BP-19 Universal 19mm Base Plate
Product Information: BP-19 Universal 19mm Base Plate
The BP-19 Universal 19mm Base Plate is a versatile camera
accessory produced by Vocas Products. It is designed to provide
stability and flexibility for camera setups. The base plate
features various components:
- A. Camera height adjustment
- B. Hex key for height adjustment
- C. Camera adapter plate
- D. Safety release for camera adapter plate
- E. Balance plate lock
- F. Standard rosette (2x)
- G. 19 mm rail lock
- H. 19 mm rails
Adjusting the Rail Locks
The base plate includes red winged nuts with a ratchet mechanism
for easy adjustment of the clamping system. To adjust the rail
locks, simply pull the red winged nut outward and rotate it.
Attaching the Base Plate to Your Camera
Follow these steps to attach the base plate to your camera:
- Remove the camera adapter plate from the base plate by pulling
the red balance plate lock lever backwards and pressing the red
safety release. - Slide the camera adapter plate out of the base plate.
- Slide your camera with the camera adapter plate onto the base
plate. - Lock the balance plate lock lever to secure the camera.
Height Adjustment of the Rails
To adjust the height of the rails, use the supplied hex key and
follow these steps:
- Partially unscrew the two height adjustment screws.
- Adjust the rear of the BP-19 MKII to the desired height.
- Retighten the two height adjustment screws.
- Note: For more adjustment, there are additional sets of
threaded holes available in the base plate.
Adjusting the Dovetail Lock
Follow these steps to adjust the dovetail lock:
- Remove the locking screw.
- Tighten or loosen the dovetail adjustment screw to adjust the
locking mechanism. Clockwise tightens, counterclockwise
loosens. - Reattach the locking screw in one of the three holes around the
dovetail adjustment screw. Choose the hole that aligns best with
the shape of the dovetail adjustment screw.
Additional Information
The BP-19 MKII is part of Vocas’ new sliding system. It allows
for quick switching between the 15 mm base plate, 19 mm base plate,
and Quick Release Dovetail Plate. For more information on available
accessories, please visit the following link:
Vocas BP-19 MKII Accessories.
Vocas Products
www.vocas.com [email protected]
User manual BP-19 universal 19mm base plate
Index:
Introduction:……………………………………………………………………………………………………………………. 3 Guide to Components:……………………………………………………………………………………………………… 4 Adjusting the rail locks: …………………………………………………………………………………………………….. 5 Attaching the base plate to your camera: …………………………………………………………………………….. 5 Height adjustment of the rails: …………………………………………………………………………………………… 7 Adjusting the dovetail lock: ……………………………………………………………………………………………….. 8 Accessories: …………………………………………………………………………………………………………………… 8 Additional information: ……………………………………………………………………………………………………… 9
2 © Vocas v2.0
Introduction:
Thank you for purchasing a Vocas product. You are now the owner of a revolutionary Universal Shoulder Base Plate! (USBP for short) Its great design, the incredible adjustability and quick release are unique in the market. More than 25 years of experience are part of USBP`s design and functionality. We believe that the Vocas USBP gives you the perfect configuration for your camera. You will now experience having your camera in perfect balance. Before you start to use your new accessory, please read these instructions carefully to enjoy optimum performance and a longer service life. Keep this manual in a safe place for future reference.
3 © Vocas v2.0
Guide to Components:
C
B
D
A
E
G
F
H
A. Camera height adjustment. B. Hex key for height adjustment. C. Camera adapter plate. D. Safety release for camera adapter plate. E. Balance plate lock. F. Standard rosette (2x). G. 19 mm rail lock. H. 19 mm rails.
4 © Vocas v2.0
Adjusting the rail locks:
All red winged nuts contain a ratchet mechanism, allowing for easy adjustment of the clamping system. Simply pull red winged nut outward and rotate to adjust.
Attaching the base plate to your camera:
First remove the camera adapter plate form the base plate. Do this by pulling the red balance plate lock lever backwards (1) and pressing the red safety release (2). Now slide the camera adapter plate out of the base plate (3).
1
3 2 Next, attach the camera adapter plate to your camera using the provided 1/4″ and 3/8″ screws. 5 © Vocas v2.0
You can now slide the camera with camera adapter plate on the base plate and lock the balance plate lock lever.
6 © Vocas v2.0
Height adjustment of the rails:
Partially unscrew the two height adjustment screws with the supplied hex key. Adjust the rear of the (US)BP-19 MKII to the desired height. Retighten the two height adjustment screws. Please note that for more adjustment, there are more sets of threaded holes available in the base plate.
7 © Vocas v2.0
Adjusting the dovetail lock:
1. Remove the locking screw (1). 2. Tighten or loosen the dovetail adjustment screw (2) to adjust the locking mechanism of
the dovetail. (CW to tighten CCW to loosen) Often only a very slight adjustment is required. 3. Reattach the locking screw in one of the 3 holes around the dovetail adjustment screw. Choose the hole that lines up the best with the shape of the dovetail adjustment screw.
2 1
8 © Vocas v2.0
Accessories:
For all available accessories please see: https://www.vocas.com/vocas-bp-19-mkii-without-dovetail-plate.html
Additional information:
This (US)BP-19 MKII is part of our new sliding system. Once the camera adapter plate (1) is attached to your camera, you can very quickly switch from the 15 mm base plate (2) to the 19 mm base plate (3) or to the Quick release dovetail plate (4)
3, 0480-0022
1, 0350-2250
9 © Vocas v2.0
2, 0350-220X
4, 0350-2220
