Bike Rack
Product Information: The product being referred to in the
user manual is called Steadyrack, which is a bike storage and
organization system. It is designed to securely hold and store
bicycles on a wall. The manual provides instructions for removing
and reattaching the Steadyrack to the wall, as well as installing a
new lock bracket for added security. Product Usage
Instructions: 1. To begin, remove the Steadyrack from the wall.
Depending on the type of wall, whether it is masonry or timber,
follow the corresponding instructions: – For masonry walls, take
off the End Caps and unscrew the mounting screws. – For timber
walls, follow the same steps as for masonry walls. 2. Place the new
lock bracket: – For masonry walls, position the lock bracket over
the lower mounting holes from your Steadyrack installation. – For
timber walls, follow the same steps as for masonry walls. 3.
Replace the lower mounting screws: – Place the Steadyrack on top of
the lock bracket, aligning it with the previous mounting holes. –
Use the original screws to replace the lower mounting screws,
ensuring they go through both the Steadyrack and lock bracket. 4.
For an extra layer of security, you can install your lock bracket
with tamper-proof bolts. Visit the website
steadyrack.com/lock-bracket-extra-security for more information and
installation instructions. 5. Replace the upper mounting screws and
end caps: – Depending on your wall type (masonry or timber),
replace the upper mounting screws. – Attach both end caps to the
Steadyrack. 6. Roll your bike onto the Steadyrack and secure it
using any old bike lock. By following these instructions, you can
easily install and use the Steadyrack bike storage system.
1. REMOVE STEADYRACK FROM THE WALL
MASONRY
TIMBER
2. PLACE THE NEW LOCK BRACKET
MASONRY
TIMBER
(A)
Remove your Steadyrack from the wall by (A) taking off the
(B)
End Caps and (B) unscrewing
the mounting screws.
3. REPLACE LOWER MOUNTING SCREWS
Place the Steadyrack on
top of the Lock Bracket,
aligning with the previous
mounting holes (C).
Replace the lower
(D)
mounting screws
(using the original screws)
ensuring they go through
both the Steadyrack and
Lock Bracket (D).
(C)
For an extra layer of security, install your
Lock Bracket with tamper-proof bolts.
For more information on tamper-proof options
and installation instructions, visit our website:
steadyrack.com/lock-bracket-extra-security
Place the new Lock Bracket over the lower mounting holes from your Steadyrack installation. The Lock Bracket has been designed to use the same mounting holes as the Steadyrack.
4. REPLACE UPPER MOUNTING SCREWS & END CAPS
(E) MASONRY
TIMBER
(F) Replace the upper mounting screws (E) and both End Caps for the Steadyrack (F).
5. ROLL BIKE ON. DONE. EASY. Roll your bike on and secure your bike using any old bike lock.
