Eira Er3106 Pcie X1 To Usb 3.2 Gen1 Card 4 Type C Ports User Manual

ER3106 PCIe x1 to USB 3.2 Gen1 Card 4 Type C Ports

Product Information

Product Name: EiRA ER3106 PCIe x1 to 4-port Type-C GEN1
interface extension card

Type: PCIe x1 to USB 3.2 Gen1 Card

Model: ER3106

Features: 4 * Type C Ports, Type-CX4 Power indicator,
15Pin SATA power supply port

Compatibility: PCIe X1 is compatible with x4/x8/X16 card
slots

Interface: Type-C GEN1 with 5Gbps bandwidth

Power Supply: Dual power supply interface – PCIe
interface + 15Pin SATA

Size: 116mm (L) * 120mm (W) * 18.6mm (H)

Supported Systems: Windows 7/8/10/11, Linux

Product Usage Instructions

1. Connect the 15pin SATA power cable to the motherboard and the
   hard disk.
2. To initialize the new hard disk, follow these steps:
   1. Open the “Computer” window.
   2. Select “Manage” and then click on “Disk Management”.
   3. Find the new disk in the list.
3. To format the new hard disk, there are two methods:
   1. Method 1:
      1. Right-click on the external disk in the “Disk Management”
         window.
      2. Select “New Simple Volume”.
      3. Follow the instructions to choose the size of the partition and
         click “Next” to finish.
   2. Method 2:
      1. Open the “Computer” window.
      2. Find the new hard disk in the list of drives.
      3. It is now ready to be used.

Note: It is important to initialize the partitioned hard
disk when connecting the USB interface to a new removable hard
disk.

Remark: There are two types of formatting available – MBR
and GPT. The capacity of an SSD can also be viewed in the “Disk
Management” window.

User Manual
PCIe x1 to USB 3.2 Gen1 Card (4 * Type C Ports) ER3106

Introduction
Product name EiRA ER3106 PCIex1 to 4-port Type-C GEN1 interface extension card
Type-CX4 Power indicator 15Pin SATA power supply port

PCIE X1

Item name Support Interface Connector power supplys Size System

PCIex1 to 4-port Type-C GEN1 interface extension card Mobile hard disk drive PCIe X1 is compatible with x4/x8/ X16 card slots Type – C GEN1 5Gbps bandwidth PCIe interface +15Pin SATA dual power supply interface 116 (L)*120(W)*18.6( H) MM Windows7/8/10/11/Linux

Note Initialize the partitioned hard disk step when the USB interface is connected to the new removable hard disk
New hard disk format 1. View ” comput er – Manage – disk management ” to Find the new disk .

New hard disk format 2. Right click the “External disk” , then click “New Simple Volume”.

Quick Installation Guide
Installation 1 . Insert express card to PCIe×1/4/8/16 slot on motherboard; 2 . Fix full profile bracket with tower panel of PC.

Quick Installation Guide Installation 3 . Connect 15pin SATA power cable with motherboard and

PCIe×1/4/8/16

Hard disk Partition
3According to the inst ruct ion, choos e the size of part it ion, then click “Next ” to finish.

Hard disk Partition 4Then you can find the new hard disk in the “Comput er”,
it’s ready to be use.

initialization, partition and format
1.1View”computer – Manage – disk management”to Find the new disk . Remark There two types MBR and GPT. SSD capacity <=2T, please choose MBR, if more than 2T, choose GPT. 2.2 Right click the “Disk 1”, then click “New Simple Volume”.
