Fleet Management Dashboard
Product Information
The product is called X-Rite Link, a fleet management dashboard
provided by X-Rite Pantone. It offers centralized fleet management
and color insights. Users can access X-Rite Link through the
website link.xrite.com using their existing My X-Rite login
credentials.
Admins Quick Start Guide
- A system administrator will grant you access to X-Rite
Link. - You will receive a welcome email from [email protected].
- Login using your existing My X-Rite login credentials or with
the temporary password provided in the welcome email.
Devices – Fleet View
The fleet view provides a clear visibility of the instrument
fleet with at-a-glance location and status tracking. Users can
export a .csv file of the current device view and turn map view
on/off. The devices can be sorted by Location, Device Type, and
Device Status. Clicking a pin on the map allows sorting devices by
geographic location.
Device Card
The device card provides customizable device name, location,
basic device information, customizable notes, status indicators,
warranty/service care plan certification, and NetProfiler.
Device Details – Overview
This section provides a detailed overview of the device to keep
users informed. It includes customizable device name, general
device information, editable location, quick indicators,
customizable notes, warranty and service care plan end dates, and
the ability to request service with form pre-fill. It also displays
the most recent and recommended certification dates.
Device Details – NetProfiler
In this section, users can monitor the performance of the device
using NetProfiler. It provides NetProfiler status and profile
expiration, certificate of performance export, profiled vs.
unprofiled dE* per tile from the most recent NetProfile, and
profiled vs. unprofiled average dE* over time.
NetProfiler Statistics – Fleet Level
This section allows fleet-level NetProfiler tracking to monitor
compliance and inter-instrument agreement. It shows profiled and
unprofiled devices, inter-instrument agreement impact,
inter-instrument agreement histogram, and provides device-level
tracking with 1-click certificate download.
Service – Records and Statistics
Users can view active service cases in real-time and track past
cases. It is possible to export a .csv file of service records,
filter and sort them. Clicking the RMA number provides service
details. The section also includes service statistics for tracking
the number of service cases and diagnosis reasons.
Adding New Locations
The product allows users to assign devices and users to
locations for easy sorting and permission setting. To create a new
top-level location, users can add a street address to see the
location on the interactive map.
Admins Quick Start Guide
Fleet Management Dashboard
1
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
Access to X-Rite Link
Access X-Rite Link in 3-steps: 1. A system administrator will grant
you access
2. You will receive a welcome email from [email protected]
3. Login using your existing My X-Rite login credentials or with the temporary password provided in the welcome email
link.xrite.com
Welcome to X-Rite Link.
Centralized fleet management and color insights from the experts at X-Rite Pantone To access X-Rite Link, sign in to link.xrite.com You can use your existing my.xrite.com account information to sign in If you have forgotten your password, you can request a password reset at account.xrite.com Thank you, The X-Rite Team
22
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
Devices – Fleet View
Clear visibility of your instrument fleet with at-a-glance location and status tracking
Export .csv file of current device view Turn map view on/off Sort by Location, Device Type, and Device Status
Click a pin to sort for devices by geographic location
Device Card
Customizable device name Location Basic device information
Customizable notes
Status indicators
Warranty/ Service Care Plan Certification NetProfiler
33
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
Device Details – Overview
Detailed device overview to stay informed about your instrument
Customizable device name General device information
Editable location Quick indicators Customizable notes
Warranty and Service Care Plan end dates Request service with form pre-fill
Most recent and recommended certification dates
44
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
Device Details – NetProfiler Click tab Device level NetProfiler details to monitor performance Device details tabs NetProfiler status and profile expiration Certificate of performance export Profiled vs. Unprofiled dE* per tile from the most recent NetProfile
Profiled vs. Unprofiled Average dE* over time
55
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
NetProfiler Statistics – Fleet Level
Fleet level NetProfiler tracking to monitor compliance and inter-instrument agreement
Profiled and unprofiled devices Fleet level inter-instrument agreement impact Inter-instrument agreement histogram
NetProfiled devices at-a-glance
Device level tracking & 1-click certificate download
66
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
Service – Records and Statistics
View active service cases in real time and track past cases
Export .csv file of service records Filter and sort Record of all current and past service records Click the RMA number for service details
Service Statistics for tracking number of service cases and diagnosis reason
77
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
Adding New Locations
Devices and users are assigned to locations for easy sorting and permission setting
Create a new Toplevel location Add a street address to see the location on the interactive map
Create a new Child location
Create a location nested under an existing location
(ex. Creates a location under Printing HQ like Printer #1 and Printer #2. Be sure to select the parent location first.)
88
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
Adding New Admins & Users
Welcome email will be sent to new users with access details
Admins Full permissions to view/ create / modify · Devices · Locations · Users
99
Local Admin Same permissions as a User plus ability to view/ create / modify users at this location only
Users Permissions to view · Devices at assigned
locations
(ex. Only able to see devices at the following locations: Printing HQ including sub-location & Europe Printer #1)
C O N F I D E N T I A L (Internal Use Only) Confidential – Company Proprietary
