RS 50200 Wireless On-Ear TV Headphones
Instruction Manual

Contents hide

1 RS 50200 Wireless On-Ear TV Headphones

2 Important safety instructions

3 Intended use/Liability

4 Manufacturer Declarations

5 Documents / Resources

5.1 References

RS 50200 Wireless On-Ear TV Headphones

RS 5200
Model: RS 5200, TR 5000, RR 5200
Flex 5000
Model: Flex 5000, TR 5000, RR Flex
RS 2000
Model: RS 2000, TR 2000, RR 2000
Set 880
Model: Set 880, TR 880, RR 800
Set 860
Model: Set 860, TR 860, RR 800

Important safety instructions

▷ Read the instruction manual, safety guide, quick guide (depending on the package contents) carefully and completely before using the product.
▷ Always include these safety instructions and the instruction manual when passing the product on to third parties.
▷ Do not use an obviously defective product.
▷ Only use the product in environments where wireless 2.4 GHz transmission is permitted.

Preventing damage to health and accidents

▷ These headphones allow you to set higher volumes than conventional headphones.
Protect your hearing from high volume levels. Permanent hearing damage may occur when headphones are used at high volume levels for long periods of time. Headphones of the Sennheiser brand sound exceptionally good and provide clear speech intelligibility even at low and medium volume levels.
▷ To prevent hearing damage, set the volume to a low level before passing the product on to third parties.
▷ Do not use the product in an environment that requires your special attention (e.g. when perfor- ming skilled jobs).
▷ Always keep the headphones/MCA 800 charging adapter at least 3.94“ (10 cm) from cardiac pacemakers or implanted defibrillators. The headphones/MCA 800 charging adapter contain/s magnets that generate a magnetic field which could cause interference with cardiac pacemakers and implanted defibrillators.
▷ Do not use the product near water. To reduce the risk of fire or electric shock, do not expose the product to rain or moisture.
▷ Keep the product, accessories and packaging parts out of reach of children and pets to prevent accidents. Swallowing and choking hazard.
▷ Only use the power supply units supplied by Sonova Consumer Hearing.

Preventing damage to the product and malfunctions

▷ Always keep the product dry and do not expose it to extreme temperatures to avoid corrosion or deformation. The normal operating temperature is from 5 to 40 °C/41 to 104 °F.
▷ Use the product with care and store it in a clean, dust-free environment.
▷ Switch off the product after use to conserve battery power.
▷ Unplug the power supply unit from the wall socket

to completely disconnect the product from the power source,
during lightning storms or
when not using the product for long periods of time.

▷ Always ensure that the power supply unit is

in a safe operating condition and easily accessible,
properly plugged into the wall socket,
only operated within the permissible temperature range,
not exposed to direct sunlight for longer periods of time in order to prevent heat accumulation.

▷ Varnish or furniture polish may degrade the feet of the transmitter, which could stain your furniture. You should therefore place the transmitter on a non-slip pad to avoid potential staining of furniture.
▷ Do not operate the product near heat sources.
▷ Clean the product only with a soft, dry cloth.
▷ Use only attachments/accessories/spare parts supplied or recommended by Sonova Consumer Hearing.

Intended use/Liability

This wireless TV headphone system (RS 5200, RS 2000)/TV listening system (Set 880, Set 860, Flex 5000) is suitable for use with TV sets, hi-fi systems, and home cinema systems and can be connected to analog and digital audio sources (the RS 2000 headphone system can only be connected to analog audio sources).
This product is intended for private domestic use only. It is not suitable for commercial use. This product is also not intended to be used with portable audio devices.
It is considered improper use when the product is used for any application not named in the corresponding product documentation.
Sonova Consumer Hearing GmbH does not accept liability for damage arising from misuse or improper use of the product and its attachments/accessories.
Before putting the product into operation, please observe the respective country-specific regulations.

