40A Electronics 70 Amp Power Supply and Charger

X-Line Sources and Chargers – User Manual

Product Information:

The X-Line Sources and Chargers are high-power supplies that
allow for powering and charging of automotive batteries. They are
available in 40A, 60A, 70A, 120A, 150A, and 200A outputs and
operate in three intelligent modes that manage battery charging.
The X-Line Sources and Chargers are designed for heavy use, being
able to provide maximum power for an extended period of time while
keeping the sound on and charging the batteries. They feature a
super compact SLIM format that is ideal for use in any project.
Additionally, they come with the exclusive X-LINE FUNCTION, which
raises battery bank voltage to up to 15.2V for 30 seconds, allowing
amplifiers to deliver maximum performance.

Product Usage:

Before using the X-Line Sources and Chargers, make sure to read
the user manual carefully to understand the different modes of
operation and functions.

Performance X-LINE FUNCTION: This function is
unique to X-LINE chargers and raises the battery bank voltage to up
to 15.2V for 30 seconds, allowing amplifiers to deliver maximum
performance.

INTELLIGENCE AUTO SCI MODE: The STORM Sources
have an auto sci operating mode that is ideal for use when the
system is turned on and the sound takes power from the batteries
and the source or when a quick charge is required on the batteries.
In this mode, the STORM Source will maintain maximum output power
(14.4V) whenever requested and will automatically enter the PULSED
SCI system (SMART CHARGE SYSTEM) when the batteries are charged,
remaining into fluctuation.

SOURCE MODE – Fixed Output Voltage: The X-Line
Sources allow the user to digitally choose between 6 voltage values
at the source output (12.6V / 13.0V / 13.4V / 13.8V / 14.0V /
14.4V). This mode is ideal for battery-free systems, allowing you
to power the amplifier or other devices with a stable voltage.

BATTERY CHECK-UP – Accumulated Charge Meter:
The STORM Sources display, in addition to working such as voltmeter
and ammeter, informs the user how much cargo was accumulated by the
battery during the charging cycle, letting you know if the battery
is still in good working order.

COMFORT SMART COOLER: The X-Line Sources
feature an intelligent ventilation system with dynamic PWM control.
When the source is turned on, the fan initiates a gradual
acceleration, reduces the rotation to the appropriate value, and
adjusts to the source’s need. There is also a decrease in noise
level, maintaining cooling and increasing the life of fans.

SLIM FORMAT: With the highest power density,
X-LINE Fonts have robust, modern and super-compact design, taking
up the smallest space in automotive sound design, which makes them
ideal in any project.

Overall, the X-Line Sources and Chargers are designed to provide
high-performance, intelligent, and diagnostic functions while
offering comfort items with the best design. They were designed and
developed to be the most complete product on the market until
then.

View Fullscreen

User manual
power supply and battery charger
The best source, so far.

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL
PRESENTATION
The X-Line Sources and Chargers of 40A, 60A, 70A, 120A, 150A and 200A are high-power supplies, in super compact format “SLIM”, which allow to power and charge automotive batteries. They provide a maximum current of 40A, 60A, 70A, 120A, 150A and 200A at their output, respectively, and operate in 3 intelligent modes that manage battery charging. In addition, the line has the exclusive X-LIINE FUNCTION.
They are designed for heavy use, being able to provide maximum power for an extended period of time, keeping the sound on and charging the batteries. Its super compact “SLIM” format is ideal for use in any project.
X-Line Sources and Chargers o er performance, INTELLIGENCE, DIAGNOSTIC functions and COMFORT items with the best design. They were designed and developed to be the most complete product on the market until then.
MODES OF OPERATIONS AND FUNCTIONS
PERFORMANCE X-LINE FUNCTION: Unique to X-LINE chargers, it raises battery bank voltage to up to 15.2V
for 30 seconds, allowing amplificators to deliver maximum performance.
INTELLIGENCE AUTO SCI MODE: STORM Sources have auto sci operating mode, ideal for use when the
system is turned on and the sound takes power from the batteries and the source or when a quick charge is required on the batteries. In this mode, the STORM Source will maintain maximum output power (14.4V) whenever requested, and will automatically enter the PULSED SCI system (SMART CHARGE SYSTEM) when the batteries are charged, remaining into flutuation.
SLOW CHARGE MODE: X-Line Sources have SLOW BATTERY charging mode, charging them in 3 phases (LIFTING, ABSORPTION, EQUALIZATION) indicated on the CONTROL PANEL by 3 LEDs. This function is ideal for recharging low-charge batteries and the sound system turned o . When using the SLOW LOAD, the battery is charged at 100% capacity and without su ering heating, as its smart charge curve is adjusted to the capacity of the battery or the Batteries Installed. You get a maximum e ciency in upload without Wear. Right Extend a life useful of battery beyond from enable still more load.
1

