Fantech Edm-300c Residential Range Wall Mounted Fans Instructions

EDM-300C Residential Range Wall Mounted Fans

Product Information

The Residential Range fan from EDM-300C comes with a Fly Wire
that is included in the package. It is designed to be installed in
narrow wall panel applications and comes with a Slimfit external
grille and spacer plate. The fan and grille combination can be
installed into wall panels of width ranging from 45 to 130mm. The
product also includes DPL150 Louvre and DPS150 Spacer Plate.

Product Usage Instructions

To install the fan, follow these steps:

  1. Determine the thickness of the wall panel where the fan will be
    installed.
  2. Refer to the installation data chart to determine the number of
    spacer plates required for your wall panel thickness.
  3. Attach the spacer plate(s) to the fan using screws.
  4. Insert the fan and grille combination into the wall panel
    opening and secure it in place using screws.
  5. Attach the fly wire to the grille using clips or screws.

Please note that the product is suitable for installation in
narrow wall panel applications such as mining accommodation huts,
portable homes, and site offices. All dimensions are given in
millimeters.

// RESIDENTIAL RANGE

FLY WIRE
INCLUDED

Designed to fit directly onto the EDM-300C wall mounted fan in narrow wall panel applications.
Fan and grille combination designed to be installed into wall panels from 45 to 130mm wide.

SLIMFIT
EXTERNAL GRILLE AND SPACER PLATE
MADE

The Slimfit Grille and Spacer Plate have been specifically designed to fit directly onto the spigot of an EDM-300C fan. · Spacer Plate can be mounted on exterior or interior wall. · Made from UV-stabilised ABS Plastic. · Comes with flywire mesh sheet to eliminate entry
of insects. · Grille can also be used with thicker walls or ducted
applications using wall tube or flex duct. · Available with 150mm spigot only.
All dimensions in mm

INSTALLATION DATA
Can be installed into 45 to 130mm thick narrow wall panel applications such as mining accommodation huts, portable homes and site offices.

DPL150 Louvre
99 to 130mm

Wall

EDM-300C

1 x DPS150 Spacer Plate
DPL150 Louvre

81 to 98mm

1 x DPS150 Spacer Plate
DPL150 Louvre
63 to 80mm

EDM-300C 2 x DPS150 Spacer Plates

1 x DPS150 Spacer Plate

DPL150 Louvre
45 to 62mm

EDM-300C
EDM-300C 1 x DPS150 Spacer Plate

© FANTECH TRADE 2023

WALL MOUNTED FANS

21
