256815 Classic Flanger
Product Information
The Classic Flanger is an effects pedal designed for electric
guitars. It features controls for regeneration, delay time, width,
and speed. The pedal can be powered by a 9-V block battery or a
power adapter (both not included).
Product Usage Instructions
- Before using the pedal, carefully unpack and check for any
transportation damage. Keep the original packaging for future
use. - If transporting or storing the pedal, it is recommended to use
the original packaging or suitable packaging material to protect it
against vibration, dust, and moisture. - Connect your electric guitar to the input jack of the Classic
Flanger pedal. - Connect the output jack of the pedal to your amplifier or audio
interface. - Adjust the regeneration, delay time, width, and speed controls
according to your desired flanger effect. - If using a 9-V block battery, insert it into the designated
battery compartment on the pedal. Ensure the correct polarity. - If using a power adapter, connect it to the power input on the
pedal. Make sure to use a compatible power adapter. - Turn on your amplifier or audio interface, then activate the
Classic Flanger pedal by pressing the appropriate button or
switch. - Experiment with different settings and controls to achieve your
desired flanger effect. - To turn off the pedal, simply deactivate it by pressing the
button or switch again.
Please note that improper use of the Classic Flanger pedal may
result in personal injury or property damage. It is important to
read and follow all safety instructions provided in the user
manual.
User Manual
Classic Flanger
Effects pedal
Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de
01.09.2022, ID: 256815 (V3)
Table of contents
Table of contents
1 General information………………………………………………………………………………………………………………… 5 1.1 Further information…………………………………………………………………………………………………………… 6 1.2 Notational conventions…………………………………………………………………………………………………….. 6 1.3 Symbols and signal words………………………………………………………………………………………………… 7
2 Safety instructions……………………………………………………………………………………………………………………. 8 3 Features……………………………………………………………………………………………………………………………………. 10 4 Installation and starting up…………………………………………………………………………………………………. 11 5 Connections and operating elements………………………………………………………………………………. 13 6 Technical specifications……………………………………………………………………………………………………….. 14 7 Protecting the environment……………………………………………………………………………………………….. 16
3 Classic Flanger
Effects pedal
4 Classic Flanger Effects pedal
General information
1 General information
This user manual contains important information on the safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to another user, be sure that they also receive this manual. Our products and user manuals are subject to a process of continuous development. We there- fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de.
5 Classic Flanger
Effects pedal
General information
1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the following points:
Download
This manual is also available as PDF file for you to download.
Keyword search
Use the search function in the electronic version to find the topics of interest for you quickly.
Online guides
Our online guides provide detailed information on technical basics and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service
If you have any problems with the device the customer service will gladly assist you.
1.2 Notational conventions
This manual uses the following notational conventions:
6 Classic Flanger Effects pedal
General information
Letterings
The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are used in this manual.
Signal word DANGER!
NOTICE!
Meaning
This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided.
This combination of symbol and signal word indicates a pos- sible dangerous situation that can result in material and environmental damage if it is not avoided.
Warning signs
Type of danger Warning danger zone.
7 Classic Flanger
Effects pedal
Safety instructions
2 Safety instructions
Intended use
This device is intended to be used for sound processing of signals from musical instruments with electromagnetic pickups. Any other use or use under other operating conditions is con- sidered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual abilities and having corresponding knowledge and experience. Other persons may use this device only if they are supervised or instructed by a person who is responsible for their safety.
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specified in the chapter `Technical specifications’ of this user manual. Avoid heavy temperature fluctuations and do not switch the device on immediately after it was exposed to temperature fluctuations (for example after transport at low outside temperatures). Dust and dirt inside can damage the unit. When operated in harmful ambient conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by qualified service personnel at regular intervals to prevent overheating and other malfunction.
8 Classic Flanger Effects pedal
Safety instructions
NOTICE! External power supply The device is powered by an external power supply. Before connecting the external power supply, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly the user. Unplug the external power supply before electrical storms occur and when the device is unused for long periods of time to reduce the risk of electric shock or fire. NOTICE! Risk of fire due to incorrect polarity Incorrectly inserted batteries may destroy the device or the batteries. Ensure that proper polarity is observed when inserting bat- teries. NOTICE! Possible damage by leaking batteries Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period.
