3208-96T-F2AL exacqVision EV-Series Hybrid

EV 2UA, F2A Hybrid-Series H410/X1313 Quick Start Guide

Introduction

The exacqVision EV-Series is a part of exacqVision’s series of
network video recorders (NVR). The exacqVision EV-Series Hybrid,
2UA, and F2A provide high-performance hardware with an exacqVision
surveillance video management software. The F2A hybrid model is a
rack-mounted system that features greater storage capacity and an
optional RAID 5 disk configuration.

Installation

Before starting the exacqVision server, ensure that you adhere
to the following requirements:

Electrical requirements
Mounting and operating environment requirements

Larger to make the connection, and label the grounding screw
near the power connector with the following image. Figure 2:
Grounding wire

Electrical environment requirements

500-00110 Rev. A 2022-07-01

Network connection requirements

This VLAN configuration reduces the chances of network traffic
conflicts and unauthorized access to the cameras.

Configuring the server

Turn on the server.
Open the exacqVision client application.
From the navigation tree, select System Setup, and select the
Network tab.
Choose one of the following options:
- To install the server on a network that uses static IP
  addressing, select Static and enter the IP address.
- To install the server on a network using DHCP (dynamic host
  configuration protocol), select Dynamic. If the information does
  not configure automatically, contact your network
  administrator.
Click Apply.
Repeat this procedure for any additional network ports. For
more information about configuring the server, refer to the
exacqVision Start User Manual.

Setting up remote access to the server

Configure the server through a remote exacqVision client.

Download the latest exacqVision Client software from the Exacq
website at: https://www.exacq.com/support/downloads.php
Install the client software on a system administrator
computer.
Confirm the connectivity with the server using the ping command
and the server’s IP address. If the client PC cannot communicate
with the server, contact your network administrator.

Remote access for administrative support

For administrative support to access to the server remotely,
configure remote desktop for Windows or SSH for Linux, depending on
the computer operating system. For more information, refer to the
following Exacq Knowledge Base articles:

Configuring the client

Start the exacqVision client application.
Click the Config (Setup) page icon.
From the navigation tree, select Add Systems.
In the System List select the server.
In the System Information area, type the exacqVision username
and password that you created during initial start-up.
Select the Connection Speed. Choose from the following options,
Remote, WAN, LAN or Local.
Verify that the server appears in the Systems list with a
status showing Connected.
Note: If the server does not connect to the client, check for
antivirus software on the remote client machine that may block
communication between the server IP addresses and ports.
Click Apply.

These instructions will help you to install and configure the
exacqVision EV-Series Hybrid, 2UA, and F2A network video recorders
(NVR). Before installing, ensure that you adhere to the
requirements mentioned in the manual. The manual also includes
instructions on configuring the server and the client for remote
access. Follow the instructions carefully to set up the system
correctly and use it effectively.

View Fullscreen

EV 2UA, F2A Hybrid-Series H410/X1313 Quick Start Guide
Introduction
The exacqVision EV-Series is part of exacqVision’s series of network video recorders (NVR). The exacqVision EV-Series Hybrid, 2UA and F2A provide high performance hardware with an exacqVision surveillance video management software. The F2A hybrid model is a rack mounted system and features greater storage capacity and an optional RAID 5 disk configuration.
Installation
Before you start the exacqVision server, ensure that you adhere to the following requirements:
Electrical requirements
· Do not replace NVR batteries. There is a risk of explosion if the battery is replaced with an incorrect battery. · Do not use this NVR in locations where children are likely to be present. · Only a skilled person must install the socket-outlet protective earthing connection. Use a green-yellow wire minimum 18 AWG. Figure 1: Socket-outlet protective earthing connection
Mounting and operating environment requirements
· Mount the exacqVision server in a dust-free and climate controlled location where the temperature is between 40°F to 95°F (4.5°C to 35°C), and the humidity level is less than 80% non-condensing. Note: Dust can cause components of the server to overheat, and elevated temperatures can contribute to premature hard drive failures.
· If the hard drives dispatch separately to the system, insert each drive into the appropriate hard drive slot, if they are numbered. · You can place a surge suppressor between the camera and the recorder of all outdoor cameras. · The server must connect permanently to the ground wire. Ensure this connection is made by a skilled individual. Use an 18 AWG wire or
larger to make the connection, and label the grounding screw near the power connector with the following image. Figure 2: Grounding wire
Electrical environment requirements
· For maximum reliability, connect the exacqVision server to an online UPS (uninterrupted power supply). An online UPS filters power surges and dips that can damage the server.
· Connect a mouse and keyboard to the server. · Connect the exacqVision server network interface cards (NIC) to the appropriate network switch ports. · Ensure that only a skilled person replaces the battery.
500-00110 Rev. A 2022-07-01