Safety instructions for Lithium rechargeable batteries
WARNING
If abused or misused, rechargeable batteries may leak. In extreme cases, they may even present a risk of:

explosion,
heat and fire development
smoke and/or gas development
damage to health and/or the environment

	Only use rechargeable batteries and chargers recommended by Sonova Consumer Hearing.		Do not leave the product / rechargeable batteries unattended while charging.
	Only charge the product / recharge- able batteries at ambient tempera- tures between 10 °C and 40 °C/50 °F and 104 °F and do not charge them near easily flammable objects.		Do not heat the product / rechargeable batteries above 70 °C/158 °F. Avoid exposure to sunlight and do not throw the product / rechargeable batteries into fire.
	Switch rechargeable battery-powe- red products off after use.		When not using the product / rechargeable batteries for extended periods of time, charge them regularly (about every three months).
	Avoid prolonged skin contact with the product, rechargeable battery, charger or charging cable when connected to a power source. These components can heat up during charging and cause skin irritation.		Dispose of defective products with built-in rechargeable batteries at special collection points or return them to your specialist dealer to facilitate recycling.

Information on the additional receivers (RR 5200, RR Flex, RR 800)
If you have purchased an additional receiver (RR 5200, RR Flex, RR 800), you can find a detailed instruction manual for your TV headphone system (RS 5200)/TV listening system (Flex 5000, Set 880, Set 860):

in printed form along with the TV headphone system/TV listening system
on the respective product page on our website at www.sennheiser-hearing.com or at www.sennheiser-hearing.com/download.

Manufacturer Declarations

For more information on regulatory compliance markings, refer to the end of the document.
Warranty
Sonova Consumer Hearing GmbH gives a warranty of 24 months on this product. For the current warranty conditions, please visit our website at www.sennheiser-hearing.com/warranty or contact your Sonova Consumer Hearing partner.
For AUSTRALIA and NEW ZEALAND ONLY
Sonova Hearing Australia Pty Ltd provides a warranty of 24 months on these products. For the current warranty conditions, visit the Sonova Consumer Hearing website: www.sennheiser-hearing.com/warranty.
Sonova Consumer Hearing goods come with guarantees that cannot be excluded under Australian and New Zealand Consumer law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. This warranty is in addition to other rights or remedies under law. Nothing in this warranty excludes, limits or modifies any remedy available to the consumer which is granted by law.
To make a claim under this contract, raise a case via the Sonova Consumer Hearing website: www.sennheiser-hearing.com/service-support.
All expenses of claiming the warranty will be borne by the person making the claim.
Sonova Consumer Hearing international warranty is provided by: Sonova Hearing Australia Pty Ltd (ABN 82651492929) The Zenith, Level 14, Tower A, 821 Pacific Highway, Chatswood New South Wales 2067, Australia.
EU declaration of conformity

RoHS Directive (2011/65/EU)
ErP Directive (2009/125/EC

Hereby, Sonova Consumer Hearing GmbH declares that the radio equipment type RS 5200 (TR 5000, RR 5200), RS 2000 (TR 2000, RR 2000), Flex 5000 (TR 5000, RR Flex), Set 880 (TR 880, RR 800), Set 860 (TR 860, RR 800) is in compliance with the Radio Equipment Directive (2014/53/EU). The full text of the EU declaration of conformity is available at the following Internet address: www.sennheiser-hearing.com/download.
UK declaration of conformity

RoHS Regulations (2012)
Radio Equipment Regulations (2017)
The Ecodesign for Energy-Related Products and Energy Information (Amendment) (EU Exit) Regulations (2019)

Notes on disposal

EU: WEEE Directive (2012/19/EU)
EU: Battery Directive (2006/66/EC & 2013/56/EU)
UK: WEEE Regulations (2013)
UK: Battery Regulations (2015)

