appliance and put in on a worktop or table (but not too close to the wall). · Plug in your air fryer. Don’t be alarmed if you see smoke or smell burning. This is the protective
film on the heating element. After 15 minutes it’ll be ready for use.
USER GUIDE: SAFEGUARDS · Check the socket is the correct voltage for your air fryer. · Never use your air fryer if the plug or cord is damaged. Purchase a replacement and have it fitted
by a professional electrician. · Never touch the hot surface of the fryer. Always use the handle or the button instead. · Only use your air fryer for its intended use. · Don’t allow the cord for your air fryer to hang over the edge of a table or worktop as it
could be pulled off. · Don’t let the air fryer sit near a gas or electric burner. Don’t put it in a heated oven. · Don’t sit the fryer beside flammable materials ie curtains, and don’t place anything on top of it. · Don’t leave unattended when in use. · Always supervise nearby children when your air fryer is in use. · Never immerse the air fryer in water. · When cleaning always unplug and allow to cool down before removing parts. · Make sure the frying drawer is positioned correctly before use. · The frying drawer can be cleaned in water but must be thoroughly dried before its next use. · Always ensure the frying drawer is fully closed as the airfryer will not work unless correctly
positioned · Always disconnect the air fryer when not in use. · Don’t let children aged eight or under use the air fryer. Older children cooking with it
should always be supervised by an adult. · The airfryer is intended to be used in domestic environments
FOOD GUIDELINES
Image G
FOOD PRESETS
The following chart showing the presets below is intended as a guide ONLY. The quantity, thickness or density of the food types may adjust cooking times.
Icons Pre-set Time(min) Temp. Time range Temperature Range
Fries 20 mins 200 1-60min
80-200
Chicken 25 mins 200 1-60min
80-200
Fish
10 mins 180 1-60min
80-200
Cake 12 mins 180 1-60min
80-200
Vegetables 16 mins 160 1-60min
80-200
Dehydrate 8H
60 1-24H
40-80
To ensure your food is evenly cooked, remove the frying drawer halfway through cooking and turn or
Tosheankseurteheyoituermfosoodnitsheevwenirley rcaocokk.ed, remove the frying drawer halfway through cooking and turn
or shake the items on the wire rack. AAlwlwayasysmmakaekesusruerethteheaiarirfrfyreyrerisisswswiticthcehdedofofffwwhehnenyoyuourermemovoevethtehefrfyriynigngdrdarwawere.r. Reload it once the Rderloaawdeirtiosnbcaeckthien dthraewfreyreirsabnadckitiwn itlhl estfarrytecroaonkdinitgwagilal sintawrtitchoinok1in0gmaignauitnesw.ithin 10 minutes.
USING THE AIRFRYER
Always defrost frozen meat before cooking in the air fryer.
The letter C and G refer to the images C and G
1. Place the product on a stable, flat and heat resistant surface. (i) Keep the air outlet (C5) at least 15 cm away from the wall.
2. Place C2 into C3. 3. Place C6 into C7. 4. Plug the power cable into a mains socket outlet. 5. Place food into C3 and/or C7. 6. Slide C3 and/or C7 back into the product using the handles C4. 7. Press the power button 8. Press the left drawer button G7, L=R button G10 or right drawer button G11, depending on which drawer
you wish to use. 9. Press the desired preset button G3 to set the programme and then G6 to start cooking. Temperature
and time can still be adjusted. Aternatively, set the time and tempeature manually following these steps:
– Press the timer up button G4 or timer down button G5 to set the required time according to the food packaging.
– Press the temperature up button G2 or temperature down button G1 to set the required temperature according to the food packaging.
(i) To preheat, select a drawer by pressing G7, G10 or G11. Then press the preheat button G9 and set the pre-heat settings to your preference by G1, G2, G4 and G5. Press the start/pause button G6 to start preheating for 5 minutes. (i) To use both drawers simultaneously with the same settings, press G10. (i) To use both drawers with different settings, follow steps 9-10 for each drawers and press the Sync button G8 to synchronise the end times. G9 stays on to indicate end time synchronisation is active.
10. Press G6 to start.
(i) Do not touch any hot parts of the drawers and tray. Use the handle to move the drawer When the timer ends, the product emits a beeping sound.
11. Slide out C3 and/or C7 using C4. (i) Be careful when sliding out the drawers, hot steam may escape.
12. Slide C3 and/or C7 back into the product using C4 and reset the timer and temperature if the food is not ready yet.
13. Remove the prepared food out of C3 and/or C7 using a kitchen tong.
To ensure your food is evenly cooked, remove the frying drawer halfway through cooking and turn or shake the items on the wire rack.
Always make sure the air fryer is switched off when you remove the frying drawer. Reload it once the drawer is back in the fryer and it will start cooking again within 10 minutes.
TROUBLESHOOTING
Problem
Possible Cause
Solution
The airfryer is not working and has no display
The appliance is not plugged into a Check your connection – connect the
socket
power cable to an earthed wall socket
The drawer s not correctly positioned
Check that your drawer clicks into place when inserting it into the housing.