· Use cables with a ferrite core to connect to monitors. If the cables do not have a ferrite core, the unit still performs as expected but may not meet CE safety regulation standards.
Network connection requirements
· If the video surveillance system does not have a physically isolated network, connect all IP cameras and one server NIC to a dedicated camera VLAN (virtual LAN).
· Install the camera manufacturer’s software on a PC in this subnet, or configure the router to connect a client computer with the camera subnet. For information on how to configure the network, see Configuring the server.
This VLAN configuration reduces the chances of network traffic conflicts and unauthorized access to the cameras.
Configuring the server
1. Turn on the server. 2. Open the exacqVision client application. 3. From the navigation tree, select System Setup, and select the Network tab. 4. Choose one of the following options:
– To install the server on a network that uses static IP addressing, select Static and enter the IP address. – To install the server on a network using DHCP (dynamic host configuration protocol), select Dynamic. If the information does not
configure automatically, contact your network administrator. 5. Click Apply. 6. Repeat this procedure for any additional network ports. For more information about configuring the server, refer to the exacqVision Start
User Manual.
Setting up remote access to the server
Configure the server through a remote exacqVision client. 1. Download the latest exacqVision Client software from the Exacq website at: https://www.exacq.com/support/downloads.php 2. Install the client software on a system administrator computer. 3. Confirm the connectivity with the server using the ping command and the server’s IP address. If the client PC can not communicate with the server, contact your network administrator.
Remote access for administrative support
For administrative support to access to the server remotely, configure remote desktop for Windows, or SSH for Linux depending on the computer operating system. For more information, refer to the following Exacq Knowledge Base articles:
· Using remote desktop to manage Windows-based exacqVision servers: https://support.exacq.com/#/knowledge-base/article/579 · Enabling/Disabling SSH on exacqVision Linux Server: https://www.exacq.com/kb/?kbid=6186
Configuring the client
1. Start the exacqVision client application. 2. Click the Config (Setup) page icon. 3. From the navigation tree, select Add Systems. 4. In the System List select the server. 5. In the System Information area, type the exacqVision user name and password that you created during initial start up. 6. Select the Connection Speed.
Choose from the following options, Remote, WAN, LAN or Local. 7. Verify that the server appears in the Systems list with a status showing Connected.
Note: If the server does not connect to the client, check for antivirus software on the remote client machine that may block the communication between the server IP addresses and ports. 8. Click Apply.

EV 2UA, F2A Hybrid-Series H410/X1313 Quick Start Guide

Connecting the cameras

1. Connect the analog cameras, PTZ serial cables, or alarm I/O. For more information, see Connections.

Note: Connections vary by model. 2. Using the camera manufacturer’s software, configure the IP address for all the cameras, and record this information for future reference.

Note: Do not change the user name and password until after you establish connectivity with the exacqVision server.

For additional information, see the camera manufacturer’s website or the exacqVision IP Camera Quick Start Guide at http://

www.exacq.com/downloads/ev-ip-quickstart-0311.pdf. You can also find the Quick Start Guide in the Quickstarts directory on the CD that

Exacq dispatches with your system.

3. To determine the compatibility of a particular camera model and firmware combination with exacqVision servers, use the following link: http://www.exacq.com/support/ipcams.php

4. Test the connectivity between the camera and the server by completing the following steps:

Log off from the operating system user account.

Type the camera’s IP address into the address bar on your Internet browser.

Press Enter. If the browser does not display an introductory or log on window, the camera is not establishing a connection with

the server. Check the exacqVision User Manual, and www.exacq.com/kb for a solution if the problem persists.

5. Repeat this process for all other camera connections.

Connections

The following images and tables show the configuration options for the server’s back panel. Configurations vary depending on the system you purchase.
Figure 3: Configuration A: EV-Series Hybrid 2UA and F2A System back panel

Callout A B
C D
E

Name Power Video out
10/100/1000 Ethernet USB 3.0/3.1
Audio in/out

No. of ports 1 3
2 4
3-5

Description 100-240VAC 50/60Hz. Power port (A1) and power switch (A2). VGA (B1), Display port (B2), and HDMI (B3). Use a maximum of three video outputs simultaneously. Dual onboard NICs, 2.5Gbps (blue) and 1Gbps (black). USB, keyboard, mouse, memory device, or DVD burner. USB 3.0 (D1) and USB 3.1 (D2). Line in (blue), line out (green), microphone (pink).

EV 2UA, F2A Hybrid-Series H410/X1313 Quick Start Guide

Figure 4: Configuration B: EV-Series Hybrid 2UA and F2A System back panel

Callout A B C

Name Power PS/2 connector Video out

No. of Ports 1 1 3

USB3.0/3.1

Audio in/out

10/100/1000 Ethernet

Serial ports

Auxiliary connections

Description 100-240VAC 50/60Hz. Power port (A1) and power switch (A2). PS/2 port. HDMI Port (C1) Display Port (C2), VGA (C3) . You can use a maximum of three video outputs simultaneously. USB keyboard, mouse, memory device, or DVD burner. USB 3.1 (D1 and D3) and USB 3.0 (D2). Line in (blue), line out (green), microphone (pink). Dual onboard NICs, 2.5 Gbps (blue), (F1) and 1Gps (black), (F2). Serial port

Figure 5: EV-Series hybrid system auxiliary connections

Table1: EV-Series hybrid system auxiliary connections

1-16
G NO C NC G
Tx+ TxRx+ Rx-
1-16 G 1-16

Audio Block Connections Line level audio in 1-16
Relay Block Connections Common for all inputs Normally open relay output #1 (24V/1A max) Relay common Normally closed relay output #2 (24V/1A max) Common for all inputs
RS-485 Block Connections PTZ control PTZ control PTZ control PTZ control
Trigger Inputs/Alarm Outputs Blocks Trigger inputs 1-16 Common for all inputs Alarm outputs 1-16