9 Classic Flanger
Effects pedal
Features
3 Features
n Effects pedal for electric guitars n Flanger n Regeneration, Delay Time, Width and Speed controls n Power supply via 9-V block battery or power adapter (both not included)
10
Classic Flanger Effects pedal
Installation and starting up
4 Installation and starting up
Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards.
Handle the device with care. Do not try to disassemble or repair the device yourself if it should not work. Do not use solvents such as alcohol to clean the device.
Power supply
You can either use a 9 V battery or the DC 9 V connection for an external power supply. Before connecting, check for correct polarity.
When you do not use the pedal unplug the instrument cable from the input jack. Otherwise, the battery will be discharged.
Classic Flanger Effects pedal
11
Installation and starting up
Changing the battery
To insert or change the battery, disconnect a possibly used power adapter from the mains socket. Turn the pedal over, press lightly on the battery compartment cover and slide it down- wards in the direction of the arrow. Remove the back cover. Insert/replace the 9-V block bat- tery paying attention to the polarity markings and place the cover again into its original posi- tion until it locks.
NOTICE! Risk of fire due to incorrect polarity Incorrectly inserted batteries may destroy the device or the batteries. Ensure that proper polarity is observed when inserting batteries.
NOTICE! Possible damage by leaking batteries Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period.
12
Classic Flanger Effects pedal
Connections and operating elements
5 Connections and operating elements
ö#$%
&
*
‘
)
(
1 [REGEN] | turn this control to set the regeneration of the effect.
2 [DELAY TIME] | turn this control to set the delay time of the effect in a range from 0.9 ms to 6.4 ms.
3 [WIDTH] | turn this control to set the sound width of the effect.
4 [SPEED] | turn this control to set the speed of the effect in a range from 0.4 Hz to 8 Hz.
5 [DC 9V] | connection for the external power supply with 9 V DC. When an external power supply is used, the battery supply is cut off automatically.
6 [IN] | 1/4″ jack socket to connect instruments
7 [TRUE BYPASS] | foot switch for enabling or disabling the pedal function
8 This LED lights when the effects pedal is used. When the LED is off or dim while the effects pedal is used, the battery is exhausted and must be replaced.
9 [OUT] | 1/4″ jack socket to connect an amplifier
Classic Flanger Effects pedal
13
Technical specifications
6 Technical specifications
Input connections
Input impedance Output connections Output impedance Delay time Speed range Current consumption Power supply Power adapter
Battery Degree of protection Dimensions (W × H × D)
Power supply Instrument Amp
Secondary current Secondary voltage Polarity
14
Classic Flanger Effects pedal
Socket for power adapter 1/4″ jack socket 500 k 1/4″ jack socket 10 k 0.9 ms to 6.4 ms 0.4 Hz to 8 Hz 14 mA External power adapter, 100 – 240 V 50/60 Hz 200 mA 9 V Centre negative 9-V block battery IP20 97 mm × 55 mm × 120 mm
Weight Ambient conditions
Further information Flanger Chorus Phaser includes power supply includes battery
Temperature range Relative humidity
390 g 0 °C…40 °C 20 %…80 % (non-condensing)
yes no no no, optionally available (item no. 409939) no, optionally available (item no. 417473)
Technical specifications
Classic Flanger Effects pedal
15
Protecting the environment
7 Protecting the environment
Disposal of the packaging mate- rial
For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose these materials with your normal household waste, but make sure that they are fed to a recovery. Please follow the notes and markings on the packaging.
Disposal of batteries
Batteries must not be disposed of as domestic waste or thrown into fire. Dispose of the bat- teries according to national or local regulations regarding hazardous waste. To protect the environment, dispose of empty batteries at your retail store or at appropriate collection sites.
16
Classic Flanger Effects pedal
Protecting the environment
Disposal of your old device
This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version. Do not dispose with your normal household waste.
Dispose this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility.
Classic Flanger Effects pedal
17
Notes
18
Classic Flanger Effects pedal
Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de