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL

PHASE 1

PHASE 2

PHASE 3

CURRENT CONSTANT PULSATING
ELEVATION

CONSTANT VOLTAGE
ABSORPTION

MAXIMUM LOAD
EQUALIZATION

During phase 1 (LIFTING) the battery current is limited to a maximum of 20% of the current of the previously configured battery bank; which gradually increases the voltage of the battery cells without heating or overloading. This phase has 6 steps, which are indicated by the firing frequency of LED 1 (ELEVATION), from 1 to 6Hz. When LED 1 (ELEVATION) lights up constantly, it means that this phase has already been performed. After the battery voltage is raised to 14.4V, the source automatically enters phase 2 (ABSORPTION). In phase 2 (ABSORPTION),the voltage remains constant at 14.4V while the battery absorbs charge, until the current reaches 4% of the bank value, previously configured, triggering LED 2 (ABSORPTION) constantly and automatically moving to phase 3 (EQUALIZATION). In phase 3 (EQUALIZATION), the voltage is reduced to 13.8V with pulses of 14.4V every 5 minutes. The battery is charged at its maximum capacity, because the equalization is done pulsatively.
SOURCE MODE – Fixed Output Voltage: X-LINE Sources allow the user to digitally choose between 6 voltage values at the source output (12.6V / 13.0V / 13.4V / 13.8V / 14.0V / 14.4V). This mode is ideal for battery-free systems, allowing you to power the amplifier or other devices with a stable voltage.

DIAGNOSIS CCA METER Cold Start Current: Função exclusiva das Fontes STORM, a medição de CCA –
Corrente de Partida a Frio (Cold Cranking Ampere) – permite realizar uma análise da bateria em apenas 10 segundos, fornecendo o valor de CCA da bateria em amperes, que pode ser comparado com o CCA disponível no rótulo da bateria ou com medições anteriores. A função mede também a resistência interna (Ri) em m (miliOhm) e a porcentagem comparativa da carga em relação a uma bateria nova.
BATTERY CHECK-UP – Accumulated Charge Meter: The STORM Sources display, in addition to working such as voltmeter and ammeter, informs the user how much cargo was accumulated by the battery during the charging cycle, letting you know if the battery is still in good working order.
2

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL
COMFORT SMART COOLER: X-LINE sources feature an intelligent ventilation system with dynamic
PWM control. When the source is turned on, the fan initiates a gradual acceleration, reduces the rotation to the appropriate value, and adjusts to the source’s need. There is also a decrease in noise level, maintaining cooling and increasing the life of fans.
SLIM FORMAT: With the highest power density, X-LINE Fonts have robust, modern and super compact design, taking up the smallest space in automotive sound design, which makes them ideal in any project.
MAIN FEATURES
7 1
6 2
3 5
4
1. Control panel: Displays all source information and allows you to configure all functions; 2. Ventilation: Forced ventilation inlet from the source (do not block); 3. DC connector protection cover: Protege as conexões de saída da fonte; 4. DC output connector: Connects the battery terminals to the bus or equipment to be powered. Always check the correct connection polarity; 5. Fixation points: Robust system, allowing to be firmemente fixados by the metal chassis; 6. AC Connection: Connection of the Source to the power grid. Use compatible connection socket and do not use adapters and/or line machines; 7. Output from Ventilation: Output ventilation of the Source. Do not obstruct.
3

