1678 Industrial Solvent Parts Cleaner
Product Information
The Model 1678 80g Agitation Unit is an Industrial Solvent Parts
Cleaner designed to clean parts, using a mineral spirits based
solvent. The system is economical, safe, and innovative. Solvents,
when used to clean grease and oil, must be disposed of properly.
The unit should be installed on a flat, level surface in an area
with adequate ventilation. The parts cleaner is connected to a
properly grounded power source and has a serial plate for power
requirements. The unit is not intended for outdoor operation. The
cover is designed to close automatically in the event of a
fire.
Product Usage Instructions
- Read and understand all labels, MSDS, and the instruction
manual before use. - Install the parts cleaner on a flat, level surface in an area
provided with adequate ventilation. - Connect the parts cleaner to a properly grounded power source
and check the serial plate for power requirements. - Wear protective eyewear, gloves, and clothing to avoid contact
with eyes or skin. - Conduct operation in a manner that prevents splashing or
spillage. Promptly and properly clean up any spills with absorbent
material. Remove and dispose of all soaked material in accordance
with regulatory requirements. - Do not use compressed air to dry parts as this may cause a high
concentration of vapors in the immediate area. Local exhaust
ventilation should be used in areas of high vapor
concentration. - Do not allow the parts cleaner to operate unattended.
- Keep cover closed whenever the unit is not in use.
- Do not remove fluid from this equipment or it may cause
malfunction or unsafe conditions. - Do not modify, alter, or obstruct the operation of the fusible
link. - If an extension cord is necessary, use a cord with a current
rating equal to or more than that of the equipment. Cords rated for
less current than the equipment may overheat. Arrange the cord so
that it will not be tripped over or pulled. - Always unplug equipment from electrical outlet when not in use.
Grasp plug and pull to disconnect. Never use the cord to pull the
plug from the outlet. - To reduce the risk of fire, do not operate equipment in the
vicinity of open containers of flammable liquids (gasoline).
MODEL 1678
80g Agitation Unit
Operating Manual
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948
INTRODUCTION
GENERAL INSTRUCTIONS
CAUTION
READ AND UNDERSTAND ALL LABELS, MSDS, AND THIS INSTRUCTION MANUAL BEFORE USE.
The Industrial Solvent Parts Cleaner is an economical, safe, and innovative system designed to clean parts, using a mineral spirits based solvent. Solvents, when used to clean grease and oil, must be disposed of properly. Consult your local environmental management agency for additional guidance and other potentially hazardous materials compliance requirements.
Install your parts cleaner on a flat, level surface in an area provided with adequate ventilation. Avoid repeated or prolonged breathing of vapors. Do NOT use compressed air to dry parts as this may cause a high concentration of vapors in the immediate area. Local exhaust ventilation should be used in areas of high vapor concentration. Provisions for determining and maintaining adequate ventilation are the responsibility of the operator.
Make sure the parts cleaner is connected to a properly grounded power source. Check serial plate for power requirements.
Do not allow parts cleaner to operate unattended.
Complete safety in use is dependent upon proper use and handling of the parts cleaner in your workplace.
It is important that you follow the instructions provided in this manual. If you fail to read, understand, and follow all of the procedures in this manual, you may cause or suffer personal injury.
DO NOT OPERATE ELECTRICAL EQUIPMENT INSIDE OF PARTS CLEANER.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 2
CAUTION
USE ONLY MINERAL SPIRITS BASED SOLVENTS DO NOT USE WATER-BASED CLEANING SOLUTIONS This equipment is designed for use only with mineral spirit based solvents with a flash point greater than 40°C (104°F). Do NOT add any other chemicals to the cleaning agent including, but not limited to, kerosene, fuel oil, gasoline, or chlorinated solutions. The use of any other solutions could potentially cause a hazardous condition.
Avoid contact with eyes or skin. Wear protective eyewear, gloves, and clothing. Operation should be conducted in a manner, which prevents splashing, or spillage. Any spills should be promptly and properly cleaned up. Soak up all spills with absorbent material. Remove and dispose of all soaked material in accordance with regulatory requirements.
