1634 30g Tank Unit
Product Information: MODEL 1634 30g Tank Unit
The Industrial Solvent Parts Cleaner is an innovative system
designed to clean parts using a mineral spirit-based solvent. It is
an economical and safe option for cleaning grease and oil from
parts. However, it is important to dispose of solvents properly.
This product is manufactured by Heritage-Crystal Clean, LLC and is
located at 2000 Center Drive, Suite East C300 Hoffman Estates, IL
60192. The product’s phone number is 877-938-7948.
Product Usage Instructions
- Read and understand all labels, MSDS, and the instruction
manual before use. - Install the parts cleaner on a flat, level surface in an area
with adequate ventilation. Avoid breathing vapors for prolonged
periods. - Ensure the parts cleaner is connected to a properly grounded
power source. Check the serial plate for power requirements. - Do not operate electrical equipment inside the parts
cleaner. - Use only mineral spirits-based solvents. Do not use water-based
cleaning solutions. - Wear protective eyewear, gloves, and clothing to avoid contact
with eyes or skin. - Conduct operation in a manner that avoids splashing or
spillage. Clean up any spills promptly and properly with absorbent
material and dispose of soaked material in compliance with
regulatory requirements. - Do not leave solution-soaked rags in the parts cleaner or in
uncovered containers. - Do not obstruct the cover as it is designed to close
automatically in the event of a fire. - Read all instructions carefully before use. Failure to follow
procedures may cause personal injury. - Do not use compressed air to dry parts as it may cause a high
concentration of vapors in the immediate area. Use local exhaust
ventilation in areas of high vapor concentration. - Complete safety in use is dependent upon proper use and
handling of the parts cleaner in your workplace. - Do not use the unit for outdoor operation.
Important Safety Instructions
- Read all instructions carefully before use.
- Do not operate the parts cleaner unattended.
- If an extension cord is necessary, use a cord with a current
rating equal to or more than that of the equipment to prevent
overheating. Arrange the cord to avoid tripping or pulling. - Always unplug equipment from the electrical outlet when not in
use. Never use the cord to pull the plug from the outlet. Grasp the
plug and pull to disconnect. - To reduce the risk of fire, do not operate equipment in the
vicinity of open containers of flammable liquids. - Ensure that the safety link and cover have been examined by a
qualified service person.
MODEL 1634
30g Tank Unit
Operating Manual
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948
INTRODUCTION
GENERAL INSTRUCTIONS
CAUTION
READ AND UNDERSTAND ALL LABELS, MSDS, AND THIS INSTRUCTION MANUAL BEFORE USE.
The Industrial Solvent Parts Cleaner is an economical, safe, and innovative system designed to clean parts, using a mineral spirit based solvent. Solvents, when used to clean grease and oil, must be disposed of properly. Consult your local environmental management agency for additional guidance and other potentially hazardous materials compliance requirements.
Install your parts cleaner on a flat, level surface in an area provided with adequate ventilation. Avoid repeated or prolonged breathing of vapors. Do NOT use compressed air to dry parts as this may cause a high concentration of vapors in the immediate area. Local exhaust ventilation should be used in areas of high vapor concentration. Provisions for determining and maintaining adequate ventilation are the responsibility of the operator.
Make sure the parts cleaner is connected to a properly grounded power source. Check serial plate for power requirements.
Do not allow parts cleaner to operate unattended.
Complete safety in use is dependent upon proper use and handling of the parts cleaner in your workplace.
It is important that you follow the instructions provided in this manual. If you fail to read, understand, and follow all of the procedures in this manual, you may cause or suffer personal injury.
DO NOT OPERATE ELECTRICAL EQUIPMENT INSIDE OF PARTS CLEANER.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 2
CAUTION
USE ONLY MINERAL SPIRITS BASED SOLVENTS DO NOT USE WATER-BASED CLEANING SOLUTIONS
This equipment is designed for use only with mineral spirit based solvents with a flash point greater than 40°C (104°F). Do NOT add any other chemicals to the cleaning agent including, but not limited to, kerosene, fuel oil, gasoline, or chlorinated solutions. The use of any other solutions could potentially cause a hazardous condition.
Avoid contact with eyes or skin. Wear protective eyewear, gloves, and clothing. Operation should be conducted in a manner, which prevents splashing, or spillage. Any spills should be promptly and properly cleaned up. Soak up all spills with absorbent material. Remove and dispose of all soaked material in accordance with regulatory requirements.
This unit is NOT intended for outdoor operation. Do NOT leave solution-soaked rags in parts cleaner or in uncovered containers. Do NOT obstruct the cover. It is designed to close automatically in the event of a fire. The safety link and cover
closing mechanism must be intact. Do NOT substitute with any other type of cover positioning device. Do NOT leave large objects in the parts cleaner or hang anything on the cover that could prevent the cover from closing in the event of a fire. Do NOT place heavy objects on edges or front of sink. Although this parts cleaner is designed to be stable, uneven weight distribution could cause a hazardous condition. Do NOT contaminate cleaning solutions with gasoline, alcohol or flammable liquids. When cleaning carburetors or other fuel supplying components: remove all gasoline into a proper disposal container before placing the component into the parts cleaner. Do NOT spray aerosols into or around this machine. Install the equipment in an area away from heat, sparks, and open flame. Never put hot parts into the solution. Do NOT use compressed air to dry parts. Be sure parts, especially brake parts, are completely dry prior to reassembly. Turn unit “OFF” and close lid when equipment is not in use. This will reduce evaporation.