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL

DASHBOARD FROM CONTROL

PCAIONNELTRDEOCLOPNATNREOLLE

BCAHTETCEKR-UYPCDHAEBCAKT-EURPIA

VOTLETNASGÃEO
RESAEDLIENTGOR SELEICTTUORRA
CCMAED-IRDOi mR MECTCEAR- Ri m MSEOSMLDEEOLCEDETTOOORR

ACMOPRERREANGTEE

SLOW CHARGE CARPGHAALSENESTA

1.1E.ELELVEAVÇAÃTOION

22. A.ABBSOSROÇRÃPOTION

10 12
SESLEELCETTOORR

33. E.EQQUUALAILZIAZÇAÃTOION
13

CSHLCALOAERWNRGTGEAA

AIUACSUTSCOTIO VOOTUSELTATNPAÍSDUGÃATOE

BBAATTTEERRIYA VTEONLSTÃAOGE
super-x

CCBABHRAAATRTRTEEEGGRRAEIAYDDA

8. LED that indicates the voltage parameter VOLTAGE, CURRENT or BATTERY CHECK-UP (2 LEDS on);
9. VOLTAGE, CURRENT and BATTERY CHECK-UP readings selector key; 10. Selector switch of SLOW LOAD, AUTO SCI e OUTPUT VOLTAGE; 11. LEDs that indicate SLOW LOAD, AUTO SCI and OUTPUT VOLTAGE; 12. BATTERY capacity selector switch (when in SLOW CHARGE mode), VOLTAGE of the output (when in VOLTAGE OUTPUT mode) or triggering of the X-LINE function (press for 2 seconds); 13. BATTERY CHARGED LED indicator; 14. Indicator LEDs of the 3 loading phases of SLOW LOAD mode; 15. Voltage/current indicator display or hour ampere counter.

INSTALLATION AND CONNECTIONS

X-LINE sources have a robust fixation system, allowing them to be firmly fixed by the metal chassis, giving greater resistance and safety in the installation (fig. 1).
To remove the protective cover from the DC connectors, pull it up by exposing the connecting screws to the output cables (fig. 2).

Fig. 1

Fig. 2

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL
Each Source 40A, 60A, 70A, 120A, 150A and 200A can power about 2,000, 3,000, 3,500, 6,000, 7,500 and 10,000 Wrms of sound playing respectively, provided that a parallel battery is used to supply the peak consumption.
When connecting to the batteries, observe the correct polarity of the connection and use the appropriate cable gauge, according to the MINIMUM GAUGE table OF THE CABLES FOR CONNECTION (see page 11). In battery-powered systems, the source should always be connected to the battery and the battery to the amplificators (the connection point should always be made in the battery post).

Amplifier
12V

You can use as many Fonts (40A, 60A, 70A, 120A, 150A and 200A) that are required to power the sound, with reference that each one keeps about 2,000, 3,000, 3,500, 6,000, 7,500 and 10,000 Wrms of sound playing respectively.
Another important point to note is that, operating in parallel, the sources must be in the same OPERATING MODE, example:
AUTO SCI MODE: All sources must be in SCI. OUTPUT VOLTAGE MODE: All sources must have the same output voltage.

SERIAL CONNECTION – HIGH VOLTAGE

PARALLEL CONNECTION

12V

–

12V

12V
+ –
12V

12V

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL
OPERATING MODES AND FUNCTIONS

MODE (REDLINE) SLOW LOAD – Smart Slow Load To use Smart Slow Load mode, press the SELECTOR MODE until the LED indicative Of
LOAD SLOW Light. Press a key SELECTOR BATTERY e Select a capacity, in amperes, of the battery to be charged. Upon arriving in 999, the counter returns to the first value.