The symbol of the crossed-out wheeled bin on the product, the battery/rechargeable battery (if applicable) and/or the packaging indicates that these products must not be disposed of with normal household waste, but must be disposed of separately at the end of their operational lifetime. For packaging disposal, observe the legal regulations on waste segregation applicable in your country. Improper disposal of packaging materials can harm your health and the environment.
The separate collection of waste electrical and electronic equipment, batteries/rechargeable batteries (if applicable) and packagings is used to promote the reuse and recycling and to prevent negative effects on your health and the environment, e.g. caused by potentially hazardous substances contained in these products. Recycle electrical and electronic equipment and batteries/ rechargeable batteries at the end of their operational lifetime in order to make contained recyclable materials usable and to avoid littering the environment.
If batteries/rechargeable batteries can be removed without damaging them, you are obliged to dispose of them separately (for the safe removal of batteries/rechargeable batteries, see the instruction manual of the product). Handle lithium-containing batteries/rechargeable batteries with special care, as they pose particular risks, such as the risk of fire and/or the risk of ingestion in the case of coin batteries. Reduce the generation of battery waste as much as possible by using longer-life batteries or rechargeable batteries.
Further information on the recycling of theses products can be obtained from your municipal administration, from the municipal collection points, or from your Sonova Consumer Hearing partner. You can also return electrical or electronic equipment to distributors who have a take-back obligation.
Herewith you make an important contribution to the protection of the environment and public health.

Compliance Information Model: RS 5200, Flex 5000, RS 2000, Set 880, Set 860

Frequency band: 2400 – 2483.5 MHz
Transmit power: 10 mW (max)

Country/ Region	Model: TR 5000 TR 860 TR 880	Model: RR 5200 RR 800	Model: RR Flex	Model: TR 2000	Model: RR 2000
USA
	FCC ID: 2A3ULTR5000	FCC ID: 2 A3ULRR5000	FCC ID: 2A3ULRRFLEX	FCC ID: 2A3ULTR2000	FCC ID: 2A3ULRR2000
Canada	CAN IC ES3(B)/NM B3(B)
	IC: 28115-TR5000	IC: 2 8115-RR5000	IC: 28115-RRFLEX	IC: 28115-TR2000	IC: 28115- RR2000
Europe
United Kingdom
Australia/ New Zealand
Singapore	Complies with OMDA Standards DB107630
Russia
China

Country/Region	Model: TR 5000, TR 860, TR 880	Model: TR 2000	Model: RR 5200, RR 800
Japan	201-163245	201-163244	201-163246
	Model: RR Flex	Model: RR 2000
	201-163243	201-163247

Statements regarding FCC and ISED
FCC Supplier’s Declaration of Conformity (SDoC)

SENNHEISER
Model:
RS 5200, Flex 5000, RS 2000, Set 880, Set 860
TR 5000, TR 2000, TR 880, TR 860
RR 5200, RR 2000, RR Flex, RR 800

We,
Sonova Consumer Hearing USA, LLC
One Enterprise Drive • Old Lyme •
CT 06371 • USA
Tel: +1 (860) 598-7800

declare the above device comply with the requirements of Federal Communications Commission.
This device complies with Part 15 of the FCC rules. Operation is subjected to the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause undesired operation.
Responsible Party: Lou deLaforcade

This device complies with Part 15 of the FCC rules, RSS-247 of Innovation, Science and Economic Development Canada (ISED). Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications made to this equipment not expressly approved by the manufacturer may void FCC authorization to operate this equipment.

RF Radiation Exposure Information
The product complies with the rules of FCC and ISED (RSS-102) for the portable RF exposure limit set forth for an uncontrolled environment and is safe for intended operation as described in this manual. This product is not subjected to FCC routine RF exposure evaluation per Section 2.1093 and RSS-102 of ISED. Further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.
The transmitter of this device should be installed and operated at least 8“ (20 cm) away from the user’s body.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Use of other accessories not verified by the manufacturer may not ensure the compliance.

Sonova Consumer Hearing GmbH
Am Labor 1, 30900 Wedemark, Germany
www.sennheiser-hearing.com
Publ. 01/23, 591196/A04
