Ryobi Pcl480 One+ 18v Multi Tool Accessory Kit User Manual

ROTARY TOOL ACCESSORY KIT
OPERATOR’S MANUAL

PCL480 ONE+ 18V Multi Tool Accessory Kit

WARNING:
Do not use any attachments or accessories not recommended by the manufacturer of this product. The use of attachments or accessories not recommended can result in serious personal injury.
DANGER:
If you are changing an accessory immediately after use, be careful not to touch the collet, collet nut, or the accessory with your hands or fingers. You will get burned because of the heat buildup from cutting. Always use the wrench provided.

ACCESSORY TABLE

Figure	Qty	Accessory	Application	RPM MAX
	1	1/16 in. Engraving Bit	Engraving metal, wood, and plastics	35K
	1	1/8 in. High Speed Steel Drill Bit	Drilling	35K
	1	1/8 in. High-speed Cutter	Engraving metal, wood, and plastics	35K
	1	1/8 in. Screw Mandrel	Holding polishing wheels	15K
	2	(1) 1/2 in. Drum Sanding Mandrel (1) 1/4 in. Drum Sanding Mandrel	Holding sanding drums	35K
	12	(2)  1/4 in. 60 Grit Sanding Band (3)  1/4 in. 120 Grit Sanding Bands (2) 1/2 in. 60 Grit Sanding Bands (2)  1/2 in. 120 Grit Sanding Bands (3)  1/2 in. 240 Grit Sanding Bands	Sanding wood, metal, and plastics	35K
	4	(2) 1/2 in. Felt Polishing Wheels (2) 1 in. Felt Polishing Wheels	Polishing and buffing metals, stone, glass and ceramics	15K
	1	Polishing Compound Vial	Used with felt polishing wheels to polish metal and plastic	N/A
	1	Carbon Steel Brush	Cleaning and deburring metal, rust and paint	15K
	3	(1) 3/8 in. Arch Aluminum Oxide Grinding Stone (1) 3/8 in. Cylinder Aluminum Oxide Grinding Stone (1) 1/4 in. Pointed Aluminum Oxide Grinding Stone	Sharpening and deburring metals, steel, and rust	35K
	1	3/32 in. Diamond Wheel Point Engraving Cutter	Engraving metal, wood, and plastics	35K
	1	1/8 in. Twist Lock Mandrel	Attaching cut-off wheels	35K
	6	1-1/2 in. Twist Lock Cut Off Wheels	Cutting nails, screws, thin metal and wood, and plastic	35K
	1	Wrench	Changing accessories on collet	N/A

REGISTER YOUR TOOLS
http://regIster.ryobitooIs.corn
1-800-525-2579
ONE WORLD TECHNOLOGIES, INC.
1428 Pearman Dairy Road, Anderson, SC 29625
Phone 1-800-525-2579
États-Unis, Telephone 1-800-525-2579
USA, Telefon 1-800-525-2579
www.ryobitools.com
998000829
11-4-21 (REV:01)