PACIONNELTRDEOCLOPNATNREOLLE
BCAHTETCEKR-UYPCDHAEBCAKT-EURPIA

VOTLETNASGÃEO

ACMOPRERREANGTEE

RESAEDLIENTGOR SELEICTTUORRA

CCMAED-IRDOi Rm

MECTCEAR- Ri m MSEOSMLDEEOLCEDETTOOORR

SESLEELCETTOORR

SCLLOAENWRTGAA CHARGE

AUASUTCOTIO ICS

VOOTUSELTANTPÍASDUGÃATOE

BBAATTTEERRIAY VTEONLSTÃAOGE
super-x

CCABABBHRRAAAARTRTTRTEEEEEGRGGRRAIAEIAAYDDDAA

SLOW CHARGE CCAARRPGGHAAALLESENNETSTAA 11..1EE.LELEELVVEAAVÇÇAÃÃTOOION 22.2. AA.ABBSBSOOSRROÇÇRÃÃPOOTION 33.3. EE.QEQQUUAUALLAIIZLZAIAZÇÇAÃÃTOOION

If your battery does not fit the options, use the nearest smallest value, and in case there is more than one battery in parallel in the system, add the amperage of all and select the capacity that most closely closes to that of the seat.
The available options are:

A 7 12 17 25 40 45 50 60 70 75 80 / H 90 100 105 115 150 200 300 400 600 800 999
IMPORTANT: If there are more sources in parallel in the system, use only one of the sources in slow load mode and keep the other ones o .

SCI MODE – Smart Fast Charge To use AUTO SCI mode, press the MODE SELECTOR switch until the Auto SCI (Smart
Charging System) LED lights up. This mode allows the source output to operate at 14.4V when the system requests more
(sound on playing or in a battery charge situation). In fluctuation, it operates with the tension from output in Cycles from 13.8V during 5 minutes e 14.4V during 10 Seconds.

PACIONNELTRDEOCLOPNATNREOLLE
BCAHTETCEKR-UYPCDHAEBCAKT-EURPIA

VOTLETNASGÃEO
RSEESLAEEDILCTIETNUTORGORAR
CCMAED-IRDOi Rm MECTCEAR- Ri m MSEOSMLDEEOLCEDETTOOORR

ACMOPRERREANGTEE
1

SLOW CHARGE CCAARRPGGHAAALLESENNETSTAA 11..1EE.LELEELVVEAAVÇÇAÃÃTOOION 22.2. AA.ABBSBSOOSRROÇÇRÃÃPOOTION 33.3. EE.QEQQUUAUALLAIIZLZAIAZÇÇAÃÃTOOION

SESLEELCETTOORR

CSHCLALOAERNWRGTGEAA

AUASUTCOTIO ICS

VOOTUSELTANTPÍASDUGÃATOE

BBAATTTEERRIAY VTEONLSTÃAOGE
super-x

CCABABBHRRAAAARTRTTRTEEEEEGRGGRRAIAEIAAYDDDAA

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL
THE AUTO SCI allows the battery to absorb a greater amount of charge and prevent excessive elevation of the potential of the plates, a chemical phenomenon caused by load stress (electrolysis), increasing the life and e ciency of the batteries.

OUTPUT VOLTAGE MODE (Fixed Source Mode)

To use in FIXED OUTPUT VOLTAGE mode, press the SELECTOR switch MODE until the LED

VOLTAGE OUTPUT turns on.