This unit is NOT intended for outdoor operation. Do NOT leave solvent-soaked rags in parts cleaner or in uncovered containers. Do NOT obstruct the cover. It is designed to close automatically in the event of a fire. The safety link and cover
closing mechanism must be intact. Do NOT substitute with any other type of cover positioning device. Do NOT leave large objects in the parts cleaner or hang anything on the cover that could prevent the cover from closing in the event of a fire. Do NOT place heavy objects on edges or front of sink. Although this parts cleaner is designed to be stable, uneven weight distribution could cause a hazardous condition. Do NOT contaminate cleaning solvents with gasoline, alcohol or flammable liquids. When cleaning carburetors or other fuel supplying components: remove all gasoline into a proper disposal container before placing the component into the parts cleaner. Do NOT spray aerosols into or around this machine. Install the equipment in an area away from heat, sparks, and open flame. Never put hot parts into the solution. Do NOT use compressed air to dry parts. Be sure parts, especially brake parts, are completely dry prior to reassembly. Turn unit “OFF” and close lid when equipment is not in use. This will reduce evaporation.
IMPORTANT SAFETY INSTRUCTIONS
1. Read all instructions. 2. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged until it has
been examined by a qualified service person.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 3
3. If an extension cord is necessary, a cord with a current rating equal to or more than that of the equipment should
be used. Cords rated for less current than the equipment may overheat. Care should be taken to arrange the cord so that it will not be tripped over or pulled.
4. Always unplug equipment from electrical outlet when not in use. Never use the cord to pull the plug from the
outlet. Grasp plug and pull to disconnect.
5. To reduce the risk of fire, do NOT operate equipment in the vicinity of open containers of flammable liquids
(gasoline).
6. To reduce the risk of electric shock, do NOT use on wet surfaces or expose to rain. 7. Use only as described in this manual. Use only manufacturer’s recommended attachments. 8. ALWAYS WEAR PROPER PPE 9. Do NOT operate any electrical equipment inside sink or vat. 10. Do NOT use light bulbs rated over 40 watts. 11. Do NOT smoke, eat or drink in the work area. 12. Do NOT modify these machines. 13. Do NOT operate this unit in any manner that will cause splashing or cause mist to form. 14. Use only the mineral spirit based solvent provided. 15. Adjust flexible nozzle or flow-thru brush so solution is directed to inside the sink only. 16. On the Control box, set the breaker switches to OFF before plugging in unit. 17. In any emergency, turn off the unit. 18. These parts washers employ a safety feature called a fusible link that holds the cover open during use. Do NOT
modify, alter, or obstruct the operation of the fusible link.
19. Keep cover closed whenever unit is not in use. 20. Do NOT remove fluid from this equipment or it may cause malfunction or unsafe conditions.
SAVE THESE INSTRUCTIONS
SERVICE
Call your representative should your parts cleaner need service and always unplug unit when servicing. Inspect and keep in good working order the power cord and all electrical components. If components show
signs of damage or wear replace immediately. All work should be done by a trained technician.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 4
Do NOT replace pump before unplugging unit. Do NOT replace fusible link with any other device to hold lid up. If fusible link should fail, for any reason, call
your representative immediately.
INSTALLATION
Position equipment on a hard level surface in a well-ventilated area. Check to make sure that the rollers are on the roller guides. The rollers are located inside of the machine on
the back of the lift. Mount the cylinder housing to the machine, and secure with four 10-32 screws. CAUTION: Make sure not to
pinch any air lines. Connect an air supply line of 80-120 PSIG (5.5-8.3bar) to the air inlet on the back of the control box. Turn the agitation selector switch to the up, down, and agitate positions to make sure the machine operates
correctly. Fill solution reservoir to the correct level. This equipment is designed for use only with a mineral spirit based
solvents with a flash point greater than 40º C (104º F). Do NOT add any other chemicals to the cleaning agent including, but not limited to, kerosene, fuel oil, gasoline, or chlorinated solutions. The use of any other solutions could potentially cause a hazardous condition.
Capacity Model 1678 = 80 gal. (303 L.) Minimum Level = 48 gal. (182 L.)
Power Requirements: o For the pump to function properly, it must be plugged into the receptacle on the back of the control box (right side of the machine). The power cord from the control box must be connected to a properly grounded power source. Check serial plate for power requirements. 115 Volt Pump: 115 volt, 1amp, 60 Hz, 1PH
Weight capacity for this parts cleaner is 250LBS. Do not exceed rated load.
ADDITIONAL SPECIFICATIONS Overall Dimensions: 33″W x 51 1/2″L x 66 1/2″H Inside Dimensions: 27 1/4″W x 44 1/2″L x 28″D Carrier Dimensions: 17 1/2″ W x 41 1/2″ L Shipping Dimensions: 36 1/4″ W x 56 1/2″ L x 56 1/2″ H
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 5
Shipping Weight: 556lbs. Fluid Capacity: 80 Gallons Load Lift Over: 38″ 115Vac 60Hz 1PH 1Amp Pump HP: Fractional Load capacity: 250lbs. Lift Air Requirements: 8CFM@120PSI
OPERATING INSTRUCTIONS
LOADING (Requires the platform to be in the “UP” position). 1. Open the cover by lifting up. 2. Turn the “PLATFORM CONTROL VALVE” to the “UP” position. 3. When the platform is in its upper-most position, place load on the shelf. DO NOT EXCEED 250 LBS! DO NOT DROP PARTS ON PLATFORM!