The ingredients fried within the airfryer are not cooked
The drawer is to full
Put smaller batches of ingredients in the drawers
The temperature is set to low
Cook at a higher temperature
The preperation time was to short
Increase your cooking time
The ingredients are fried unevenly in the air fryer
Some ingredients need to be shaken halfway through the
cooking time
Ingredients that lie on top of or across each other may need to be shaken halfway through cooking.
I cannot slide the drawer into the appliance properly
The drawer is too full
Do not fill the basket beyond the MAX indication
Fried snacks are not crispy when they come out of the airfryer
The food you cooked needs to be prepared in a traditional deep fryer
Use oven snacks or lightly brush some cooking oil onto the snacks for a crisper
result
White smoke comes out of the airfryer
When you are frying ingredients that are greasy, a large amount of excess oil will
leak into the pan. The cooking oil will You are frying greasy ingredients produce white smoke and the pan may
heat up more than normal. This does NOT affect the appliance or your end
cooking results.
The airfryer still contains grease reisdues from your previous use
White smoke is caused by grease bulding up in the apppliance. We would
recommend cleaning the appliance before your next use
To ensure yoFurershfoinogdredisieentvseanrelyfriceod okedUs,irnegmFreosvheIntghreedifernytsinisgddiffrearewnter hAadldfwmoarye ctohorkoinuggohil ocrowoakteinr ign wanithd turn or
shake the itemunesvoennlytahned wnoitrceriprsayck.
to Frozen
the Fresh Ingredients or increase
cooking time
Always make sure the air fryer is switched off when you remove the frying drawer. Reload it once the drawer is back Iifnptrhoebflerymesr aanredsittiwll iollcsctuarrrtincgo,oykoinugcaangacionnwtaitchtiuns1a0tmheinlpu@tecso. okology.com
COOKING TABLE
The cooking times and temperatures in the below table are ONLY guidelines. Depending on your experience with cooking you may want to vary these settings according to your taste and the quantity you cook. Always check that your food is completely cooked before serving. If you are unsure, return it to the air fryer for a further cooking time period until it is fully cooked.
Food
Thin, frozen fries Thick, frozen fries
Potato Gratin Steaks
Pork Chops Burgers
Sausage Rolls Drumsticks Chicken Breast Spring Rolls Frozen Chicken
Nuggets
Min-Max Amount (grams)
300-400 300-400
500 100-500 100-500 100-500 100-500 100-500 100-500 100-400
100-500
Temperature
200c 200c 200c 200c 180c 180c 200c 200c 180c 200c
200c
Frozen Fish Fingers
100-400
200c
Frozen Bread/Crumbed Cheese Snacks
100-400
180c
Stuffed Vegetables
Cakes Quiche Muffins Sweet Snacks
100-400 300 400 300 400
160c
180c 180c 200c 160c
Time (Minutes)
15-20* 20-25* 20-25* 10-20 10-20 10-20 13-15 15-22 15-20 8-10*
Additional Info
10-15*
6-10
Use Oven Ready
8-10
10 10-15 20-22 15-18
20
Use Baking Tin
Use Baking Tin/Oven Dish
*Shake when half the cooking time has elapsed
To ensure your food is evenly cooked, remove the frying drawer halfway through cooking and turn or shake the items on the wire rack.
Always make sure the air fryer is switched off when you remove the frying drawer. Reload it once the drawer is back in the fryer and it will start cooking again within 10 minutes.
CLEANING AND MAINTENANCE
· Unplug and always allow the appliance to cool down completely before cleaning · Wash the wire rack, frying drawer and other accessories in hot soapy water · Never use an abrasive cleaner for the wire rack or frying drawer otherwise it
may remove the surface coating · Regularly wipe the oil from the main appliance with a warm cotton cloth and dry
thoroughly before use · Never immerse the appliance into water
Environmentally friendly disposal
Your air fryer contains electrical equipment which can be disposed of in an environmentally friendly way at your local tip (recycling centre).
WARRANTY
Your Cookology Appliance is covered by a 1 year guarantee from the date of purchase. If a fault develops during this period, please contact our customer service team to arrange support on making your claim. Please note: Upon receipt of your appliance, be sure to register your warranty by visiting our website and completing the form.
UK: Waste electrical products should not be disposed of with household waste. Please check with your local authority or retailer for recycling advice.
Cookology The Wright Buy Limited Unit 2 Piperell Way Haverhill, Suffolk CB9 8QW UNITED KINGDOM
Cookology Limited Ground Floor 7T1oLeonwseurreByaogugroftoSotdreiestevenly cooked, remove the frying drawer halfway through cooking and turn or Dsuhbalkine2th, DeOit2emP5s9o3n the wire rack. IRELAND Always make sure the air fryer is switched off when you remove the frying drawer. Reload it once the drawer is back in the fryer and it will start cooking again within 10 minutes.