PPACAIIONNNEELLTRDDEEOCCLOOPNNATTNRREOOLLLEE
BCCAHHTEETCCEKKR–UUYPPCDDHAAEBBCAAKTT-EEURRPIIAA

VOTTLEETNNASSGÃÃEOO

ACCMOOPRRERRREEANNGTTEEE

RSEESLSLAEEEEDIILCLTTIEETNUUTTORGROORAARR

CCMMAEEDD- IIRDDOiORmR MECCTCCEAAR– RRii mm
1 MSEOSMLSMDEEEOOLCLEDDEETTOTOOOORRR

2 SESSLEEELLCEETTTOOORRR

CSHCLCALLOAAEERNWRNRGTGTGEAAAA

AIUAACSSUTUSCCOTTIIOO VOOTTUSSEELTANATNPÍAÍSSDDUGÃÃAATOOE

BBBAAATTTTEEERRRIIAAY VTTEEONNLSSTÃÃAOOGE
super-x

CCCAABABBBHRRRAAAAARRTRTTTRTEEEEEEEGGRRGGRRAAIIAEIAAAYDDDDAAA

SLOW CHARGE CCCAAARRRPGGGHAAAALLLEESENNNETTSTAAA 111…1EEE.LLELEEELVVVEAAAVÇÇÇAÃÃÃTOOOION
222..2. AAA.ABBBSBSSOOOSRRROÇÇÇRÃÃÃPOOOTION
333..3. EEE.QQEQQUUUAUAALLLAIIIZZLZAAIAZÇÇÇAÃÃÃTOOOION

Immediately after, press the VOLTAGE SELECTOR switch and select the desired output voltage.

The options healthy:

12,6 13,0 13,4 13,8 14,0 14,4

VDC

X-LINE FUNCTION To select the X-LINE function, simply hold down the BATTERY /VOLTAGE/X-LINE
SELECTOR switch for 2 seconds. When triggered, the display will show the SPL inscription flashing for 30 seconds. After this time, the display displays the OFF subscription and the font returns to its previous operating condition.

PACIONNELTRDEOCLOPNATNREOLLE
BCAHTETCEKR-UYPCDHAEBCAKT-EURPIA

VOTLETNASGÃEO

ACMOPRERREANGTEE

RSEESLAEEDILCTIETNUTORGORAR

CCMAED-IRDOi Rm MECTCEAR- Ri m
MSEOSMLDEEOLCEDETTOOORR

SESLEELCETTOORR

SCLLOAENWRTGAA CHARGE

AUASUTCOTIO ICS

VOOTUSELTANTPÍASDUGÃATOE

BBAATTTEERRIAY VTEONLSTÃAOGE
super-x

CCABABBHRRAAAARTRTTRTEEEEEGRGGRRAIAEIAAYDDDAA

SLOW CHARGE CCAARRPGGHAAALLESENNETSTAA 11..1EE.LELEELVVEAAVÇÇAÃÃTOOION 22.2. AA.ABBSBSOOSRROÇÇRÃÃPOOTION 33.3. EE.QEQQUUAUALLAIIZLZAIAZÇÇAÃÃTOOION

To disable the function, before time runs out, simply press the key again BATTERY/VOLTAGE/STORM SELECTOR while the function is running. The display displays the inscription OFF e a source Returns à its condition from operation previous.

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL

CCA METER FUNCTION (Cold Start Current Meter)

To perform CCA measurement, simultaneously press the SELECTOR READING and

SELECTOR MODE keys.

PCAIONNELTRDEOCLOPNATNREOLLE
BCCAHHTEETCCEKKR–UYUPPCDDHAAEBCBAAKTT-EEURRPIIAA

VOTTLETENNASSGÃÃEOO

ACMCOOPRRERREAENNGTTEEE

RSEESLASLEEEDEILCITLITETNEUUTOTGRORORARAR CCMMAEED-DIRIDDOiOmRR

MECCTCCEAAR–RRiimm

MSEOSMLSMDEEOEOLCELDEDTETOOTOOORRR

SESSLEELCETTOORR

CSHLCALCLOAERAEWNRNRGTGTGEAAAA

AIUACASUTSSUCOCTTIOIOVOOTUTSELSETATNANPAÍSÍSDUDGÃÃATAOEO

BBAATTTEERRIYA VTEONLSTÃAOGE
super-x

CCBABHRAAATRTRTEEEGGRRAIEAYDDA

SLOW CHARGE CARPGHA ALSENETSA 1.1E.LEELVEAVÇAÃTOION 2.2A.ABBSOSROÇRÃPOOTION 3.3E.EQQUUALAIZLAIZÇÇAÃÃTOOION

When the CCA METER function is activated, the STORM Source disconnects from the AC

power grid, disconnects the fan, and starts the battery test. When the display displays the CCA-

BATXXX information, press the BATTERY SELECTOR switch to select the battery capacity to be

tested. During this process, the display displays the word CCA flashing. After 10 seconds, the display

displays the CCAXXX information, which can range between 20A and 999A, with the CCA value

obtained in the reading and RiXXXX (internal battery resistance) in m the percentage of battery

charge is displayed in comparison to a new battery (selected at the beginning of the test).