AGITATION OPERATION 1. Turn the “PLATFORM CONTROL VALVE” to the “AGITATE” position. When the platform reaches the bottom position it will begin agitating. 2. To adjust the agitation speed, turn the “PLATFORM SPEED CONTROL” knob counterclock wise to increase and clock wise to decrease the speed. Note: The speed control has a locking feature, if it will not turn, pull up on the knob. 3. To reduce evaporation, close the cover while the parts are agitating.
SOAKING OPERATION 1. Turn the “PLATFORM CONTROL VALVE” to the “DOWN” position. 2. Close the cover to reduce evaporation while the parts are soaking.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 6
UNLOADING OPERATION 1. Open the lid of the parts washer. 2. Turn the “PLATFORM CONTROL VALVE” to the “UP” position. 3. When the platform is in its upper-most position, allow parts to drain before removing.
MANUAL PARTS CLEANING OPERATION 1. Open the lid. 2. Turn the “PLATFORM CONTROL VALVE” to the “UP” position. 3. Turn the pump switch to the “ON” position. 4. Manually clean the parts using the brush. 5. Turn the pump switch to the “OFF” position. 6. Place brush in the brush holder. 7. Unload parts or continue to clean in the agitation operation.
MACHINE DIAGRAM
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 7
ITEM 1 2 3 4 5 6 7 8 9
BACK MOUNT PUMP 59650
59659-01 55449 8939 8440 01158 03500 8169 57148
TOP MOUNT PUMP 59650 54916 55449 8939 8440 01158 03500 8169 57148
DESCRIPTION CONTROL BOX (SEE DETAIL) PUMP ASSY DOOR CLOSURE CYLINDER ROLLER, LH ROLLER, RH ROLLER, UPPER BRUSH FUSIBLE LINK
ITEM 1 2 3 4 5 6 7 8
Control Box Assembly
115V 58387 56968 59757 59756 58531 01122 59656 01132
DESCRIPTION FILTER/REGULATOR ASSY NOT VALVE ASSY REGULATOR ASSY, AGITATION SWITCH ASSY, 3 POSITION SPEED CONTROL ASSY ROCKER SWITCH POWER CORD RECEPTACLE
NOTICE:
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 8
THIS MACHINE IS PRESET AT THE FACTORY TO OPERATE WITH A MINIMUM OF 100 LBS ON THE AGITATION PLATFORM. IF YOU INTEND TO OPERATE THE MACHINE WITH LOADS LESS THAN 100 LBS, YOU WILL NEED TO LOWER THE PRESSURE SETTING ON THE AGITATION REGULATOR ON THE BOTTOM OF THE CONTROL BOX.
1. Place a typical load on the platform. 2. Turn the selector switch to agitate. 3. Pull out on the adjustment knob on the agitation regulator. 4. Rotate the agitation regulator adjustment knob counter clockwise until the lift begins to agitate. 5. Push in the adjustment knob on the regulator to lock the setting.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 9
TROUBLESHOOTING
1. Make sure the parts cleaner is connected to electric power and/or air supply.
2. Check for incoming power. Check serial plate for power requirements.
3. On electric units: check reset button on GFCI cord to make sure it is not tripped. On air units: an increase in air supply may be required.
LITTLE OR NO FLUID FLOW
POSSIBLE CAUSE Power cord not plugged in. Pump Switch not turned on. Inlet to pump obstructed. Crimped/Pinched hose. Not enough fluid in the tank.
SOLUTION Plug in power cord Turn on pump switch Remove obstruction Check the hoses, straighten as needed Add fluid to fill level
NO AGITATION
POSSIBLE CAUSE No air connected to the machine. Not enough air. Too much weight on the lift. Speed control turned off. Crimped air line.
SOLUTION Connect to a clean/dry air supply Check serial plate for air recommendations Remove some of the weight / 250lbs. Max Adjust agitation speed Check air lines, straighten crimp
AGITATES AT TOP OF STROKE
POSSIBLE CAUSE Not enough weight on the lift. Too much weight on the lift. Wrong agitation pressure. Not enough air.
SOLUTION Add weight, factory tested with 100lbs. Remove some of the weight / 250lbs. Max Adjust the regulator on the up/down switch Check serial plate for recommended air pressure
