Wall Mounted Modular Shelves
Product Information
The A7 Wall Mounted Modular Shelves are a versatile storage
solution for your home or greenhouse. The shelves are made of
durable materials including angle fixing brackets, bracket plates,
cropped head bolts, round head bolts, nuts, wood screws, timber
slats, aluminium tray, and retaining clips. The shelves can be
purchased as single shelves or in packs of three. You have the
option to choose shelves with slats or shelves with a tray.
Product Usage Instructions
- Using the round-headed bolts and nuts, attach the Bracket
Plates to the inside of the Fixing Brackets. Make sure you have an
equal number of left and right brackets. - Decide on the desired height for the shelves and mark the
glazing bar using a pen or scribe. - Insert two cropped bolts into the fixing bracket and align them
with the marked height on the glazing bar. Secure them with two
nuts. If you are installing multiple shelves side by side, place a
second bracket over the first before securing with nuts. - To attach timber slats, use the front four holes on top of the
brackets and secure them with wood screws provided. - If you want to fit the aluminium shelf tray, fix the securing
clip to the back hole on top of the bracket using a bolt and nut
(finger tight only). Slide the shelf tray onto the bracket and
ensure its back edge is positioned under the clip. Tighten the nut
and bolt to clamp the tray in place.
Please refer to the user manual for further instructions and
safety guidelines.
A7
Wall Mounted
Modular Shelves
Assembly Instructions
Components
Angle Fixing Bracket Bracket Plate (left & right) Cropped Head Bolts Round Head Bolts Nuts Wood Screws Timber Slats Aluminium Tray Retaining Clip
Single Shelf
With slats
With tray
2
2
1/1
1/1
4
4
4
6
8
10
8
–
4
–
–
1
–
2
Pack of 3
With slats
With tray
6
6
3/3
3/3
12
12
12
18
24
30
24
–
12
–
–
3
–
6
1. Using the round headed bolts and nuts, attach the Bracket Plates to the inside of the Fixing Brackets so that you have an equal number of left and right.
Once assembled decide at what height you wish to set the shelves
and mark the glazing bar using a pen or scribe.
Insert two of the cropped bolts into the fixing bracket and offer up to the glazing bar of the greenhouse, level with your mark, and secure with two nuts. If you are fitting multiple shelves to run side by side, place a second bracket over the first before securing with the nuts.
Once in position, the timber slats can be attached to the top of the brackets using the front four holes and the wood screws supplied.
If the aluminium shelf tray is to be fitted, fix the securing clip to the back hole on top of the bracket using a bolt and nut finger tight only. Slide the shelf tray onto the bracket and locate its back edge under the clip. Tighten the nut & bolt to clamp the tray in position.
Retaining Clip
Angle Fixing Bracket
Top of Bracket Plate