This function can be used to test a battery bank that is within the maximum source specifications (for parallel connection, add CCA of each battery) however, it is more indicated that the test is done on individual batteries.

For proper operation, use 50mm2 x 30cm cables for 200A and 150A sources; 35mm2 x 30cm for 120A sources; and 16mm2 x 30cm for 70A, 60A and 40A sources; and make sure that the supply terminals are correct ly so in the terminals to the battery terminals.

BATTERY CHECK-UP FUNCTION (Cumulative Charge Meter) To perform a BATTERY CHECK-UP, proceed: The battery must be discharged to approximately 11V voltage. Turn on the source, press the key SELECTOR READING until the mode BATTERY CHECK-UP
is active (VOLTAGE and CURRENT LEDS ON). To reset the counter, hold down the key SELECTOR READING by 5 Seconds.

BATTERY CHECK-UP

CONTROL PANEL

VOLTAGE

AMPERAGE

READING SELECTOR

CCA – Ri m

METER

MODE SELECTOR

SELECTOR SLOW AUTO OUTPUT BATTERY VOLTAGE CHARGED
CHARGE ICS VOLTAGE super-x BATTERY

SLOW CHARGE PHASES 1.ELEVATION 2.ABSORPTION 3.EQUALIZATION

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL
Connect the battery to the charger and wait the indication light BATTERY LOADED (charging time may vary depending on battery capacity and the source used). Read in display a quantity from Amps than a battery Accumulated during o process from load.
Verify the value obtained is close to the amount of amperes specified by the battery manufacturer (e.g. If the battery charged is 60A, the obtained value should be close to 60A). The lower, in relation to the value indicated by the manufacturer, the worse the battery status. If a battery bank is used in parallel, add the currents of the seat batteries.
(Note: When the meter reaches 9 9 9 it must be reset to continue reading the accumulated charge on the battery).

VOLTAGE READING The X-LINE Source display allows you to view the output voltage (in Volts) that is being
applied at that time to the system. To access this voltage value, press the SELECTOR READING switch until the VOLTAGE INDICATOR LED lights up.

BATTERY CHECK-UP

CONTROL PANEL

VOLTAGE

AMPERAGE

READING SELECTOR
1
CCA – Ri m METER
MODE SELECTOR

SELECTOR

SLOW AUTO OUTPUT BATTERY VOLTAGE CHARGED
CHARGE ICS VOLTAGE super-x BATTERY

SLOW CHARGE PHASES 1.ELEVATION 2.ABSORPTION 3.EQUALIZATION

CURRENT READING The X-LINE Source display allows you to view the output current (in amperes) that is being
applied at that time to the system. To access this current value, press the SELECTOR READING switch until the CURRENT INDICATOR LED lights up.

PAINEL DE CONTROLE
CHECK-UP DA BATERIA

TENSÃO

CORRENTE

SELETOR LEITURA
1
MEDIDOR CCA – Ri m SELETOR MODO

SELETOR

CARGA AUTO TENSÃO BATERIA TENSÃO BATERIA

LENTA SCI SAÍDA

CARREGADA

CARGA LENTA 1. ELEVAÇÃO 2. ABSORÇÃO 3. EQUALIZAÇÃO

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL

CONSUMPTION – MINIMUM CABLE GAUGE – POWER

Model X-LINE 40A 60A 70A 120A 150A 200A

Max. Consumption
entry

Network Network 127Vac 220Vac

AC input cable (up to 10 meters)

