CONCEPTRONIC FNC-0105 Fast Ethernet Fiber PCI Network Card User Guide
Product Images
Short Description
- Hourly-based current statistics for analysis and diagnosis_x005F_x005F_x005F_x000D_
- Management: web browser, SNMP, SSH and Hyper Terminal_x005F_x005F_x005F_x000D_
- Built-in Wake-on-LAN feature to startup/shutdown computers remotely
Description
The LevelOne FNC-0105 network card offers a broad feature set with high performance at a great price. The card has a Wake-on-LAN feature offering remote start-up and shutdown, two SFP jacks for TX/RX, and clearly visible diagnostic LEDs showing link, activity, collision and FDX. The network card also supports all current operating systems, including Linux.
Additional Information
| Approval and compliance | CE FCC Class B�RoHS |
| Max. operating humidity (%) | 95 |
| Max. operating temperature (°C) | 55 |
| Min. operating humidity (%) | 5 |
| Compatible operating systems | Netware Windows 2000/ XP/ Vista/ 7/ 8/ 10 OS/2 warp IBM LAN Server DEC Pathworks Banyan Vines; Lantastic/AI SCO Unix |
| Indicators | Link, FDX, Col, Activity |
| Chipset | VT6105 |
| Features | Both full-height and low profile for small form factors Support PXE Boot Rom Supports 32-bit PCI 2.2 buses support IP Unicast broadcast and multicast address filtering mechanism support GVRP VLAN registration protocol suppport TCP/IP, CPU Task Offload reduces host CPU use |
| Product weight (kg) | 0,053 |
| Product breadth (mm) | 120 |
| Product depth (mm) | 53 |
| Product height (mm) | 17 |
| Color | Silver |
| EAN | 4015867191040 |
| Model number | FNC-0105 |
| Package contents | FNC-0105 Low Profile Bracket Quick Installation Guide Resource CD (User Manual, Driver) |
| Fast Ethernet SFP | 1 |
