Vevor Js-75-gd-01 Button Maker Machine Instruction Manual

JS-75-GD-01 Button Maker Machine

VEVOR

BUTTON MAKER MACHINE INSTRUCTION MANUAL

JS-75-GD-01

NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
[email protected]
This is the original instruction. Please read all manual instructions carefully before operating VEVOR reserves clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if there are any technology or
software updates on our product
01

SAFETY REMINDER
1. This badge machine is only applied for the intended purpose. Don’t apply in other applications which exceed safety considerations.
2. Children cannot operate this product unless accompanied by an adult. 3.Pay attention to safety during operation, and avoid crushing fingers.
COMPONENTS
Connector, Flexible Core Down Mold (Left) Revolve Plate
02

1. Tin Up Cover
2.Plastic Back Plate
3.White Paper (The paper thickness needs to be in the range of 127g-159g, and the paper diameter should be the same as the transparent film diameter)
4. Transparent Film

5.Metal Back Plate

6.Plastic (Only back

Washer required when
plate.)

using

metal

03

MANUFACTURE PROCESS

1.Revolve and twist handle in

2.Put “Tin up cover”–“Paper” (pattern levelly placed)–
“Transparent plastic film”into the right mold in sequence, then anticlockwise revolve the down mold to bottom till the up and
down mold aligned

3. Use one hand to hold the machine body first then stable the machine body by the handle
another hand press the machine handle till down press to be bottom. (Special attention: this
time down pressed up mold hinge is in a separate state.)

4. Put the plastic back plate into the eft mold (Attention: The pin should be level without protruding. The
upside words upward placed according to the mold side triangle indication mark), rotate the down mold clockwise to the bottom until the up and down mold aligned

5.Hand holds the machine body, right hand down press the handle until up and down mold
merged to bottom, now the upper mold hinge is in merged state, and the pin passes through the hole.

6.Manufacture finished

Special Attention: If use the metal back plate, the left mold groove needs to place the plastic washer
04

FAILURE AND TROUBLESHOOTING

Failure Appearance
First time downward press iron cover and not absorbed to up mold
Second downward press part not wrapped in
Not tightly press the badge, pressed in but not firm

Possible Reasons
1. Unsuitable operating method 2. Too much lubricating oil in the
up mold
1. Unsuitable operating method 2.High mold friction force 3. Unsuitable paper thickness 4. Up mold screws loosen
1. The downward press is not in place, not press to the bottom
2. Paper is thinner 3. (75mm) Configured metal back
consumables must place the washer

Troubleshooting
1.First time downward press up mold hinge is in a separate state
2. Use clean cloth or tissue completely wipe it if found too much lubricating oil on the up mold
3. The up and down mold must be on the same vertical line when closing
1.The up and down mold must be on the same vertical line when closing
2. Evenly coat lubricating oil in the up and down mold internal holes
3. Use the stipulated thickness paper 4. Place the up mold on the machine
body, use the complimentary Allen key to fix the screws in the up mold internal hole center.
1. Need press to the bottom when downward pressing
2. Change to use a slightly thicker paper
3.Right side mold place 2mm thickness washer when using the metal back consumables

Noise during pressing manufacture
Up mold unable to lift up after pressing manufacture, blocked

High friction force between molds

Evenly coat lubricating oil in the up and down mold internal holes

1. Up and down mold position deviated
2. The paper is incorrectly cut round or blocked by a foreign object.

Use a sharp tool (such as a straight
screwdriver) to align to middle merge position clearance which is between up and down mold, and pry open with
the object like a hammer (Attention: Just tap it, generally, it will not be too tightened)

05

MODEL AND PARAMETER

Product Mode Model
Manufactured Badge Specification
Machine Body Color
Paper Requirements
Accessories With Machine

JS-75-GD-01
75
Gold
127-157g Copper Plate Paper
1. 75 Iron Bottom Back Plate *50 Pieces 2. 75 Plastic Bottom Back Plate* 50 Pieces 3. 75 Tin Up Cover *100 Pieces 4. 75 Blank Round Paper* 50 Pieces 5. 75 Transparent Film*100 Pieces 6. 75 Round Cutter*1 Piece 7.Allen Key* 2 Pieces 8.Magic Book *1 Set 9.Washer * 2 Pieces 10.Instruction *1 Set