DC output cable (up to 1 meter)

Max power. Output

600W

2,5mm2

6mm2

40A

900W

4mm2

10mm2

60A

1050W

4mm2

16mm2

70A

1800W

15A 8A

4mm2

25mm2

120A

2250W

18A 10A

6mm2

35mm2

150A

3000W

24A 14A

6mm2

50mm2

200A

TECHNICAL SPECIFICATIONS

X-LINE 40A

AC input

90 to 140Vac / 170 to 240Vac (Automatic Bi-volt)

Consumption with maximum load

600W

Maximum output current

40 Amperes

Selectable output voltage

12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V

SCI – Intelligent charging system

13,8 / 14,4 cyclic

3-phase slow load system – Customizable

Elevation /Absorption/ Equalization

Smart cooler – Smart ventilation system

Dynamic control by PWM

Precision voltmeter / ammeter

99% / 96%

Protections

Excesso de carga / Curto na saída / Temperatura

Dimensions L x A x P (mm)

259 x 151 x 58

Weight Kg

1,420

X-LINE 60A

AC input

90 to 140Vac / 170 to 240Vac (Automatic Bi-volt)

Consumption with maximum load

900W

Maximum output current

60 Amperes

Selectable output voltage

12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V

SCI – Intelligent charging system

13,8 / 14,4 cyclic

3-phase slow load system – Customizable

Elevation /Absorption/ Equalization

Smart cooler – Smart ventilation system

Dynamic control by PWM

Precision voltmeter / ammeter

99% / 96%

Protections

Overload / Short at output / Temperature

Dimensions L x A x P (mm)

259 x 151 x 58

Weight Kg

1,440

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL

X-LINE 70A

AC input

90 a 140Vac / 170 a 240Vac (Automatic Bi-volt)

Consumption with maximum load

1050W

Maximum output current

70 Amperes

Selectable output voltage

12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V

SCI – Intelligent charging system

13,8 / 14,4 cyclic

3-phase slow load system – Customizable

Elevation /Absorption/ Equalization

Smart cooler – Smart ventilation system

Dynamic control by PWM

Precision voltmeter / ammeter

99% / 96%

Protections

Overload / Short at output / Temperature

Dimensions L x A x P (mm)

259 x 151 x 58

Weight Kg

1,440

X-LINE 120A

AC input Consumption with maximum load Maximum output current Selectable output voltage SCI – Intelligent charging system 3-phase slow load system – Customizable Smart cooler – Smart ventilation system Precision voltmeter / ammeter Protections Dimensions L x A x P (mm) Weight Kg

90 a 140Vac / 170 a 240Vac (Automatic Bi-volt) 1800W 120 Amperes 12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V 13,8 / 14,4 cyclic Elevation /Absorption/ Equalization Dynamic control by PWM 99% / 96% Overload / Short at output / Temperature 279 x 163 x 86 2,050

X-LINE 150A

90 a 140Vac / 170 a 240Vac (Automatic Bi-volt) 2250W 150 Amperes 12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V 13,8 / 14,4 cyclic Elevation /Absorption/ Equalization Dynamic control by PWM 99% / 96% Overload / Short at output / Temperature 289 x 172 x 95 2,250

X-LINE SOURCES AND CHARGERS – INSTRUCTION MANUAL

X-LINE 200A

90 a 140Vac / 170 a 240Vac (Automatic Bi-volt) 3000W 200 Amperes 12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V 13,8 / 14,4 cyclic Elevation /Absorption/ Equalization Dynamic control by PWM 99% / 96% Overload / Short at output / Temperature 317 x 172 x 95 2,650

X-LINE 200A MONO

AC input

170 a 240Vac (mono-volt)

Consumption with maximum load

3000W

Maximum output current

200 Amperes

Selectable output voltage

12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V

SCI – Intelligent charging system

13,8 / 14,4 cyclic

3-phase slow load system – Customizable Smart cooler – Smart ventilation system
