SDXC™ UHS-II
Memory Card
Quick Start Guide
How to Use Wise SDXC UHS-II Memory Card
Before operating this media, please read this manual thoroughly, and retain it for future reference.
Components
- Wise SDXC UHS-II Memory Card
- Quick Start Guide
How to connect
Select the device compatible with a SD Card Reader.
Connect one end of the cable to the device and the other end to the reader with the card insert.
Tech Specs
| Model | SD-N128 | SD-N256 | SD-N512 |
| Capacity1 | 128GB | 256GB | 512GB |
| Video Speed Class | V90 | ||
| Maximum read2 | 290 MB/s | 290 MB/s | 290 MB/s |
| Maximum write2 | 260 MB/s | 260 MB/s | 260 MB/s |
| Minimum write2 | 90 MB/s | 90 MB/s | 90 MB/s |
| Size | 24 x 32 x 2.1 mm | ||
| Weight | 2 g | ||
| Operating voltage | VDD1: 2.7-3.6 V, VDD2: 1.70-1.95 V | ||
| Operating temperature | -13°F to 185°F (-25°C to 85°C) | ||
| Storage temperature | -40° F to 185°F (-40°C to 85°C) | ||
1 Some of the listed storage capacity is used for formatting and other purposes and is not available for data storage. 1GB = 1 billion bytes.
2 Speeds based on internal testing. Actual performance may vary.
Caution
- Wise shall not be responsible for any damage to or loss of recorded data.
- Recorded data may be damaged or lost in the following situations.
－If you remove this media or turn off the power while formatting, reading or writing data.
－If you use this media in locations subject to static electricity or electrical noise. - When this media is not recognized with your product, turn the power off and on again or restart the product after removing this media.
- Connecting the Wise SD cards to non-compatible devices may result in unexpected interference or malfunction of both products.
- Copyright law prohibits unauthorized use of recording.
- Do not strike, bend, drop or wet this media.
- Do not touch the terminal with your hand or any metal object.
- Do not expose the unit to rain or moisture.
- All Wise memory cards have a 2-year warranty. If you register your product here online, you can extend it to 3 years at no additional charge: www.wise-dvanced.com.tw/we.html
- Any damage caused by customers through neglect or incorrect operation may result in the warranty being void.
- For more information, please visit www.wise-advanced.com.tw
Wise Advanced is an authorized licensee of the SDXC™ trademark, which may be registered in various jurisdictions. Information, products, and/or specifications are subject to change without notice. The Wise logo is a trademark of Wise Advanced Co., Ltd.
SD-N Series
© 2022 Wise Advanced Co., Ltd.
www.wise-advanced.com.tw
Printed in Taiwan.
WISE ADVANCED CO., LTD.
© 2022 Wise Advanced Co., Ltd. All rights reserved.
Design and contents of this manual are subject to change without notice
All other trademarks are property of their respective owners.