IMPORTANT SAFETY INSTRUCTIONS
1. Read all instructions.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 3
2. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged until it has
been examined by a qualified service person.
3. If an extension cord is necessary, a cord with a current rating equal to or more than that of the equipment should
be used. Cords rated for less current than the equipment may overheat. Care should be taken to arrange the cord so that it will not be tripped over or pulled.
4. Always unplug equipment from electrical outlet when not in use. Never use the cord to pull the plug from the
outlet. Grasp plug and pull to disconnect.
5. To reduce the risk of fire, do NOT operate equipment in the vicinity of open containers of flammable liquids
(gasoline).
6. To reduce the risk of electric shock, do NOT use on wet surfaces or expose to rain. 7. Use only as described in this manual. Use only manufacturer’s recommended attachments. 8. ALWAYS WEAR PROPER PPE 9. Do NOT operate any electrical equipment inside sink or vat. 10. Do NOT use light bulbs rated over 40 watts. 11. Do NOT smoke, eat or drink in the work area. 12. Do NOT modify these machines. 13. Do NOT operate this unit in any manner that will cause splashing or cause mist to form. 14. Use only the aqueous solution provided. 15. Adjust flexible nozzle or flow-thru brush so solution is directed to inside the sink only. 16. On the Control box, set the breaker switches to OFF before plugging in unit. 17. In any emergency, turn off the unit. 18. These parts washers employ a safety feature called a fusible link that holds the cover open during use. Do NOT
modify, alter, or obstruct the operation of the fusible link.
19. Keep cover closed whenever unit is not in use. 20. Do NOT remove fluid from this equipment or it may cause malfunction or unsafe conditions.
SAVE THESE INSTRUCTIONS
SERVICE
Call your representative should your parts cleaner need service and always unplug unit when servicing.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 4
Inspect and keep in good working order the power cord and all electrical components. If components show signs of damage or wear replace immediately. All work should be done by a trained technician.
Do NOT replace pump before unplugging unit. Do NOT replace fusible link with any other device to hold lid up. If fusible link should fail, for any reason, call
your representative immediately.
INSTALLATION
Open carton and inspect for damage. Remove the shelves, and legs. Open the cover and remove the parts basket. Close the cover and flaps on the carton. Turn the carton upside down, and open the bottom flaps. Assemble the legs to the brackets on the bottom of the tank. The bolt package is located in the parts basket.
DO NOT tighten the bolts at this time. Remove the packing from the shelves, and assemble the lower shelf inside the four (4) legs using the
remainder of the bolts from the bolt package. Turn the assembly over onto its legs and remove the carton and packaging. Tighten all screws. Open the tank and place the inner shelf and basket inside the machine. Fill the machine with 15 to 30 gallons of a mineral spirit based solvents. Do NOT add any other chemicals to
the cleaning agent including, but not limited to, kerosene, fuel oil, gasoline, or chlorinated solutions. The use of any other solutions could potentially cause a hazardous condition. Plug the power cord into a properly grounded power source. See serial number plate for proper voltage.
Power Requirements = 15 amp, 115 volt 60 Hz Weight capacity for this parts cleaner is 150 LBS
ADDITIONAL SPECIFICATIONS Overall Dimensions: 26 1/2″W x 34 1/2″L x 63″H Inside Dimensions: 24″W x 32″L x 7 1/2″D Shipping Weight: 131lbs. 115Vac/60HZ/1PH 1 Amp
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 5
MACHINE DIAGRAMS
ITEM 1 2 3 4 5 6 7 8 9 10
QTY 1 1 1 1 1 1 1 1 4 1
PART NO 59491 54267 59480-3 6024 50560 50542 50576 50562 50563
6932
DESCRIPTION COVER DOOR CLOSURE ASSY MODULE ASSY (SEP BOM) FLEXIBLE HOSE INNER SHELF PARTS BASKET FILTER. HOG HAIR LOWER SHELF LEG HARDWARE PKG (24 N/B)
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 6
MODULE ASSEMBLY
ITEM 1 2 3 4 5 6 7 8 9 10 11
QTY 1 1 1 1 1 1 1 1 1 1 1
PART NO 59480-3 59484 58423 60240 58415 59485 51389 54242
8612 01122 57387
DESCRIPTION MODULE ASSY HOUSING WELDMENT COVER, MODULE CTRL BOX COVER, CTRL BOX PANLE, FRONT FILTER ASSY PUMP ASSY POWER CORD SWITCH RECEPTACLE 115V
TROUBLESHOOTING
Machine does not operate:
Make sure the parts cleaner is connected to electric power or air supply. Check for incoming power. Check serial plate for power requirements. On electric units: check reset button on GFCI cord to make sure it is not tripped.
Little or no fluid flow thru the flow-thru brush:
Turn pump switch “ON” or increase air pressure.
Heritage-Crystal Clean, LLC 2000 Center Drive, Suite East C300 Hoffman Estates, IL 60192 877-938-7948 7
Check the fluid level in the tank. Check pump intake for obstructions.
