JBL Club 422
Club 322F
Club 3412T
Club 422F
Club 522F
Club 602C
Club 602CTP
Club 620F
Club 622
Club 6422F
Club 8622F
Club 9632
Club 422F
Specifications
- Type: 4″ (100mm) Two-Way Car Speaker
- Power Handling: 35W RMS, 105W peak
- Sensitivity (@ 2.83V): 90dB
- Frequency Response: 75Hz 20kHz
- Nominal Impedance: 3.0 ohms
Thiele-Small Parameters
- BL (Tm): 3.783
- DCR (ohms): 2.46
- Mms (g): 6.608
- Sd (cm2): 63.62
- Cms (m/N): 0.750
- Vas (l): 4.2937
- Fs (Hz): 71.5
- Qes: 0.510
- Qms: 6.495
- Qts: 0.473
- Crossover Point: 3kHz
